Summary of Contents for Alpha-InnoTec WWC100HX
- Page 1 Water / Water CompaCt Heat pumps WWC H/X series WWC X series We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
-
Page 2: Please Read First
Reference to other sections of the operating manual. Reference to other documents of the manufac- turer. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 3: Table Of Contents
..............19 Testing and setting the overflow valve ......19 InSTAllInG THE conTRol pAnEl .........20 InSTAllATIon And REmovAl oF THE ScREEn ..21 We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 4: Intended Use
Important For safety reasons: never disconnect the unit from the power sup- ply, unless the unit is being opened. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 5: Customer Service
“dismantling”. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 6: Area Of Use And Heat Source Requirements
The following table helps to assess the water quality. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 7: Heat Metering
(fully opening windows for a short period, two to three times a day) reduces energy con- sumption and your heating bill. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 8: Malfunctions
In conjunction with a multi-functional and/or buffer tank with volume > 200 l, always install an additional, adequately-dimensioned expansion vessel. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 9: Installation
“Technical data / Scope of delivery” overview, “General unit data” section, CautIon! Wear safety gloves. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 10: Installation
Set the extra box to the side and lift the unit from the wooden pallet... “Transport to installation location”. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... - Page 11 Hands and fingers could be crushed during the following work! • position a Sylomer strip under the unit, flush with the respective outer edge... We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
-
Page 12: Installing The Hydraulic Connections
We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 13: Safety Assembly
>200 l, always install an additional, adequately-dimensioned expansion vessel. Straight or extended hose laying of the vibration isola- tors is not permitted. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 14: Electrical Connection Work
1 cover plate of the switchbox 2 Screw plugs 1 controller board connections 2 power and control cable connections We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... - Page 15 “Technical data / Scope of delivery” overview, “Electrics” section. Important The sensor cable for heat quantity recording may not be shortened! We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
-
Page 16: Flushing And Filling The System
- and regular servicing and maintenance are carried out. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 17: Flush And Fill The Heating Circuit And Domestic Hot Water Tank
If necessary, place a bleeder at the highest point of the heating circuit in the heating water inlet (return)… We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 18: Bleeding
CirCuit Unscrew the screw cover in the middle of the circulation pump until loose and close again after venting. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 19: Insulating The Hydraulic Connections
= increases spread. – anticlockwise = decreases spread. open valves to heating circuit. Reset the heating and heat pump controller. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 20: Installing The Control Panel
This requires a shielded network cable (category 6) to be laid through the unit during the electrical connection work. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 21: Installation And Removal Of The Screen
2 logo 3 dummy cover First, insert the masking plate below in the slots provided in the front panel… We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 22: Domestic Water Heating
There is a fee for commissioning! “Hydraulic connection” documents. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 23: Safety Temperature Limiter
The battery can be pushed out using a screwdriver. dispose of battery and electronic components in an environmentally friendly way. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 24: Technical Data / Scope Of Delivery
Incl. in scope of delivery: • yes — no UK813241-a *) comply with local regulations n.d. = not detectable We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... - Page 25 • ı • • ı • • ı • • ı • • ı • 813233-d 813234-d 813235 -d 813236-b 813237-f We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
- Page 26 Incl. in scope of delivery: • yes — no UK813241-a *) comply with local regulations n.d. = not detectable We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
-
Page 27: Wwc 280X - Wwc 440X
• ı 50l ı 1,5 • ı 80l ı 1,5 • • • ı • • ı • 813238-d 813239-d We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 28: Performance Curves
- / ÄM001-2007 / Neumann / 27.09.07 ∆p„ Heat source pressure loss Zeichnungsnummer: 823201 Compressor Datei: 823201 Leistungs-Druckverlustkurve WWC100HX.xls We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 29: Wwc 130H/X
∆p„ Heat source pressure loss - / ÄM001-2007 / Neumann / 27.09.07 Zeichnungsnummer: 823002 Compressor Datei: 823202 Leistungs-Druckverlustkurve WWC130HX.xls We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 30: Wwc 160H/X
- / ÄM001-2007 / Neumann / 27.09.07 ∆p„ Heat source pressure loss Zeichnungsnummer: 823203 Compressor Datei: 823203 Leistungs-Druckverlustkurve WWC160HX.xls We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 31: Wwc 190H/X
