Ruckus SmartZone 100
Quick Setup Guide
Supporting SmartZone 5.1
This Quick Setup Guide provides basic instructions for
setting up the Ruckus SmartZone 100 (SZ100) on the
network. For information on advanced configuration and
management options, see the SmartZone 100 Getting
Started Guide and SmartZone 100 Administrator Guide,
which are available for download from the Ruckus
Support website:
https://support.ruckuswireless.com/documents
This Guide in Other Languages
请从以下网站获得该指南的简体中文版 https://
support.ruckuswireless.com.
Vous trouverez la version française de ce guide à
l'adresse suivante https://support.ruckuswireless.com.
このガイドの日本語版は https://
support.ruckuswireless.com でご覧ください。
이 가이드의 한국어 버전은 웹 사이트 (https://
support.ruckuswireless.com) 에서 확인하시기 바랍니다.
Veja a versão em português (Brasil) deste guia em
https://support.ruckuswireless.com.
Puede ver la versión en español (América Latina) de esta
guía en https://support.ruckuswireless.com.
Licensing Information
The SZ100 comes pre-shipped with 1000 temporary AP
Capacity Licenses, which are valid for a period of 90 days
from when the SZ100 is configured via the initial setup
configuration. For operation beyond 90 days, you MUST
buy permanent AP Capacity licenses. The purchased
Licenses MUST be activated for them to become valid.
The management of the AP Capacity Licenses and the
ability to activate the permanent License will be through
the Ruckus Support Portal (https://
support.ruckuswireless.com). An email will be sent to the
User that is identified on the Purchase Order and full
Copyright © 2018 ARRIS Enterprises LLC. All rights reserved.
Published November 2018, Part Number 800-71962-001 Rev A
instructions as to how to activate the Licenses is included
in the email. As a guide, full instructions can be found at
https://support.ruckuswireless.com/activate.
Using the LiMAN (license management) portal on the
Ruckus Support website, you can assign licenses to or
from a SZ100 or move them to another SZ100 (see a
summary of LiMAN features in Table 1). To physically
manage the distribution of licenses from the Support
website to the actual SZ100, do one of the following:
• Connect the SZ100 directly to the Internet.
• Deploy a Ruckus Local License Server (LLS) within your
network. The LLS must be able to communicate with
your SZ100 and it must be connected to the Internet.
– LLS should first synchronize with the license server in
the cloud to get the required license (as per the
SZ100 serial number)
– Remove licenses from one SZ100 to add to another
NOTE: NOTE: In the event that the SZ100 is not
connected to the Internet and you have not deployed
an LLS, you can download the actual licenses from the
Support Portal and manually upload to the specific
SZ100.
For step-by-step instructions on how to activate the
SZ100's licenses, see Step 5: Activate the SZ100's Licenses
on page 3.
TABLE 1 LiMAN features and how to activate them on the
SZ100
LiMAN Features SZ100 Online
(Connected to
the Internet)
• Register SZ100 No action
controllers, required. The
licenses, SZ100 syncs with
support LiMAN
entitlement automatically
within 24 hours
• Add capacity
and applies the
licenses to
appropriate
SZ100
licenses.
controllers
• Remove
licenses from
one SZ100 and
add to another
TABLE 1 LiMAN features and how to activate them on the
SZ100 (continued)
LiMAN Features
Before You Begin
Before deploying Ruckus Networks products, please
check for the latest software and the release
documentation.
• Release Notes and other user documentation are
available at http://support.ruckuswireless.com/
documents.
• Software upgrades are available at
support.ruckuswireless.com/software.
• Open source information is available at
opensource.ruckuswireless.com.
• Software license and limited warranty information are
available at http://support.ruckuswireless.com/
warranty.
Package Contents
• One SmartZone 100 appliance with one AC/DC power
supply unit and power cord
SZ100 Offline
• One console cable
(Disconnected
from the • One rack mount kit
Internet)
• Service Level Agreement/Limited Warranty Statement
sheet
Three steps
• Regulatory Statement sheet
required:
• This Quick Setup Guide
1. Download the
license file
What You Will Need
from LiMAN.
• An administrative computer (admin PC) with a
2. Log on to the
connection to the local area network
SZ100, and
then upload
• A web browser, such as Internet Explorer, Mozilla
the license
Firefox, Google Chrome or Apple Safari
file from
• The IP address, netmask, gateway and DNS server
LiMAN.
addresses assigned to the SZ100 —if it has a static
3. Download the network address (recommended)
license
response file
from the
SZ100 Online SZ100 Offline
(Connected to (Disconnected
the Internet) from the
Internet)
SZ100, and
then upload it
to LiMAN.
http://
http://
