3330 Dixie-Narco Blvd.
Williston, SC 29853
www.dixienarco.com
Energy Star Evaporator Fan Motor Sub-Assembly
06/10/09
Please read these instructions in their entirety before proceeding.
Ensure that the Electrical Power is disconnected from the Vending Machine by removing Vending
Machine Power Cord from the wall outlet.
Remember use caution working with the Refrigeration Unit parts. These parts may have sharp edges and
corners.
Failure to comply with these instructions could result in injury or electrical shock, which can be serious
or fatal.
M095.0
276E HVV
Models affected:
Produced Beginning Production Run 6757DZ and higher.
Reason: To Provide Step-by-Step Instructions for the
removal of the current Evaporator Fan Shroud Assembly
and installation of the new Energy Star Evaporator Fan
Shroud Assembly. This kit is designed to be installed in
venders with factory installed Environmental Control Kits
and SBC (Single Board Controller) E Model electronics.
Additional information for the Environmental Control
Assembly (631,004,00x.x4) can be obtained from
Instruction E013.x or contact your Dixie-Narco
Representative or the Technical Service Department.

Safety Precautions!

All Pepsi HVV 276E-Model Venders
M095.x
1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HVV 276E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dixie Narco HVV 276E

  • Page 1 Energy Star Evaporator Fan Motor Sub-Assembly 276E HVV 06/10/09 Models affected: All Pepsi HVV 276E-Model Venders Produced Beginning Production Run 6757DZ and higher. Reason: To Provide Step-by-Step Instructions for the removal of the current Evaporator Fan Shroud Assembly and installation of the new Energy Star Evaporator Fan Shroud Assembly.
  • Page 2 Order Kit: 646,070,00x.x3 Energy Star Evaporator Fan Motor, Narrow Sub-Assembly Kit contents: Part Number Description Quantity in Kit 609,050,73x.x3 Housing, Right Evap. 58mm ECM Motor 609,050,74x.x3 Housing, Left Evap. 58mm ECM Motor 609,050,83x.x3 Shroud, Fan Evap. Narrow EBM Papst 609,050,84x.x3 Cover, Evap.
  • Page 3 5. Locate and disconnect the Evaporator Fan Leads (See Figure 2) from the Main Power Harness. Evaporator Fan Leads Main Power Harness Figure 2 6. Remove the two (2) fasteners from the Top Evaporator Cover (Figure 3 marked “A”) and discard them.
  • Page 4 Figure 4 14. Lay the new Evaporator Fan Shroud Assembly on a flat surface as shown in Figure 5. Figure 5 15. Align the male fan connectors to the female fan connectors of the Main Power Harness. When connecting, align the ribbed wires with ribbed wires and smooth wires with smooth wires. Ensure nothing is in the fan blade area.
  • Page 5 22. Center the Evaporator Fan Shroud Assembly in the back of the Cabinet so it rests on the bottom of the Tank. 23. With a drill, secure the Evaporator Fan Shroud Assembly with four (4) new Self Drilling Screws (800,304,18x.x1). See “A” in Figure 6. Figure 6 24.
  • Page 6 Figure 9 Clean this area. 30. Remove the protective paper from the back side of the Foam, Poly Strip Narrow (803,301,58x.x1) and apply gasket to the cleaned area as shown in Figure 10. This edge goes to the back of the cabinet.
