The actual configuration of the PC board can be seen by viewing the top and bottom BOARD LAYOUT pages together.
• MIC-JACK UNIT (B-8868C: TOP VIEW)
J2
B8868C
• GPS-ANT UNIT (B-8258 for only IC-M220G: TOP VIEW)
EP2
L1
C1
W1
B8258
See the PARTS LIST H/V location on the PARTS LIST for location details.
7-5
