Parts List - Icom IC-M220 Service Manual

SECTION 5
[MAIN UNIT]
REF PART
NO. NO.
IC2 1110008890 S.IC NJU7056F3-TE2-#ZZZH
IC201 1110010000 S.IC AT1846S
IC301 1110010000 S.IC AT1846S
IC302 1130019580 S.IC TC7SU04FULF
IC504 1130015760 S.IC TC74VHC4066AFK (EK)
IC505 1110008890 S.IC NJU7056F3-TE2-#ZZZH
IC506 1110010010 S.IC U2429G-S08-R
IC511 1180003980 S.REG XC6221A332MR-G
IC512 1180002781 REG KIA7805API-U/PF
IC551 1120003230 S.IC UTRS485G-S08-R
IC552 1170000352 S.IC PC357N6J000F
IC701 1110009990 IC TDA2003L-TB5-T
IC702 1110008890 S.IC NJU7056F3-TE2-#ZZZH
IC703 1130007021 S.IC TC7S66FU (TE85LF)
Q10 1510001090 S.TRA KTA2015Y-RTK/P
Q11 1590004070 S.TRA LDTC144EET1G
Q12 1530004011 S.TRA KTC3770U-C-RTK/P
Q13 1560002580 S.FET AFT05MS003NT1
Q14 1560002590 S.FET AFT05MS031NR1
Q16 1590004060 S.TRA LDTC114EET1G
Q17 1590004060 S.TRA LDTC114EET1G
Q18 1590004070 S.TRA LDTC144EET1G
Q19 1590004070 S.TRA LDTC144EET1G
Q101 1530004100 S.TRA MT3S20P (TE12LF)
Q201 1590004040 S.TRA LDTA123YET1G
Q202 1590004070 S.TRA LDTC144EET1G
Q511 1590004070 S.TRA LDTC144EET1G
Q512 1550000590 S.FET UT6401G-AG6-R
D11 1750002540 S.DIO LRB520G-30T1G
D12 1750002350 S.DIO MMBD352WT1
D13 1750002350 S.DIO MMBD352WT1
D14 1750002190 S.DIO JDP2S12CR (TE85LQ)
D15 1750003520 S.DIO L5204FR
D16 1750002350 S.DIO MMBD352WT1
D551 1750001810 S.DIO L1SS400T1G
D601 1710001440 DIO 1N5402-F
X2 6050014830 S.XTA CR-1073 (26 MHz)
L1 6200013750 S.COI MLK1005SR10JT
L2 6200012880 S.COI 0.30-1.3-6TL 24.5N
L3 6200013110 S.COI 0.35-1.6-9TL 52.0N
L4 6200013030 S.COI 0.35-1.6-6TL 31.0N
L5 6200013030 S.COI 0.35-1.6-6TL 31.0N
L6 6200012390 S.COI 0.30-0.92-3TR 5.8N
L7 6200012870 S.COI 0.30-1.4-5TR 23.5N
L101 6200016650 S.COI LQW2BASR82J00L
L102 6200014320 S.COI 0.80-3.0-5TR 41.0N
L103 6200014330 S.COI 0.80-2.7-5TR 35.0N
L105 6200012700 S.COI 0.50-2.0-6TL 35.0N
L106 6200011670 S.COI LQW18AN82NG00D
L107 6200010910 S.COI LQW18AN56NG00D
L108 6200011670 S.COI LQW18AN82NG00D
L109 6200011860 S.COI LQW18ANR47G00D
L111 6200011650 S.COI LQW18AN68NG00D
L112 6200011650 S.COI LQW18AN68NG00D
L211 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00)
L216 6200001981 S.COI NLV25T-1R0J-PF
L217 6200001981 S.COI NLV25T-1R0J-PF
L311 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00)
L312 6200004660 S.COI MLF1608A 1R8K-T
