Units 1500 to 8000 Multi(-V), 1500 to 6500 MultiEco(-V), 1400 to 10100 Basic(-V): Level
o
both the longer and shorter side of the casing horizontally.
·
The unit must be secured against movement.
Hinges
Door of unit, floor-standing position
Ceiling-suspended position:
●
Slope both the longer and shorter side of the casing 3% towards the condensate drain at exhaust
air (i2).
Door
Door
Wall
Manipulation space,
floor-standing position
10
