To connect using the WPS button
1 On the home screen, press
unit is not operating.
Result: SP appears on the display. is blinking.
2 Press to change the SP menu to .
(5 sec.)
3 Press to confirm the selection.
Result: is blinking. The Daikin eye colour alternates between
orange and partly green.
4 Press the WPS button on your communication device (e.g.
router) within approximately 1 minute. Refer to the manual of
your communication device.
Result: If the connection was successful, the Daikin eye colour
alternates between blue and partly green.
INFORMATION
If the connection with your router is not possible, try
procedure "To connect
number" [ 4 15].
5 Press to exit the menu.
Result: The display will return to the home screen.
To connect using SSID and KEY number
1 On the home screen, press
unit is not operating.
Result: SP appears on the display. is blinking.
2 Press twice to change the SP menu to .
(5 sec.)
3 Press to confirm the selection.
Result: is blinking. The Daikin eye colour alternates between red
and partly green.
4 Open the Daikin Residential Controller application on your
smart device and follow the steps on the screen.
Result: If the connection was successful, the Daikin eye colour
alternates between blue and partly green.
5 Connect your smart device to the same home network as the
unit.
6 Press to exit the menu.
Result: The display will return to the home screen.
To reset the connection setting to the factory
default
Reset the connection setting to the factory default in case you want
to:
▪ disconnect the wireless LAN and the communication device (e.g.
router) or smart device.
▪ repeat the setting if the connection was unsuccessful.
CVXM20+FVXM25~50A2V1B
Split system air conditioners
3P477071-2F – 2020.06
for at least 5 seconds while the
1×
using SSID and KEY
for at least 5 seconds while the
2×

6 Energy saving and optimum operation

1 On the home screen, press
unit is not operating.
Result: SP appears on the display. is blinking.
2 Press twice to change the SP menu to .
(5 sec.)
3 Hold for at least 2 seconds to confirm the selection.
Result: is blinking. The setting is reset to the factory default.
4 Press to exit the menu.
Result: The display will return to the home screen.
To turn off the wireless LAN connection
If you want to turn off the wireless connection function:
1 On the home screen, press
unit is not operating.
Result: SP appears on the display. is blinking.
2 Press change the SP menu to
(5 sec.)
3 Hold for at least 2 seconds to confirm the selection.
Result: is blinking. Communication is OFF.
4 Press to exit the menu.
Result: The display will return to the home screen.
6 Energy saving and optimum
operation
INFORMATION
▪ Even if the unit is turned OFF, it consumes electricity.
▪ When the power turns back on after a power break, the
previously selected mode will be resumed.
CAUTION
NEVER expose little children, plants or animals directly to
the airflow.
WARNING
Do NOT place objects below the indoor and/or outdoor unit
that may get wet. Otherwise condensation on the unit or
refrigerant pipes, air filter dirt or drain blockage may cause
dripping, and objects under the unit may get dirty or
damaged.
WARNING
Do NOT place a flammable spray bottle near the air
conditioner and do NOT use sprays near the unit. Doing so
may result in a fire.
for at least 5 seconds while the
2×
for at least 5 seconds while the
.
1×
