- Page 2 SIID CONTROLLER PROGRAMMING 0773-6201CS & HIGHER The controller has two modes of operation: NORMAL MODE: In normal mode, the display will show a decimal point. If decimal is blinking, this indicates an error or problem recognized in the vender. When money is inserted, the display indicates the total amount of the deposit.
- Page 3 This section is used to count coins loaded in the top (separator) of the coin mech. Insert coins in the top (separator) of the coin mech. The total value of the coins will be displayed and will be counted in the DEX audit data, so the SIID controller knows exactly how much change is in the coin mech.
- Page 4 SIID CONTROLLER PROGRAMING STS - SPACE TO SALES To view the space to sales condition, press any select button to display the current columns assigned to that select button. To change space to sales condition: To Add Selection: Press Service Switch, "ADD" will be displayed. Note: Pressing the service switch will toggle between add and delete.
- Page 5 SIID CONTROLLER PROGRAMING ESC - ESCROW This section supports 4 (four) escrow options. To show the current escrow condition, press any select button. To change the escrow condition: Press & hold Select Button 1: "Pr" - Escrow to Price The escrow condition is "escrow to price". All dollar bills will be stacked. No cancel sale is allowed once minimum vend price is met or exceeded.
- Page 6 This function is used to show historical total vends, historical product counts that have occurred for prices being used, and interval product count for each selection from outside the vender. To program the SIID to use this function, press any select button. The current setting or four (4) key programming will be displayed. If "----" no code is programmed.
- Page 7 CR - CHANGE RULES (for use with foreign L-Plus coin mechs only) Some countries have coin mechs that do not use all three coin tubes. This would not allow the SIID to come out of exact change mode. To accommodate this, the Change Rules section allows the SIID to be programmed to use the tubes necessary for the SIID to not be in an exact change mode.
- Page 8 SIID CONTROLLER PROGRAMING LAOS - LIMITED ACCESS ON SELECTION This function is used to set selection(s) which will be limited during certain periods of the day. To view the limited access on selection condition, press any select button. The display will show "DISABLED" or "ENABLED SEL - #(s) where # shows the selections that are set for limited access.
- Page 9 SIID CONTROLLER PROGRAMING RTN - RETURN This function is used to return to the User Option Menu. Press select buttons 1 & 2 simultaneously to return to "LAOS". Press select button 1 to return to the User Option Menu at "LIM".
- Page 10 This function is used to allow 5, 6, and 8 column venders to be set on free-vend using a mechanical switch. The free- vend enable must be turned on for the switch to allow free-vend, and a free-vend switch kit (491,742,600.04) must be installed using installation instructions E004.X from Dixie-Narco. Press Select Button 1: Toggle free-vends on (ENABLED) and off (DISABLED).
- Page 11 SIID CONTROLLER PROGRAMING DSTR – DAYLIGHT SAVINGS TIME RULES This function is used to set the "DSTR" as it applies to American time or European time. To show current "DSTR" condition: Press any select button and the display will show the current settings.
- Page 12 SIID CONTROLLER PROGRAMING MV – MULTI VEND This function, when turned on, allows credit to be retained after a vend so the customer can vend from another selection. (i.e. .50¢ vend price, put in $1.00, push a select button and vends, 50¢ still shows on display, push a second selection button and vends).
- Page 13 C. Sold Out Switches F. Coin Mech The operator will manipulate switches, run motors, and insert money while the SIID control box monitors all these functions. If any errors are found, they will be logged and displayed to the operator on the display.
- Page 14 SIID CONTROLLER PROGRAMING SIID Quick Reference Menu Prompts Main Menu Sub-Menu Sub-Menu (Historical Data) (Resettable Data) (Set Price) (Coin Dump / Coin Fill) USER (User Options) (Space-To-Sales) TIME (Time) DATE (Escrow) LANG (Language) PROM (Promotional Sales) ECNT (Electronic Counters) (Note Factor)
