Summary of Contents for Eiki EK-850LU

  • Page 1 Owner's manual Multimedia Projector EK-850LU EK-1100LU V1.0...
  • Page 2: Features And Design

    Features and Design This Projector is designed with the most advanced technology for durability and ease of use. This projector utilizes built-in multimedia features, a palette of 1.07 billion colors and matrix liquid crystal display (LCD) technology. Simple Computer System Setting Security Function The projector has the Multi-scan system to The Security function helps you to ensure secu-...
  • Page 3: Table Of Contents

    Table of contents Features and Design ......Setting Table of contents Direct Power On ........52 ........3 Safety operation guideline Standby mode..........52 .....4 Compliance High land function ........52 ..........20 Accessories Cooling fast setting ........52 ..........21 Keylock function.........53 Overview Laser control ..........53 Name and function of your projector Remote control code setting ......53 Front/top ............23...
  • Page 4: Safety Operation Guideline

    Safety operation guideline Safety instructions This document and your projector employ certain symbols to illustrate how to use your projector safely. They are described below: Please get yourself familiar with them before going through this document. Ignoring messages indicated by this symbol may lead to personal injuries Caution or deaths due to human errors.
  • Page 5 Safety operation guideline Warning: DONOT leave the projector in the rain or expose it to moisture environment to prevent fire or electric shock. The proposed plug should not be used in an extension cord outlet or other outlet unless the pin is fully plugged in.
  • Page 6 Safety operation guideline Disposing of your used product In the European Union EU-wide legislation as implemented in each Member State requires that used electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste. This includes projectors and their electrical accessories.
  • Page 7 Safety operation guideline Caution Precautions on air outlet / air intake: ● Keep adequate clearance around your projector for its ventilation and cooling. See figure below for the least clearance requirements. The least clearance is a MUST when your projector is placed within a cabinet or other closed environment. ≥50cm ≥50cm ≥...
  • Page 8 Safety operation guideline Note: Precautions on using your projector: ● DO NOT project the same image for long time as residual images may be left in the panel. This is a property of LCD panel. ● Use power as indicated in tags attached to your projector. If you have doubts over avail- able power type, consult your dealer or local power company first.
  • Page 9 ● Regarding the installation and management of the equipment, please comply with the relevant laws and regulations of your country. ● Outline of laser emitted from the built-in light module: Wavelength: 455 nm Maximum power: 257W(EK-1100LU);229W(EK-850LU) ● Radiation pattern from the protective housing:: Wavelength: 455 nm Maximum laser output: : 333mW ●...
  • Page 10 This projector must be installed at a height that will prevent your eyes from being exposed within the RG3 zone. The equipment administrator (operator) must control the entry of viewers into the RG3 zone. EK-1100LU EK-850LU Radiation zone(m) Radiation zone(m) Lens...
  • Page 11 Safety operation guideline When mounting the projector on the ceiling to project an image downward RG3 zone Vertical security zone: over 3 m * If the distance between the floor face and the RG3 zone is less than 3m, entering the screen area should be restricted.
  • Page 12 Safety operation guideline Laser radiation range The figure below shows the maximum range of laser radiation.() Horizontal Angle (Unit: degree) Lens position Center Right Left Lens unit Zoom (Reference most most value) Tele AH-EC21020 Right Wide 27.9 20.7 27.9 Tele 31.7 23.8 31.7...
  • Page 13 Safety operation guideline Safety Labels For class 3R laser products conforming to IEC60825-1, 2nd edition and for class 1 laser products conforming to IEC60825-1, 3rd edition, notice and instruction labels shall be pasted in the following position Label 2 Label 3 Label 1 Label 1 Label 4...
  • Page 14 Safety operation guideline Note: Please heed all precaution for safety To install the projector ● This projector is an RG3 product. The projector is for professional use and must be installed in location where safety is assured. For this reason, be sure to consult your dealer as installation and attachment/detachment of the lens unit must be performed by a professional service personnel.
  • Page 15 Safety operation guideline Air ventilation Openings in the casing are designed for ventilation and overheating prevention. DO NOT block or cover these openings to keep your projector in normal operation and from overheating. Note: Heat exhaust at the air outlet Keep the following in mind when using or installing your projector: •...
  • Page 16 Safety operation guideline Protective cover For the safety reason, while installation as following position, please add the optional protective cover to avoid the damage caused by the falling parts throw the intake or exhaust vent. Application scenarios A position: B position: Air intake Vent face Air exhaust Vent face down.
  • Page 17 Safety operation guideline Installation of the Protective Cover: 1) Align the protective cover with the projector 2) Loosen 2 screws (M3*110) from the protective cover and tighten to the corresponding holes at the projector. Please refer to the following figure for details: Protective Cover A Snap fit Screw...
  • Page 18 Safety operation guideline Note: Precautions on ceiling mount bracket installation: M4x8 ● Get qualified technician to install the ceiling mount bracket. ● Warranty of your projector does not cover hazards and damage caused by using ceiling mount brackets provided by unauthorized dealers.
  • Page 19 Safety operation guideline Precautions on dealing with your projector: DO NOT lift or move your projector by holding the lens as it may damage the lens and your projec- tor. Be careful when handling your projector. DO NOT drop it, subject it to external forces, or place ob- jects atop it.
  • Page 20: Compliance

