Replacing the Boxer
lens circuit boards
The lens circuit board projector (LCBP) must be connected to lens circuit board lens (LCBL) for the
lens zoom motor to work.
To ensure a proper connection between the LCBP and LCBL for lens zoom functionality, Christie has
released a new service kit to replace worn or damaged parts.
Affected products
The following products are affected.
•
Boxer 4K models
•
Boxer 2K models
•
Boxer 30
•
Mirage 304K
Required components
The following components are required to complete the upgrade.
•
Boxer lens repair kit LCBL and LCBP P/N: 003-006191-01
Tools required for installation
Make sure the following tools are available during the installation:
•
Long and stubby neck magnetic-tip ball drivers—2.5 mm, 3 mm, and 5 mm provided in
projector toolbox
•
Needle nose wire cutter
•
2.5 mm hex driver
•
3 mm hex driver
Replacing the Boxer LCBP and LCBL Instruction Sheet
020-102501-01 Rev. 1 (11-2016)
Copyright
2016 Christie Digital Systems USA Inc. All rights reserved.
©
1
Advertisement
Table of Contents
Related Manuals for Christie 003-006191-01
Summary of Contents for Christie 003-006191-01
- Page 1 The lens circuit board projector (LCBP) must be connected to lens circuit board lens (LCBL) for the lens zoom motor to work. To ensure a proper connection between the LCBP and LCBL for lens zoom functionality, Christie has released a new service kit to replace worn or damaged parts.
- Page 2 • Always handle optics by their edges. • All procedures must be performed by Christie qualified technicians. • Use protective eye wear and gloves when cleaning and servicing the product. Follow workplace guidelines for using personal protective equipment when cleaning and servicing products.
- Page 3 1. If installed, remove the lens. 2. Remove the two screws securing the LCBL. Replacing the Boxer LCBP and LCBL Instruction Sheet 020-102501-01 Rev. 1 (11-2016) Copyright 2016 Christie Digital Systems USA Inc. All rights reserved. ©...
- Page 4 Europe, Middle East, and Africa: +44 (0) 1189 778111 or Support.EMEA@christiedigital.com • Asia Pacific: +65 6877-8737 or Support.APAC@christiedigital.com Replacing the Boxer LCBP and LCBL Instruction Sheet 020-102501-01 Rev. 1 (11-2016) Copyright 2016 Christie Digital Systems USA Inc. All rights reserved. ©...