∆p„ Heat source pressure loss - / ÄM001-2007 / Neumann / 27.09.07 Zeichnungsnummer: 823204 Compressor Datei: 823204 Leistungs-Druckverlustkurve WWC190HX.xls We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 32: Wwc 220H/X
- / ÄM001-2007 / Neumann / 27.09.07 ∆p„ Heat source pressure loss Zeichnungsnummer: 823205 Compressor Datei: 823205 Leistungs-Druckverlustkurve WWC220HX.xls We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 33: Wwc 280X
∆p„ Heat source pressure loss - / ÄM001-2007 / Neumann / 27.09.07 Zeichnungsnummer: 823206 Compressor Datei: 823206 Leistungs-Druckverlustkurve WWC280X.xls We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 34: Wwc 440X
- / ÄM001-2007 / Neumann / 27.09.07 ∆p„ Heat source pressure loss Zeichnungsnummer: 823207 Compressor Datei: 823207 Leistungs-Druckverlustkurve WWC440X.xls We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 35: Dimensioned Drawings Wwc 100H/X - Wwc 220H/X
Heat source outlet at the unit; flat seat G 1 1/4" Penetration for electric/sensor cables Safety assembly (in extra box) Control panel (in extra box) We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 36: Installation Plan Wwc 100H/X - Wwc 220H/X
Unit installation on Sylomer strips (in extra box) ÄM 001 20 Distance to next object PEP 00 Zust. Änderu We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 37: Dimensioned Drawings Wwc 280X
Heat source outlet at the unit; flat seat G 1 1/4" Penetration for electric/sensor cables Safety assembly (in extra box) Control panel (in extra box) We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 38: Dimensioned Drawings Wwc 440X
Penetration for electric/sensor cables ÄM 0 Safety assembly (in extra box) ÄM 0 Control panel (in extra box) PEP 0 Zust. Ände We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 39: Installation Plan Wwc 280X - Wwc 440X
Unit installation on Sylomer strips (in extra box) ÄM 001 20 Distance to next object PEP 00 Zust. Änderu We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 40: Terminal Diagram
WWC 100H/X – WWC 220H/X terminal diagram C10 A 3~N/PE/400V/50Hz C10 A 3~PE/400V/50Hz C10 A 1~N/PE/230V/50Hz ZW2/SST We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 41: Wwc 280X - Wwc 440X
WWC 280X – WWC 440X 3~PE/400V/50Hz 28 KW: C16A 44 KW: C32A 44 KW: C32A 1~N/PE/230V/50Hz C10 A ZW2/SST We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 42: Circuit Diagrams
WWC 100H/X Circuit diagram 1/3 C10 A 3~N/PE/400V/50Hz C10 A 3~PE/400V/50Hz C10 A 1~N/PE/230V/50Hz ZW2/SST We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... - Page 43 Circuit diagram 2/3 WWC 100H/X 3~PE/400V/50Hz 28 KW: C16A 44 KW: C32A 44 KW: C32A 1~N/PE/230V/50Hz C10 A ZW2/SST We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
- Page 44 WWC 100H/X Circuit diagram 3/3 -R12 yellow white Green Brown We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
-
Page 45: Wwc 130H/X - 220H/X
Circuit diagram 1/3 WWC 130H/X – 220H/X /2.6 We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... - Page 46 WWC 130H/X – WWC 220H/X Circuit diagram 2/3 We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
- Page 47 Circuit diagram 3/3 WWC 130H/X – 220H/X -R12 yellow white Green Brown We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
-
Page 48: Wwc 280X
WWC 280X Circuit diagram 1/3 /2.5 We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... - Page 49 Circuit diagram 2/3 WWC 280X We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
- Page 50 WWC 280X Circuit diagram 3/3 -R12 yellow white Green Brown We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
-
Page 51: Wwc 440X
Circuit diagram 1/3 WWC 440X /2.5 We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... - Page 52 WWC 440X Circuit diagram 2/3 VD1. VD2. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
- Page 53 Circuit diagram 3/3 WWC 440X -R12 yellow white Green Brown We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH...
-
Page 54: Ec Declaration Of Conformity
Module: Notified body: TÜV-SÜD Industrie Service GmbH (Nr.:0036) company: place, date: Kasendorf, 25/08/2011 Signature: Jesper Stannow Head of development We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH... -
Page 55: General Checklist
Sending the general checklist and the completion report also serves as a request for a technician authorized by the manufacturer to commission your heat pump. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH 820522il FAZ-Wp AIT © Alpha-InnoTec GmbH... -
Page 57: Completion Report For Heat Pump Systems
It is absolutely necessary that the operator is present for the one‑time, free instruction that occurs during commissioning. A report will be prepared during commissioning. We reserve the right to modify technical specifications without prior notice. 83050700aUK – Translation of the operating manual © Alpha-InnoTec GmbH 820522il FAZ-Wp AIT © Alpha-InnoTec GmbH... -
Page 58: Customer Service
ASAp Energy Tinggaardvej 7 origen office naas Road 6400 Sønderborg muirfield drive, naas Alpha-InnoTec Schweiz AG Tel.: +45 (0) 74 4304 80 Road, Industriepark Fax: +45 (0) 74 4304 81 dublin 12 6246 Altishofen info@asap.dk Tel.: +353 (0) 141 919 19 Tel.: +41 (0) 62 74820 00... - Page 59 Fax: +386 (0) 42 555 782 Fax: +31 (0) 26 445 93 73 info@ekoenergija.eu info@nathan.nl www.ekoenergija.eu www.nathan.nl Econic ltd Alpha-InnoTec norge AS marsham Gamle Forusveien 51b norwich Road 4033 Stavanger norfolk Tel.: +47 (0) 51 6605 95 nR 10 5pq Fax: +47 (0) 51 6605 94 Tel.: +44 (0) 16 032 770 40...
