Connectors
Part Description
2-pin DuraClik
DuraClik cable assembly
Power Plug ( P4 )
This powers up the board with a 12V supply. Power is required when the board is operating in both master and slave
mode.
Part Description
2.1 mm power jack
12.0VDC@1.5A power supply
Power Terminal ( P5 )
This powers up the board with a 12V supply. Power is required when the board is operating in both master and slave
mode.
Part Description
5.08mm power jack
12.0VDC discrete wires
Battery ( P6 )
The battery connector is a terminal block for connecting to a 3.7V Li-Ion battery.
tested on the board.
Jumpers
This section describes functionality of the configuration jumpers. The Jumper Locations figure shows the jumper
locations.
3–6
Manufacturer
Molex
Mating Cable
Manufacturer
CUI
Mating Cable
CUI
Manufacturer
Weidmuller
Mating Cable
Part Number
5023520200
Part Number
PJ-102AH
EMSA120150-P5RP-SZ
Part Number
1760510000
This
EVAL-AD2428WD1BZ A
battery from adafruit was
2
B Evaluation Board Manual