    Model Number : EK-850LU, EK-1100LU Trade Name : EIKI Responsible party : EIKI International, Inc.
  • Page 21: Accessories

    Accessories HDMI2 HDMI2 INPUT INPUT Remote Control with batteries LENS SHIFT LENS SHIFT Quick Start Guide AC Power Cord VGA Cable HDMI2 FREEZE FREEZE (AA or LR6) KEYSTONE KEYSTONE INPUT INFO. INFO. HDMI2 INPUT LENS SHIFT HDMI2 FREEZE HDMI2 KEYSTONE INPUT INFO.
  • Page 22: Overview

    Overview This chapter presents names and functions of individual component.
  • Page 23: Name And Function Of Your Projector

    Name and function of your projector Front/top        Air intake  Projection lens  Air outlet  POWER indicator  – Steady red as standby mode – Steady green while normal operation – Flash green with Power management - Ready mode STATUS indicator ...
  • Page 24: Rear

    Name and function of your projector Rear      Air Intake  MENU: Air Outlet  Open or close the OSD menu Control Panel  Lens Adjustment: ON/STAND-BY: – Adjust the optical zoom level Power on or off your projector –...
  • Page 25: Terminal

    Name and function of your projector Terminal 12 13 VGA IN Kensington Security Slot This slot is for a Kensington lock used to Connect output signal from computer to this deter theft of the projector. terminal. * Kensington is a registered trademark of USB-B IN ACCO Brands Corporation The terminal is to use the USB display function,...
  • Page 26: Remote Controller

    Name and function of your projector Remote controller Select VGA input source ① ② USB-B Select USB-B input source for USB Display HDBaseT ③ Select HDBaseT input source HDMI2 ④ ⑧ ⑤ ⑨ NETWORK ⑥ ⑩ Select LAN input source for Network Display INPUT ⑦...
  • Page 27: Remote Controller Operation Range

    Name and function of your projector ZOOM Enter the zooming mode ① ② SCREEN Select screen size ③ KEYSTONE HDMI2 ④ ⑧ Keystone calibration ⑤ ⑨ D.ZOOM+ ⑥ ⑩ INPUT ⑦ Digital zoom in projected image ⑪ D.ZOOM- ⑮ ⑫ Digital zoom out projected image Wired remote controller output terminal ⑯...
  • Page 28: Install Battery Of Remote Controller

    Name and function of your projector Install battery of remote controller Open the battery cover. Insert a new battery in it. Two AA (LR6) batteries Place your batteries with its anode and cathode (+ and -) in correct direction. Keep both poles in good connection to the contacts within the compartment.
  • Page 29: Installation

    Installation This chapter introduces the information of install.
  • Page 30: Lens Installation

    Installation Lens installation Please follow steps given below to install lens after its replacement or when optional ones are employed. Please consult your dealers for details on optional lenses. Installing lens Remove the lens 1 Centering the lens by select the "Lens 1 Remove the Dust Proof Cover as the first cernter"...
  • Page 31: Lens Shift Adjustment

    Installation Lens shift adjustment The electric lens shift function may adjust your lens in all four directions. This function enables easy image position adjustment. The projection location of your image may be Move lens to it top moved upward a distance up to 50% of the position length of the image.
  • Page 32: Set Up Your Projector

    Installation Set up your projector ● Ambient brightness may affect your projection image quality. For the optimal image effect, it is recommended to control brightness in your environment. ● Values shown in figure below are approximates only. They may differ from the actual ones. 300"...
  • Page 33: Adjustment Pad

