Ruckus Wireless SmartZone 100 Quick Setup Manual

Ruckus Wireless
SmartZone
™
Quick Setup Guide for SmartZone
3.4.1
This Quick Setup Guide provides basic instructions for setting
up the Ruckus Wireless SmartZone 100 (SZ-100) on the
network. For information on advanced configuration and
management options, see the SmartZone 100 Getting Started
Guide and SmartZone 100 Administrator Guide, which are
available for download from the Ruckus Wireless Support
website:
https://support.ruckuswireless.com/documents
This Guide in Other Languages
请从以下网站获得该指南的简体中文版
https://support.ruckuswireless.com.
Vous trouverez la version française de ce guide à l'adresse
suivante https://support.ruckuswireless.com.
こ の ガ イ ド の⽇本語版は
https://support.ruckuswireless.com
で ご 覧 く だ さ い。
이 가이드의 한국어 버전은 웹 사이트
(https://support.ruckuswireless.com)
에서 확인하시기 바랍니다 .
Veja a versão em português (Brasil) deste guia em
https://support.ruckuswireless.com.
Puede ver la versión en español (América Latina) de esta guía
en https://support.ruckuswireless.com.
Licensing Information
The SZ-100 comes pre-shipped with 1000 temporary AP
Capacity Licenses, which are valid for a period of 90 days from
when the SZ-100 is configured via the initial setup
configuration. For operation beyond 90 days, you MUST buy
permanent AP Capacity licenses. The purchased Licenses
MUST be activated for them to become valid.
The management of the AP Capacity Licenses and the ability
to activate the permanent License will be through the Ruckus
Wireless Support Portal (https://support.ruckuswireless.com).
An email will be sent to the User that is identified on the
Copyright © 2016 Ruckus Wireless, Inc.
Published October 2016, Part Number 800-71383-001 Rev A
Purchase Order and full instructions as to how to activate the
Licenses is included in the email. As a guide, full instructions
can be found at https://support.ruckuswireless.com/activate.
Using the LiMAN (license management) portal on the Ruckus
Wireless Support website, you can assign licenses to or from a
SZ-100 or move them to another SZ-100 (see a summary of
LiMAN features in
™ distribution of licenses from the Support website to the actual
SZ-100, do one of the following:
100
• Connect the SZ-100 directly to the Internet.
• Deploy a Ruckus Wireless Local License Server (LLS)
within your network. The LLS must be able to
communicate with your SZ-100 and it must be connected
to the Internet.
• LLS should first synchronize with the license server in
the cloud to get the required license (as per the SZ-
100 serial number)
• Remove licenses from one SZ-100 to add to another
NOTE: In the event that the SZ-100 is not connected to the
Internet and you have not deployed an LLS, you can download
the actual licenses from the Support Portal and manually
upload to the specific SZ-100.
For step-by-step instructions on how to activate the SZ-100's
licenses, see
Table 1. LiMAN features and how to activate them on the SZ-100
LiMAN Features SZ-100 Online
• Register SZ-100
controllers,
licenses, sup-
port entitlement
• Add capacity
licenses to SZ-
100 controllers
• Remove
licenses from
one SZ-100 and
add to another
Before You Begin
Before deploying Ruckus Wireless products, please check for
the latest software and the release documentation.
• Release Notes and other user documentation are available
at http://support.ruckuswireless.com/documents.
• Software upgrades are available at
http://support.ruckuswireless.com/software.
Table 1). To physically manage the
Step 5: Activate the SZ-100's Licenses.
SZ-100 Offline
(Connected to (Disconnected from the
the Internet) Internet)
No action Three steps required:
required. The 1 Download the license file
SZ-100 syncs from LiMAN.
with LiMAN
2 Log on to the SZ-100,
automatically
and then upload the
within 24 hours
license file from LiMAN.
and applies the
3 Download the license
appropriate
response file from the
licenses.
SZ-100, and then upload
it to LiMAN.
• Open source information is available at
http://opensource.ruckuswireless.com.
• Software license and limited warranty information are
available at http://support.ruckuswireless.com/warranty.
Package Contents
• One SmartZone 100 appliance with one AC/DC power
supply unit and power cord
• One console cable
• One rack mount kit
• Service Level Agreement/Limited Warranty Statement
sheet
• Regulatory Statement sheet
• This Quick Setup Guide
What You Will Need
• An administrative computer (admin PC) with a connection
to the local area network
• A web browser, such as Internet Explorer, Mozilla Firefox,
Google Chrome or Apple Safari
• The IP address, netmask, gateway and DNS server
addresses assigned to the SZ-100 —if it has a static
network address (recommended)
Step 1: Connect the SZ-100 to the Network
#1 Connect the SZ-100 to a convenient power source, and
then press the power switch on the rear panel. The Alarm
LED shows a flashing red light as the SZ-100 starts up.
When the SZ-100 has started up successfully, the Alarm
LED turns to a solid green light.
#2 Obtain an Ethernet cable. Connect one end of the Ethernet
cable to one of the LAN ports (port 1 or 2 recommended)
on the SZ-100, and then connect the other end to your
network's switch or router. DHCP server should be
available in the connected LAN environment for SZ-100 to
get the IP address.
NOTE The SZ-100 is a Universal Plug and Play (UPnP) device.
Once you connect it to the network, it will automatically configure
itself, obtain an IP address, and make its presence known to other
devices on the network.
#3 Go to the admin PC and verify that the SZ-100 is now
discoverable on the network. On Windows 7 and Windows
8, go to Control Panel > Network and Internet > View
network computers and devices, and then locate the
Network Infrastructure section. The SZ-100 should appear
there. In such scenarios, SZ-100 and a system (laptop or a
