■ JIG CABLE
Cut the cable and make the proper connections,
according to the diagram.
OPC-2132
■ ADJUST UTILITY
TX OUTPUT POWER
DEVIATION (DSC)
MODULATION
SENSITIVITY
SQUELCH
AUDIO GENERATOR
(300~3000 Hz/1~500 mV)
Red
(PTT)
White
(MIC)
(GMD)
(CLONE)
Blue
Brown
4-2
AC MILLIVOLTMETER
(10 mV to 10 V)
+ −
PTT
3-conductor 3.5 (d) mm jack
+ −