L313 6200004660 S.COI MLF1608A 1R8K-T
R11 7030015970 S.RES RMC1/16S-103JTH (10 k)
R12 7030016050 S.RES RMC1/16S-102JTH (1 k)
R21 7030016560 S.RES RMC1/16SJPTH
R22 7030015970 S.RES RMC1/16S-103JTH (10 k)
R23 7030016330 S.RES RMC1/16S-153JTH (15 k)
R24 7030016150 S.RES RMC1/16S-100JTH (10)
R25 7030016560 S.RES RMC1/16SJPTH
R26 7030015910 S.RES RMC1/16S-101JTH (100)
R31 7030015910 S.RES RMC1/16S-101JTH (100)
R32 7030016110 S.RES RMC1/16S-473JTH (47 k)
R33 7030015970 S.RES RMC1/16S-103JTH (10 k)
R34 7030016110 S.RES RMC1/16S-473JTH (47 k)
R35 7030015970 S.RES RMC1/16S-103JTH (10 k)
R44 7030015520 S.RES RMC1/16JPTP
R45 7030015910 S.RES RMC1/16S-101JTH (100)
R46 7030016020 S.RES RMC1/16S-104JTH (100 k)
R47 7030015970 S.RES RMC1/16S-103JTH (10 k)
R71 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R72 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R73 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R74 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R75 7030014850 S.RES RMC1/8K181FTP (180)
R76 7030016020 S.RES RMC1/16S-104JTH (100 k)
R78 7030015920 S.RES RMC1/16S-221JTH (220)
R79 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R80 7030016050 S.RES RMC1/16S-102JTH (1 k)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.

PARTS LIST

DESCRIPTION M.
LOCATION
B 74.0/31.2
T 84.5/22.5
T 102.0/28.0
T
T 71.0/19.5
T 67.4/20.4
T 59.5/19.4
T 25.9/24.5
T
T
B 12.1/24.1
B 12.1/27.7
T 52.4/21.0
T 51.8/17.3
T 37.5/33.2
T 37.2/45.7
T 54.0/45.5
B 70.6/33.5
B 78.3/31.5
T 34.1/49.6
B 32.3/48.3
B 98.5/36.5
B 79.1/27.9
B 79.1/25.5
T 28.1/16.9
T 25.9/20.6
B 78.4/34.3
T 77.5/35.7
T 80.2/35.7
T 89.4/44.3
T 94.0/39.1
B 92.7/41.9
T 16.5/13.1
T
T 35.5/33.7
T 33.0/42.9
T 41.4/42.3
T 43.2/50.4
T 63.5/41.0
T 70.0/42.7
T 69.6/48.6
T 86.4/41.4
T 81.3/41.3
T 99.5/44.3
T 90.1/40.1
B 97.6/44.3
B 101.8/37.8
B 99.1/41.8
T 90.3/36.8
B 94.4/31.8
B 96.5/31.6
T 89.7/25.6
T
T 94.5/15.4
T 106.5/32.0
T 86.2/17.0
T 104.6/22.7
T 53.7/19.0
T 52.0/19.0
T 42.5/32.7
T 38.1/31.4
T 40.4/31.4
T 38.1/30.5
T 32.9/33.7
T 41.3/34.0
T 32.0/46.0
T 32.0/48.7
T 30.7/46.5
T 32.0/49.6
B 32.0/49.8
T 47.9/50.4
T 48.2/41.0
T 46.9/39.7
T 46.0/39.7
T 77.5/41.6
T 77.5/39.9
T 83.4/37.7
T 81.7/37.7
B 83.6/37.2
T 77.7/32.8
B 76.7/33.6
B 75.8/35.3
B 75.8/33.6
[MAIN UNIT]
H/V REF PART
NO. NO.
