INSTALLATION AND SET-UP GUIDE
Please read this manual in its entirety. This service information is intended to be used by a
qualified service technician, who is familiar with proper and safe procedures to be followed when
repairing, replacing, or adjusting any Dixie-Narco vender components. All repairs should be
performed by a qualified service technician who is equipped with the proper tools and replacement
components, using genuine Dixie-Narco factory parts.
REPAIRS AND/OR SERVICING ATTEMPTED BY UNQUALIFIED
PERSONS CAN RESULT IN HAZARDS DEVELOPING DUE TO
IMPROPER ASSEMBLY OR ADJUSTMENTS WHILE PERFORMING
SUCH REPAIRS. PERSONS NOT HAVING A PROPER BACKGROUND
MAY SUBJECT THEMSELVES TO THE RISK OF INJURY OR
ELECTRICAL SHOCK, WHICH CAN BE SERIOUS OR EVEN FATAL.
Upon receipt, inspect the vender for any shipping damage. If there is any damage, have the driver
note the damage on the bill of lading and notify Dixie-Narco. Although I.C.C. regulations require
that the consignee originate shipping damage claims, Dixie-Narco will be happy to assist you if
you must file a shipping damage claim.
Remove the stretch wrap and top cover from the vender.
NOTE:
DO NOT STORE THE VENDER OUTSIDE WITH STRETCH WRAP ON.
THIS COULD CAUSE THE STRETCH WRAP TO BOND TO THE
VENDER'S SURFACE, WHICH COULD DAMAGE THE FINISH.
Remove the shipping boards from the bottom of the vender. The shipping boards are attached
by the leveling legs. To avoid unnecessary damage to the leveling legs or base, remove the
shipping boards by using a 1-1/2 inch "socket type" wrench to unscrew the leveling legs. Be sure
to replace the legs after removing the shipping boards.
To open the vender, locate the door lock keys that are located inside the coin return cup. After
unlocking the door, rotate the T-handle counterclockwise until the door can be opened. Once
inside, remove and discard the wood shipping block from the bottom right side of the cabinet.
Check the coin box, under the can/bottle chute, and between the column walls for any additional
flavor strips, additional parts, pricing labels or information concerning factory installed parts such
as coin mechanism, validator or card reader. Check the T-handle for proper alignment with the
cabinet and locking functions. Check the lamp for proper operation.
WARNING: ENSURE THAT POWER IS DISCONNECTED FROM THE
VENDER OR THAT THE POWER INTERRUPT SWITCH (IF PROVIDED)
IS NOT DEFEATED BEFORE INSPECTING OR REPLACING THE
LAMPS. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY
SUBJECT THE USER TO THE RISK OF ELECTRICAL SHOCK, WHICH
CAN BE SERIOUS OR FATAL.
SERIES 90 VENDERS
903,901,600.21

RECEIVING INSPECTION

UNPACKING THE VENDER

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 90 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dixie Narco 90 Series

Summary of Contents for Dixie Narco 90 Series

  • Page 1 INSTALLATION AND SET-UP GUIDE SERIES 90 VENDERS 903,901,600.21 Please read this manual in its entirety. This service information is intended to be used by a qualified service technician, who is familiar with proper and safe procedures to be followed when repairing, replacing, or adjusting any Dixie-Narco vender components.
  • Page 2 WARNING: DO NOT STORE ANYTHING OR ALLOW DEBRIS OF ANY KIND TO ACCUMULATE IN THE BOTTOM OF THE DOOR, IN AND AROUND THE REFRIGERATION COMPARTMENT OF THE CABINET, OR IN FRONT OF THE EVAPORATOR AND CONDENSER COILS. ELECTRIC POWER REQUIREMENTS Refer to the cabinet serial number plate/label to determine the proper voltage and frequency required by the vender.
  • Page 3 DANGER: THE VENDER MUST BE PROPERLY LOCATED AND LEVELED. IF THE MACHINE WILL BE SUBJECT TO USER MISUSE OR VANDALISM IT IS RECOMMENDED THAT THE VENDER BE SECURED TO THE FLOOR OR WALL AS DESCRIBED IN DIXIE-NARCO TECHNICAL BULLETIN NO. 344 TO MINIMIZE THE RISK OF INJURY OR DEATH FROM TIPPING.
  • Page 4 GE TEMPERATURE CONTROL ADJUSTMENT Adjustment #1 – GE Temperature Adjustment The GE Temperature control is factory preset at position #4 as shown in figure 2. Turn the Temperature adjustment screw shown in figure 2 in a clockwise direction for colder product or in a counter clockwise direction for warmer product.
  • Page 5 LOADING INSTRUCTIONS PRODUCT SHIMMING Dixie-Narco venders are shipped ready to vend 12 oz. (330ml) cans unless another package was specified at the time the vender was ordered. To vend an alternative package, contact Dixie-Narco Technical Service or refer to the appropriate Dixie-Narco set up information for the package to be vended.
  • Page 6 Rod and Spring Assembly installation (Narrow Column) Insert the rod as shown below. Refer to the appropriate Technical Bulletin or refer to the appropriate Dixie-Narco set up information for the package to be vended for the proper position of the rod. Package Loading (Narrow Column) Position the rotors as shown.
  • Page 7 CLEANING THE VENDER DO NOT USE A WATER JET OR NOZZLE TO CLEAN THE VENDER SIGN FACE The polycarbonate sign face requires proper cleaning to prolong its service life. It is recommended that you periodically inspect and clean the sign face as follows: •...
  • Page 8 DRAIN PAN/SOAKERS • Check the drain pan & soakers periodically for dirt, debris, and proper alignment. • Remove any dirt and debris by removing the drain pan, cleaning pan and soakers, and reinstalling. • Ensure nothing is obstructing the drain tube and drain hose. COIN ACCEPTOR •...
