COMPONENT IDENTIFICATION

LEFT SIDE VIEW
Individual Interlock
Function 1 Setting
Individual Interlock no.
Individual Interlock
Function 2 Setting
■ INDICATOR LED
LED OPERATION
Status OFF
Green ON
Green Blinking
Red ON
Red Blinking
Output OFF
Green ON
Interlock OFF
Red ON
■ INPUT CONNECTOR ASSIGNMENT
PIN
1
No.
2
1
3
4
2
3
4
FRONT VIEW
DIP SW
2 1
Individual Interlock 1
Connector
On
Individual Interlock 1
Indicator LED
Setting Rotary SW
Individual Interlock 2
Indicator LED
Individual Interlock 2
Connector
21
On
DIP SW
FUNCTION
Stopping
Valid host communication
Reading / writing configura-
tion
Setting error
Parameter error
OFF
ON
Interlock invalid
Interlock valid
Output ON
Interlock valid
Output OFF
ID FUNCTION
24V Excitation supply 24 V
IL Discrete input
0V Excitation supply 0 V
NC No connection
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
Status Indicator LED
RUN
Discrete Output Indicator LED
IL1
1 9
2 10
3 11
4 12
5 13
6 14
7 15
8 16
Internal Bus Connector
OUT
Output Connectors
1 2
Full Interlock
19 20
Indicator LED
Full interlock
Connector
IL2
IL ALL
■ OUTPUT CONNECTOR ASSIGNMENT
PIN
No.
1
1 2
2
3
4
5
19 20
6
7
8
9
10
11
12
13
14
15
16
17, 18
19, 20
R8-DCM16ALK
RIGTH SIDE VIEW
Function Setting
SW1
Full Interlock
Function Setting
DIP SW
ID FUNCTION
Do1 Output 1
Do2 Output 2
Do3 Output 3
Do4 Output 4
Do5 Output 5
Do6 Output 6
Do7 Output 7
Do8 Output 8
Do9 Output 9
Do10 Output 10
Do11 Output 11
Do12 Output 12
Do13 Output 13
Do14 Output 14
Do15 Output 15
Do16 Output 16
0V Excitation supply 0V
24V Excitation supply 24V
EM-9747 Rev.2
DIP SW
SW2
8
7
6
5
4
3
2
1
On
1 2
On
P. 3 / 5