    Installation Adjustment pad You may use the adjustment leg to raise your projector up to 10 mm. Turn the pad to tilt your projector to required height. To raise your projector, turn both pads clockwise. To lower down your projector or close the pad, turn both pads counterclockwise. You may use the auto setup function to adjust your projector’s keystone distortion automatically or do this with the remote controller or OSD menu manually.
  • Page 34: Connect The Ac Power Cord

    Installation Connect the AC power cord Standard voltage employed by your projector is AC 100-240V. It adapts to different input voltage automatically. Your projector employs 2-phase power cord with neutral ground cable. Do not use any other type of power cords or you may face the risks of electric shock. In case you have any doubt on type of power cord you are using, please call authorized dealer or service cen- ter for help.
  • Page 35: Connection To Equipment

    Connection to equipment Connection to computer Cables used for connection: ● VGA cable ● USB cable* ● DVI cable* ● HDMI cable* ● USB device* ● Serial cable* (*Cables are not supplied with the projector) HDMI output / onput output input / output USB-A RS232...
  • Page 36: Connection To Video And Audio Equipment

    Connection to equipment Connection to video and audio equipment Cables used for connection: ● SDI cable* ● RJ45 cable* ● DVI cable* ● Audio cable* ● HDMI cable* (*Cables are not supplied with the projector) HDMI output output output HDBaseT AUDIO output input / output...
  • Page 37: Operation

    Operation This chapter introduces you to basic operation of your projector.
  • Page 38: Basic Operation

    Basic operation Power on your projector 1. Connect all external equipment to your projec- tor (e.g. computer or camera) before powering it on. 2. Connect AC power cord of your projector to an AC power socket. The Power indicator turns on in red. 3.
  • Page 39: Power Off Your Projector

    Basic operation Power off your projector 1. Press the Power button at the control panel or the remote controller, then “Power off?” message displays. 2. Press the Power button again within 4 seconds after the “Power off?” message Power off ? prompted to you.
  • Page 40: Focus Function

    Basic operation Focus function 1. Press the Lens Adjustment button on the control panel once or "FOCUS" but- ton on the remote controller to adjust the projection image with Focus function. HDMI2 Lens adjust- 2. Press button to adjust the focus for ment INPUT center area of the image .
  • Page 41: Keystone Adjustment

    INPUT Basic operation Keystone adjustment You may adjust keystone distortion of image with the keystone adjustment. Follow steps below to adjust keystone distortion of pro- jected image manually. LENS SHIFT Press the KEYSTONE button on your remote controller. FREEZE The Keystone selection menu show up, press button KEYSTONE KEYSTONE...
  • Page 42: How To Use The Osd

    Basic operation How to use the OSD Main menu Sub menu Display Auto PC adj. Fine sync H Position V Position H. Size Aspect Normal Project way Front Menu position Center Background display Blue System 1024 x 768, 60Hz Menu operation 1.
  • Page 43: Menu Item Overview

    Basic operation Menu item overview Main menu Sub menu Display ① Auto PC adj. Fine sync ② H Position V Position ③ H. Size Aspect Normal ④ Project way Front Menu position Center ⑤ Background display Blue System 1024 x 768, 60Hz ⑥...
  • Page 44: Remote Controller Operation

    Basic operation Remote controller operation Use your remote controller for common operations. HDMI2 Auto setup function (AUTO) INPUT Press the AUTO button to auto execute the settings set in the Auto Setup menu (including Auto Searching and Auto PC Adjusting) Auto Blank Image mode selection (IMAGE)
  • Page 45: Input Selection

    Input selection Input select Remote control Direct Operation Press HDMI 1, VGA, USB-B, HDMI 2, DVI, HDMI 2 HDBASET, NETWORK or USB-A on the remote control as input source. HDMI2 HDBASET HDMI 1 Menu operation NETWORK 1 Press INPUT button on the remote control or INPUT USB-A USB-B...
  • Page 46: Display

    OSD Setting-Display Auto PC Adjusting The Auto PC Adjusting function may get Total Dots, Horizontal and Vertical position, Display area H, HDMI2 and Display area V aligned with computer input. INPUT Direct Operation Press Auto button on the remote control to launch the Auto PC Adj.
  • Page 47: Manual Computer Adjustment

