2 Schematic Checklist
• R - These pins have analog functions.
• USB - GPIO18 and GPIO19 are USB pins. The pull-up value of a USB pin is controlled by the pin's pull-up
value together with USB pull-up value. If any of the two pull-up values is 1, the pin's pull-up resistor will be
enabled. The pull-up resistors of USB pins are controlled by USB_SERIAL_JTAG_DP_PULLUP bit (1 by
default).
• G - These pins have glitches during power-up. See details in Table 5.
Espressif Systems
Table 5: PowerUp Glitches on Pins
Pin
Glitch
MTCK
Low-level glitch
MTDO
Low-level glitch
GPIO10
Low-level glitch
U0RXD
Low-level glitch
GPIO18
Pull-up glitch
Submit Documentation Feedback
Typical Time Period
(ns)
50000
15
ESP32-C3 Family Hardware Design Guidelines V0.5
5
5
5
5
