Input Connector (1) 19-pin type-A female HDMI
Output Connector (1) 19-pin type-A female HDMI, (1) RJ45
Control Connector (2) 3.5 mm mini jacks
Input Connector (1) RJ45
Output Connector (1) 19-pin type-A female HDMI
Control Connector (2) 3.5 mm mini jacks
Video Resolution Up to 4K@60Hz 4:4:4, HDR 10
HDMI Audio Format
Transmission Distance 4K/1080p ≤ 70 meters (230ft)
HDMI Version HDMI V2.0
HDCP Version
Power Supply
Power Consumption 4W (Max)
Operation Temperature -5~55°
Storage Temperature -25~70°
Relative Humidity 10%-90%
Dimensions (W*H*D) 80 mm x 16,8 mm x 80 mm
Net Weight Tx/Rx: 70g
Note: the extender set does not support HBR audio.
WWW.TECHLY.COM
SPECIFICATIONS
TRANSMITTER
Input (1) SOURCE
Output (1) DISPLAY, (1) CATx OUT
Control (1) IR IN, (1) IR OUT
RECEIVER
Input (1) CATx IN
Output (1) DISPLAY
Control (1) IR IN, (1) IR OUT
GENERAL
Supports LPCM 2ch, LPCM 5.1ch, LPCM 7.1ch,
Dolby Digital 2ch, Dolby Digital 5.1ch, DTS 2ch, DTS
5.1ch, DTS 96/24 5.1ch.
HDCP 2.2 compliant. (The HDCP of output follows
the HDCP version of display device.)
EDID Supports EDID Pass-through
Input: 100VAC~240VAC, 50/60Hz
Output: 12VDC 1A
KIT EXTENDER HDMI2.0
18G SU CAVO CAT5E/6