    OSD Setting-Display Manual PC signal format adjustment The scan system of your projector may fail to detect signal format used by certain computers as they opted some special signal format. The manual computer adjustment function of your projector enables you to adjust individual parameter to align with most special signal format. 1 Press MENU button on the remote controller or control panel and the OSD displays.
  • Page 48 OSD setting-Display Project way Project way menu Press button to select the project way. Display Front ..Projects to front screen when projector is Auto PC adj. front standing. Fine sync Rear ..Projects to rear screen when projector is H Position front standing.
  • Page 49 OSD setting-Display System The projector automatically tunes to various types of computers with its function of Multi-scan system and Auto PC Adjustment. If a computer is selected as a signal source, the projector automatically de- tects the signal format and tunes to project proper images without any additional setting. One of the following messages may appear when input source as computer: When the projector cannot recognize the connected signal conforming to the Auto...
  • Page 50: Color Adjust

    OSD setting-Color Adjust(Computer signals) Color Adjust Menu operation 1 Press the MENU button on remote controller and the OSD displays. Press button select Color Adjust icon, press button or OK button to confirm your selection. 2 Press button to point to required item and press OK button to confirm your selection. Image mode Switch image mode to fit the image source and Color adjust...
  • Page 51: Color Adjust (Video Signals)

    OSD setting-Color Adjust(Video signals) Color Adjust Menu operation 1 Press the MENU button on remote controller and the OSD displays. Press button select Color Adjust icon , press button or OK button to confirm your selection. 2 Press button to point to required item and press OK button to confirm your selection. Image mode Switch image mode to fit the image source and the Color adjust...
  • Page 52: Setting

    OSD setting-Setting Setting Your projector comes with convenient adjustment function. 1 Press the MENU button on remote controller and the OSD displays. Press button to select Setting icon, press button or OK button to confirm your selection. 2 Press button to point to required item and press OK button to confirm your selection. Direct power on Setting Setting the projector to be turned on automatically...
  • Page 53: Keylock Function

    OSD setting-Setting Keylock Set the security for the projector operation. Setting Direct power on Standby mode O ff... The control panel and remote controller High land are effective. Cooling fast 0 sec Key lock Contrast optimization P rojector... Lock the operation of the control Laser control panel.
  • Page 54: Expand

    OSD setting-Expand Expand Select the Expend menu to set up other functions of your projector. 1. Press the MENU button on remote controller and the OSD displays. Press button to select Expand icon, press button or OK button to enter the submenu. 2.
  • Page 55: Keystone

    OSD setting-Expand Keystone Keystone menu This function is used to correct the distortion image. Expend Keystone Keystone Sets whether or not to keep the keystone Keystone Store correction after turn off the projector or plug out H/V Keystone the power cord. 4-Corner correction 6-Corner correction Store ..
  • Page 56: Curved Correction

    OSD setting-Expand Curved correction Adjust when the linearity is not uniform or the vertical and horizontal lines are distorted. Press▲▼◄►to adjust the item. Items Operation Adjustment Press Adjust the right & left of the◄ & ► the width button Curved correction - X/Y Gain Press Adjust the top &...
  • Page 57: Logo

    OSD setting-Expand Logo This function allows you to customize the screen logo with Logo select, Capture, Logo PIN code lock and Logo PIN code change functions. Logo Select This function decides on the starting-up display Logo from following options. Default . Show the factory-set logo. Expend User ..
  • Page 58: Security

    OSD setting-Expand Security Security This function allows you to use the PIN code lock and PIN code change functions to set the Expend security for the projector operation. Language Auto setup PIN code lock Keystone This function prevents the projector from being Logo operated by unauthorized persons and provides Security...
  • Page 59: Power Management

    OSD setting-Expand Power management Power management For reducing power consumption as well as maintaining the lamp life, the Power management Expend function turns off the projection lamp when the Language projector is not operated for a certain period. Select Auto setup one of the following options: Keystone Logo...
  • Page 60: Network

    OSD setting-Expand Network Function : PC controls projector via LAN. Preparation: 1. Equipments: PC, projector, cables 2. Connection procedures: Connect the projector to routers or switches of the LAN by direct or cross cable. If it fails to connect PC and projector by parallel cable, please switch to cross cable as suggested. 3.
  • Page 61: Memory Viewer

    OSD setting-Memory Viewer Memory Viewer The Memory Viewer function allow to project the pictures which are stored in the USB memory Device. This function only available when the USB memory device inserted into the projector. 1 Press MENU button on the remote control to display screen menu. 2 Press ...
  • Page 62: Info

    OSD setting-Info. Information The information menu is used to the detect signal of projected image and running state. Menu operation info. menu Press MENU button on the remote control or control panel to display the screen menu. Press  to select Info., the information menu Info.
  • Page 63: Description On Using Useful Function