R81 7030016110 S.RES RMC1/16S-473JTH (47 k)
R82 7030016300 S.RES RMC1/16S-332JTH (3.3 k)
R83 7030016330 S.RES RMC1/16S-153JTH (15 k)
86.3/9.3 R84 7030016020 S.RES RMC1/16S-104JTH (100 k)
R85 7030016390 S.RES RMC1/16S-184JTH (180 k)
R86 7030015970 S.RES RMC1/16S-103JTH (10 k)
R91 7030016000 S.RES RMC1/16S-823JTH (82 k)
R99 7030016430 S.RES RMC1/16S-392JTH (3.9 k)
R100 7030015910 S.RES RMC1/16S-101JTH (100)
10.1/6.4 R101 7030016150 S.RES RMC1/16S-100JTH (10)
16.0/8.1 R102 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R103 7030016480 S.RES RMC1/16S-821JTH (820)
R104 7030016170 S.RES RMC1/16S-560JTH (56)
R105 7030016470 S.RES RMC1/16S-390JTH (39)
R106 7030015900 S.RES RMC1/16S-470JTH (47)
R107 7030016210 S.RES RMC1/16S-121JTH (120)
R108 7030016210 S.RES RMC1/16S-121JTH (120)
R109 7030016560 S.RES RMC1/16SJPTH
R110 7030016560 S.RES RMC1/16SJPTH
R111 7030015900 S.RES RMC1/16S-470JTH (47)
R112 7030015900 S.RES RMC1/16S-470JTH (47)
R211 7030015930 S.RES RMC1/16S-471JTH (470)
R212 7030016150 S.RES RMC1/16S-100JTH (10)
R213 7030015930 S.RES RMC1/16S-471JTH (470)
R214 7030015910 S.RES RMC1/16S-101JTH (100)
R220 7410001570 S.ARR MNR02M0APJ101 (100)
R221 7410001570 S.ARR MNR02M0APJ101 (100)
R223 7410001570 S.ARR MNR02M0APJ101 (100)
R224 7030016050 S.RES RMC1/16S-102JTH (1 k)
R231 7030016150 S.RES RMC1/16S-100JTH (10)
R232 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R233 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R239 7030016560 S.RES RMC1/16SJPTH
R240 7030016560 S.RES RMC1/16SJPTH
R241 7030015970 S.RES RMC1/16S-103JTH (10 k)
R242 7030015910 S.RES RMC1/16S-101JTH (100)
R322 7030015910 S.RES RMC1/16S-101JTH (100)
R323 7410001570 S.ARR MNR02M0APJ101 (100)
R324 7030016050 S.RES RMC1/16S-102JTH (1 k)
R326 7030016410 S.RES RMC1/16S-561JTH (560)
R331 7030016410 S.RES RMC1/16S-561JTH (560)
R333 7030016060 S.RES RMC1/16S-105JTH (1 M)
83.4/6.6 R334 7030015910 S.RES RMC1/16S-101JTH (100)
R341 7510001661 S.THR NTCG16 4LH 473JT
R342 7030019760 S.RES RMC1/16K223FTP (22 k)
R343 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R344 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R501 7030015980 S.RES RMC1/16S-333JTH (33 k)
R502 7030016090 S.RES RMC1/16S-223JTH (22 k)
R503 7030016090 S.RES RMC1/16S-223JTH (22 k)
R504 7030015970 S.RES RMC1/16S-103JTH (10 k)
R511 7030016440 S.RES RMC1/16S-272JTH (2.7K)
R512 7030016060 S.RES RMC1/16S-105JTH (1 M)
R513 7030016060 S.RES RMC1/16S-105JTH (1 M)
R515 7030016020 S.RES RMC1/16S-104JTH (100 k)
R523 7030016060 S.RES RMC1/16S-105JTH (1 M)
R524 7030016060 S.RES RMC1/16S-105JTH (1 M)
R527 7030015980 S.RES RMC1/16S-333JTH (33 k)
R528 7030016050 S.RES RMC1/16S-102JTH (1 k)
R551 7030016150 S.RES RMC1/16S-100JTH (10)
R552 7030016150 S.RES RMC1/16S-100JTH (10)
