WWC 440X

A
C
Item
1
2
3
4
5
6
7
38
Subject to change without notice | 83050700fUK – Translation into English of the original German operating manual | ait-deutschland GmbH
6
1780
1650
7
0
50
0
650
715
Designation
Heating water inlet (return); flat seat
Heating water outlet (flow): flat seat
Heat source inlet at the unit; flat seat
Heat source outlet at the unit; flat seat
Penetration for electric/sensor cables
Safety assembly (in extra box)
Control panel (in extra box)

Dimensional drawings

1520
1419
1344
700
0
Legend: UK819258b
All dimensions in mm.
A
Front view
C Top view
Rear view
E
E
5
1
2
3
4
Dim.
G 1 1/4"
G 1 1/4"
G 1 1/4"
G 1 1/4"
---
---
---
