Specifications

General
Number of channels
Output power
Maximum output power per channel @ 4 Ω
Maximum output power per channel @ 8 Ω
Maximum output power per channel @ 16 Ω
Maximum output power @ 8 Ω Bridged
Maximum output power @ 16 Ω Bridged
Max output voltage
Max output current
Audio
Gain
Frequency response
S/N ratio
Crosstalk separation
Input sensitivity @ 8�
Max input level
Input impedance
THD+N
DIM100
Slew rate
Damping factor
Construction
Dimensions (L x W x H)
Weight
4 in / 4 out
2000 W
1000 W
600 W
3000 W
2000 W
150 V
peak
54 A
peak
selectable: 32 dB, 38 dB
(x40, x80 voltage gain respectively)
20 Hz - 20 kHz ( +0/-1 dB) @ 1 W, 8 �
115 dB (A weighted)
-70 dB @ 1 kHz (4 �)
1.6 V / +6 dBu
2.7 V / +10.8 dBu @ 32 dB gain
10 k� balanced
< 0.09% from 0.1 W to full power
(typically <0.05%)
< 0.05% from 0.1 W to full power
(typically <0.002%)
50 V/µs @ 8 �, input filter bypassed
> 500 @ 100 Hz
309 mm x 122 mm x 79 mm
12" x 4.8" x 3.1"
2.4 kg (5.3 lb)
AC Mains Power
Power supply
Nominal power requirement
Operating voltage
Power factor
Consumption
1/8 of max output power @ 8 �
AUX supplies
Max aux supply current draw @ ±12 V
Thermal & Environment
Operating temperature &
Humidity
Thermal dissipation Fan, variable speed, temperature controlled
I/8 of max power @ 4 Ω
I/4 of max power @ 4 Ω
I/8 of max power @ 4 Ω
I/4 of max power @ 4 Ω
Reference Standard
Vibration
EMC immunity
EMC emissions
EMC other
Safety standards
13
Universal, regulated switch mode with
PFC (power factor correction)
AC 100 V - 240 V, 50/60 Hz
AC 90 - 264 V
cos > 0.90 @ 4 � full power
600 VA
500 mA
0° to 35° C, 0 to 90% Non condensing
@ 230 V
508 BTU/h 128 kcal/h
956 BTU/h 241 kcal/h
@ 115 V
621 BTU/h 156 kcal/h
1154 BTU/h 290 kcal/h
EN 60068-2-64: 2008 (Random Test)
EN 60068-2-27:2009 (Shock Test)
EN 55103-2:2009
EN 55103-1:2009,
EN 55103-1:2009/A1:2012
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 61000-3-11:2000
EN 60065:2014
EN 60065:2014/AC:2016
Electrical characteristics T
(unless otherwise specified)
Specifications | 21
= 25° C
a