R553 7030016110 S.RES RMC1/16S-473JTH (47 k)
R554 7030016640 S.RES RMC1/16S-1R0JTH (1)
R555 7030016020 S.RES RMC1/16S-104JTH (100 k)
81.9/9.6 R561 7030019410 S.RES RMC1/8-471JTP (470)
R562 7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R563 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R601 7030016560 S.RES RMC1/16SJPTH
R602 7030016110 S.RES RMC1/16S-473JTH (47 k)
R603 7030016110 S.RES RMC1/16S-473JTH (47 k)
R611 7030016330 S.RES RMC1/16S-153JTH (15 k)
R613 7030016330 S.RES RMC1/16S-153JTH (15 k)
R731 7030016240 S.RES RMC1/16S-684JTH (680K)
R732 7030016090 S.RES RMC1/16S-223JTH (22 k)
R733 7030015980 S.RES RMC1/16S-333JTH (33 k)
R735 7030016090 S.RES RMC1/16S-223JTH (22 k)
R736 7030016090 S.RES RMC1/16S-223JTH (22 k)
R737 7030016340 S.RES RMC1/16S-393JTH (39K)
R738 7030015970 S.RES RMC1/16S-103JTH (10 k)
R740 7030016040 S.RES RMC1/16S-224JTH (220 k)
R744 7030016070 S.RES RMC1/16S-474JTH (470 k)
R745 7030016560 S.RES RMC1/16SJPTH
R746 7030016090 S.RES RMC1/16S-223JTH (22 k)
R750 7030016470 S.RES RMC1/16S-390JTH (39)
R751 7030015920 S.RES RMC1/16S-221JTH (220)
R752 7030017480 S.RES RMC1/16-2R2JTP (2.2)
R753 7030016640 S.RES RMC1/16S-1R0JTH (1)
R801 7030016640 S.RES RMC1/16S-1R0JTH (1)
C11 4030023090 S.CER 0402B102K500CT
C12 4030023090 S.CER 0402B102K500CT
C13 4550007260 S.TAN F931C475MAABMA
C21 4030022540 S.CER 0402N3R0B500CT
C24 4030022570 S.CER 0402N6R0C500CT
C25 4030023090 S.CER 0402B102K500CT
C27 4030022740 S.CER 0402N220J500CT
C28 4030022630 S.CER 0402N100C500CT
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-1
DESCRIPTION M.
LOCATION
B 75.8/31.9
B 73.7/28.3
B 72.6/33.1
B 72.6/34.0
B 72.2/31.7
B 76.7/31.9
T 101.4/53.7
B 88.5/35.7
B 86.4/35.2
B 95.5/35.6
B 95.5/37.8
B 97.8/39.8
B 104.7/37.3
B 99.1/40.2
B 95.8/32.7
B 96.3/33.9
B 95.3/33.9
B 96.0/43.4
B 96.9/41.6
B 95.9/30.5
B 97.6/30.5
B 88.5/29.1
B 87.2/28.7
B 87.6/27.3
B 82.6/25.9
T 79.3/25.1
T 79.3/20.4
T 81.7/17.4
T 85.8/18.1
T 55.8/19.0
T 55.8/19.9
T 55.8/18.1
T 63.2/16.7
T 64.7/18.0
T 62.8/19.7
T 63.7/19.7
T 96.3/30.3
T 99.8/22.9
T 104.0/23.8
T 105.7/21.6
T 87.3/15.9
T
T
T 74.0/17.6
T 72.9/14.8
B 80.0/15.8
B 80.0/14.9
T 65.6/19.7
T 65.6/21.4
T 68.5/24.2
T 65.9/18.4
B 26.8/12.2
T 73.0/24.2
T 73.4/25.5
T 74.0/20.2
T 70.3/24.2
T 69.4/24.2
T 71.7/25.5
T 71.7/26.4
B 21.2/23.7
B 20.3/23.7
T 10.3/11.2
T
T
B 20.4/17.6
T
T
T 23.2/25.5
T 26.5/17.1
T 26.9/18.4
T 29.7/23.8
T 31.4/23.8
B
B
B
B 14.5/25.0
B 11.4/25.9
B 13.1/25.9
B 11.8/29.5
B 14.5/26.9
B 10.1/27.4
B 14.5/30.6
B 15.4/30.6
T
T 10.0/35.6
T 18.8/34.0
B 21.3/43.2
T
T 53.7/18.1
T 52.9/23.0
T 50.1/20.5
T 43.1/31.4
T 40.8/32.7
T 36.0/35.0
T 34.2/33.3
T 31.6/33.2
H/V
88.1/9.5
86.4/6.9
13.4/4.3
13.4/6.0
17.3/2.6
14.6/2.6
7.5/23.7
8.0/25.9
8.4/23.7
6.8/37.1
24.9/2.1
