Result: blinks.
4 Press or to set the correct time.
Note: Holding down or
setting rapidly.
5 Press .
Result: Setting is complete. blinks.
4.5 To set the brightness of the indoor
unit display
1 On the home screen, press
Result: The selection menu number appears on the display.
is blinking.
2 Press to enter the setting.
(2 sec.)
3 Press or to change the setting as follows:
Blinking
4 Press to confirm the selected setting.
Result: The brightness setting is changed.
Note: The display automatically returns to the default screen after
60 seconds. To return to the default screen sooner, press
twice.
5

Operation

5.1

Operation range

Use the system in the following temperature and humidity ranges for
safe and effective operation.
In combination with outdoor unit RXM25~50, 2MXM40+50,
3MXM40+52
Outdoor temperature –10~46°C DB
Indoor temperature
Indoor humidity
(a)
A safety device might stop the operation of the system if the unit
runs outside its operation range.
CVXM20+FVXM25~50A2V1B
Split system air conditioners
3P477071-2F – 2020.06
increases or decreases the time
for at least 2 seconds.
Brightness
High
Low
Off
(a)
Cooling and Heating
(a)(b)
drying
–15~24°C DB
–15~18°C WB
18~32°C DB 10~30°C DB
14~23°C WB
(b)
≤80% —
(b)
Condensation and water dripping might occur if the unit runs
outside its operation range.
In combination with outdoor unit RXTP25+35
Outdoor temperature –10~46°C DB
Indoor temperature
Indoor humidity
(a)
A safety device might stop the operation of the system if the unit
runs outside its operation range.
(b)
Condensation and water dripping might occur if the unit runs
outside its operation range.
5.2 Operation mode and temperature
setpoint
When. Adjust the system operation mode and set the temperature
when you want to:
▪ Heat up or cool down a room
▪ Blow air in a room without heating or cooling
▪ Decrease the humidity in a room
What. The system operates differently, depending on the user
selection.
Setting
The system cools down or heats up a
Automatic
room to the temperature setpoint. It
automatically switches between cooling
and heating if necessary.
The system decreases the humidity in a
Drying
room.
The system heats up a room to the
Heating
temperature setpoint.
The system cools down a room to the
Cooling
temperature setpoint.
The system only controls the airflow
Fan
(airflow rate and airflow direction).
The system does NOT control the
temperature.
Additional info:
▪ Outside temperature. The system's cooling or heating effect
decreases when the outside temperature is too high or too low.
▪ Defrost operation. During heating operation, frost might occur on
the outdoor unit and decrease the heating capacity. In that case,
the system automatically switches to defrosting operation to
remove the frost. During defrosting operation, hot air is NOT
blown from the indoor unit.
5 Operation
(a)
Cooling and Heating
(a)(b)
drying
–25~24°C DB
–25~18°C WB
18~32°C DB 10~30°C DB
14~23°C WB
(b)
≤80% —
Description
Operation manual
7
