This mount kit supports multiple AP models. All installation images show the 225 AP.
1. Begin by attaching the wall mount adapter to the wall as shown in
a. Install any necessary wall anchors. Wall anchors are not included in this kit.
b. Align the screw holes in the mounting bracket with the previously installed anchors or demarcated
screw points.
c. Insert the screws to secure the mounting bracket. Screws are not included in this kit.
Figure 1 Attaching the Adapter to a Wall
Figure 2 Attaching the Adapter to a Wall (Alternate)
0511288-04 | March 2015
AP-220-MNT-W1W Wall Mount Kit
Installation Guide
Figure 1
or
Figure
2.
1