    Description on using useful function...
  • Page 64: Network Control Operation

    Description on network control operation LAN control Function : PC controls projector via LAN. Preparation: 1. Equipments: PC, projector, cables 2. Connection procedures: Connect the projector to routers or switches of the LAN by direct or cross cable. If it fails to connect PC and projector by parallel cable, please switch to cross cable as suggested.
  • Page 65 Description on network control operation 4. Activate the Web browser in the personal computer. 5. Enter the IP address + /html (i.e. "192.168.1.100/html") set by the projector into the URL input field of the Web browser. (When entering the IP address only, Web browser will open Crestron Roomview page.) 6.
  • Page 66 Description on network control operation "System Status" page Display the status of the projector for the following items. ① ② ③ ① Model Name ③ LAN Status Displays the model No. of the projector. Displays the connection status of the LAN. ②...
  • Page 67 Description on network control operation ① Brightness ④ Color Adjusts the brightness of the projected image. Adjusts the color saturation of the projected image. ② Contrast Adjusts the contrast of the projected image. ⑤ Tint Adjusts the skin tone of the projected image. ③...
  • Page 68 Description on network control operation "Network Setup" page ① ② ① LAN Setup Gateway Select [Obtain an IP address automatically] Enter the default gateway address when if you want to enable the DHCP client. not using a DHCP server. IP Address Enter the IP address when not using a DHCP Enter the DNS server when not using a server.
  • Page 69: Network Display Function

    Description on network display operation Network Display function 1. PwPresenter software: when "Network" is selected in Source Select, you can project the current computer images via network. Input the IP address of the projector in webpage to enter the Network Display System, click "Download"...
  • Page 70 Description on network display operation Play/Pause ② Play or pause the selected image. ③ Choose capture mode Choose a capture mode from "Full Screen", "Fixed Size" or "Alterable." ④ Parameters Setting Basic Setting Setting language, region of capture image etc. Advanced Setting Setting image quality, network port etc.
  • Page 71 Description on network display operation Multicast Setting Setting Sound volume, Bandwidth and Capture rate etc. ⑤ Network Display Management Setting device and password management. ⑥ Disconnect the projector.
  • Page 72: Memory Viewer Function

    Description on using Memory Viewer function Memory Viewer function The Memory Viewer function is used to project the pictures which are stored in the USB memory when the USB memory is inserted into USB A(VIEWER) terminal of the projector. Memory Viewer function supports the following image files. Extension Format Description...
  • Page 73 Description on using Memory Viewer function Play the PDF Playing the PDF file. press ▲▼◄► to select a PDF file and press the OK button, playing the PDF on the full screen. Displays the previous or next page. The page number increases or decreases by 5 pages. The page number increases or decreases by 1 page.
  • Page 74: Usb Display Function

    Description on using USB display function USB Display function The USB Display function is used to project the image from the computer which is connected to USB-B (DISPLAY) terminal of the projector by a USB converting cable. ■ When using Windows Windows operation environment Windows XP, Windows7 32/64 bit, Windows8.1 32/64 bit, Windows10 32/64 bit...
  • Page 75 Description on using USB display function ■ When using Mac OS Mac OS operating environment Mac OS X 10.5, 10.6, 10.7, 10.8, 10.10, 10.11, 10.12, 10.13 Power PC G4 1GHz or faster Amount of memory 512 MB or more Hard-disk free space 20 MB or more Display Resolution 640 x 480 to 1600 x 1200 ●...
  • Page 76: Maintenance

    Maintenance This chapter describes the regular maintenance procedure of your projector to ensure its optimal operation status for long.
  • Page 77: Regular Maintenance

    Regular maintenance Status indicator The status indicator shows status of projector protection function. Check STATUS and POWER indicator for good maintenance operation. Note: Unplug the AC power cord in case of any abnormality as it may lead to fire or electric shock.
  • Page 78: Clean The Lens

    Regular maintenance Clean your projector when it is contaminated by foreign matter or its display effects are getting worse. Note: Unplug the AC power cord before any cleaning operation. Clean the lens Wipe the lens with clean cloth dampened with non-abrasive camera lens cleaner or clean it with lens cleaning paper or air blower.
  • Page 79: Appendix

    Appendix...
  • Page 80: Troubleshooting

    Appendix Troubleshooting Check the following before calling your dealer or service center: Troubleshooting Solution Power on failure – Plug the power cord of your projector in an AC socket. – Make sure the POWER light indicator turns red. – Restart your projector until the POWER light indicator turns red. It indicates your projector is ready for power on again.
  • Page 81 Appendix Some operations are – Check the display function. invisible Auto PC Adjusting – Check input signal. Auto PC Adjusting function is disable in 480p, function failure 576p, 720p, 480i, 576i, 1080i or 1080p mode. Settings do not save after –...
  • Page 82: Light Indicator Status

    Appendix Light indicator status Check light indicator to learn status of your projector. Light indicator POWER Status of your projector STATUS TEMP Green / Red / Orange Power Off (without AC power supply). Standby status. Press the Power button to turn it on. Normal operating status.
  • Page 83: Compatible Computer Screen

    Appendix Compatible computer screen Your projector is designed to accept every analog computer signal below Dot Clock 160MHz and digital computer signal below Dot Clock 150MHz. See table below for details on resolution and relevant frequency. Signal Frequency Signal Frequency Input Resolution Input...
  • Page 84: Terminal Configuration

    Appendix Terminal configuration VGA IN / VGA OUT Terminal (D-sub 15) Red (Input/output) ----- Green(Input/output) Grounding (field synchronizing) Blue(Input/output) Grounding ----- DDC data Grounding Horizontal synchronizing (line synchronizing) (compound sync.)input/output Vertical synchronizing input/ Grounding(red) output Grounding(green) DDC Clock Grounding(blue) SERIAL Terminal(D-SUB 9) ----- ----- -----...
  • Page 85: Menu Tree

    Appendix Menu tree Default Main menu Sub-menu Setting Remarks value Auto PC adj. Fine sync 0-31 H Position -5 - +5 V Position -5 - +5 The range of H H Size -15 - +15 Size differs from signals. Normal Aspect 16:09 16:10...
  • Page 86 Appendix Default Main menu Sub-menu Setting Remarks value Direct power on On/Off Standby Mode Normal/Eco mode High land On/Off Cooling fast Normal/0 Sec/30 Sec 0 Sec Key lock Off/Projector/Remote controller Contrast On/Off Optimization Setting Boost/Normal/ Light source mode Normal Eco 1/Eco 2 Laser Control Laser Adjust 100%...
  • Page 87 Appendix Main menu Sub-menu Setting Default value Remarks Focus Zoom Lens Adjust Lens shift Lens center Lens calibration Off / Gray scale(1-4) / Color bar / Test pattern Red / Green / Blue / Cross hatch / White / Black / Raster gray Expand DHCP(On/Off) Off IP address...
  • Page 88: Technical Specifications

    HDBaseT RJ45 x1 HDMI (Video, Audio), RS-232C, 100 Base-TX (100Mbps)/10 Base-T (10Mbps) SDI x1 Power Voltage and power consumption AC 100–240 V (EK-1100LU:Max 8.5A / EK-850LU: Max 6.3A), 50/60 Hz Operating Environment Operating temperature 41˚F-104˚F (5˚C-40˚C) Storage Temperature 14˚F-140˚F (-10˚C-60˚C)
  • Page 89 Appendix Information of Optional Lens Model# AH-EC21020 AH-EC22030 AH-EC21030 AH-EC24010 AH-EC23030 Image Lens Type Standard Lens Short Lens Standard Lens Middle Lens Long Lens 2.3X 1.4X 2.0X 2.0X 1.5X Zoom Ratio Motorized zoom Motorized zoom Manual zoom Motorized zoom Manual zoom 1.7-2.0 2.0-2.5 1.7-2.37...
  • Page 90: Dimensions

    Appendix Dimensions Unit: mm Screw Holes for Ceiling Mount  Screw: M4 Depth: 8.0 M4X6...
  • Page 91: Pin Code Memorandum

    Appendix PIN code memorandum Write down the PIN code in the blank below and keep it, If you forgot or lost the number and unable to operate the projector, contact the service center. Factory default PIN code 111* PIN code lock Factory default PIN code 111* Logo PIN code Lock No.
  • Page 92 E-Mail: info@eiki.de +420 241-403-095 Fax: +420 241-409-435 E-Mail: info@eiki.cz South East Asia Oceania EIKI Industrial (M) Sdn Bhd EIKI AUSTRALIA PTY LTD No. 11, Nouvelle Industrial Park, Level 5, 11 Queens Road, Lorong Teknologi B, Taman Sains Melbourne, Victoria 3004, Australia...
