Installation and Setup Guide
020-002147-01
LED Display System
Christie CoreIII Series
Product Name
1
020-001930-01 Rev. 1 (01-2024)

Advertisement

Table of Contents
loading

Related Manuals for Christie CoreIII Series

Summary of Contents for Christie CoreIII Series

  • Page 1 Installation and Setup Guide 020-002147-01 LED Display System Christie CoreIII Series Product Name 020-001930-01 Rev. 1 (01-2024)
  • Page 2 Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties of fitness for a particular purpose. Christie will not be liable for errors contained herein or for incidental or consequential damages in connection with the performance or use of this material.

  • Page 3: Table Of Contents

    Reviewing the tile configuration ....................32 Setting the input resolution ......................33 Locking and unlocking the controller .................... 33 Velvet LED Display System Installation and Setup Guide–Christie CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.
  • Page 4 Electro-magnetic compatibility ....................41 Emissions ..........................41 Immunity ..........................41 Velvet LED Display System Installation and Setup Guide–Christie CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 5: Important Safeguards

    Product overview Christie® CoreIII have been fully upgraded on the previous basis. Featuring UHD resolution, high fill-factor, and advanced monitoring capabilities, the CoreIII is a certified LED display wall solution providing 24/7 operation for critical viewing environments. With front-access serviceability, remote, and redundant power supply and a slim ADA-compliant design, the CoreIII delivers performance possible for LED displays.

  • Page 6: Power Precautions

    • SHOCK HAZARD! Only use the AC power cord provided with the product or recommended by Christie. • TRIP OR FIRE HAZARD! Position all cables where they cannot contact hot surfaces, be pulled, be tripped over, or damaged by persons walking on or objects rolling over the cables.

  • Page 7: Product Documentation

    Indicates the ratio between the area covered by pixels and the area not covered by pixels. Product documentation For installation, setup, and user information, see the product documentation available on the Christie Digital Systems USA Inc. website. Read all instructions before using or servicing this product.

  • Page 8: Typical Led Solution

    E600/E510 LED display controller Receiving card A8s-N LED display Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 9: Cable And Controller Layout And Design

    The configuration to achieve an HD display differs by the pixel pitch of the tile, as outlined in the table below. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.

  • Page 10: E510 Controller Interface And Ports

    Operating indicator • Green: The device is running normally. • Red: The device is in standby mode. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.
  • Page 11 1600×1200@(24/30/48/50/60) Hz 1920×1080@(24/30/48/50/60) Hz 1920×1200@(24/30/48/50/60) Hz 2560×960@(24/30/48/50) Hz 2560×1600@(24/30) Hz Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 12 10 km; OS1/OS2 recommended Dual-mode twin-core fiber: Support LC optical connectors; wavelength: 850 nm; transmission distance: 300 m; OM3/OM4 recommended Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.
  • Page 13 Output port for cascading devices. Up to eight E510 units can be cascaded. Power supply 100 V–240 VAC Power switch ON/OFF Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 14: E600 Controller Interface And Ports

    Menu dial for interacting with the menu Back button for exiting from the current operation or option in the menu Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.
  • Page 15 Power Power supply port: AC 100-240V~ 50/60hz Power switch Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 16 RGB444 Y'C'BC'R444 Y'C'BC'R422 Y'C'BC'R420 12-bit RGB444 Y'C'BC'R444 Y'C'BC'R422 Y'C'BC'R420 Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 17: Fe600 Controller Extender Interface And Ports

    USB In OPT Output (Quantity 4) Fiber optic ports for connecting to the E600 controller Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 18 Power supply port: AC 100-240V~ 50/60hz Power switch Power supply port: AC 100-240V~ 50/60hz Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 19 Installing an LED array from the front Perform the following steps when you install an LED array while facing the LED modules. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.

  • Page 20: Installing The Mounting Poles

    8. Configure the E510 controller (on page 31) or configure the E600 controller (on page 35). The controller can be configured at any time. Before connecting the controller to the wall, Christie recommends updating the firmware and configuring the controller.
  • Page 21 Installation and setup For 4x4 array For 5x5 array Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 22 Installation and setup For 6x6 array For 8x8 array Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 23 1. If the tiles are being mounted on an external support structure, ensure the external support structure is anchored to the wall and/or to the floor. The design and anchoring of the LED display structure is not the responsibility of Christie Digital Systems USA Inc. Contact a Christie representative for structure design options.
  • Page 24 Fix the top poles to the support structure using screws. d. Remove the template for future use. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.

  • Page 25: Mounting The Tiles

    Warning! If not avoided, the following could result in death or serious injury. • External support for a display wall must be designed and implemented by a Christie qualified installer and must comply with local area regulations and safety standards.

  • Page 26: Connecting The Data Source Cables

    Data B Data A Data B Fart Data A Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 27: Connecting The Power Cables

    Power in Power out 2. Connect the cabinet power cable to the wall outlet. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 28: Installing The Led Modules

    Check the sticker on each LED module and install the LED module by orders. The meaning of the numbers on the sticker above is shown below. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.
  • Page 29 If the LED module does not fit back into place or there is a gap between the LED modules of two tiles, adjust the spacing between the tiles. Alignment pins Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.

  • Page 30: Powering On The Array

    After the controller is connected and powered up, the video content is available as long as the video source is connected. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.

  • Page 31: Installing The Christie Controller Software

    2. Switch to the Downloads tab and select Software Downloads. 3. Download and unzip the Christie controller Software zip file. 4. Double-click the Christie Controller Software Setup <version>.exe file and follow the on- screen instructions and install the Christie controller software.

  • Page 32: Testing The Communication Between The Controller And Tiles

    2. Select Configure Screen and select Next. 3. Switch to the Screen Connection tab. 4. Select Read from HW. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.

  • Page 33: Setting The Input Resolution

    Upgrading the firmware on the E510 controller When a new version of the software is released, the E510 controller must be upgraded. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.
  • Page 34 9. To verify the upgrade was successful, in the top left corner of the controller display verify the version number displayed is 1.0.5.9. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.

  • Page 35: Installing/Accessing The E600 Controller Software

    1. On the Christie website, navigate to the E600 product page. 2. Switch to the Downloads tab and select Software Downloads. 3. Download and unzip the Christie LED Control Unit E600 Software zip file. 4. Double-click the Christie Controller Software Setup <version>.exe file and follow the on- screen instructions and install the E600 controller software.

  • Page 36: Testing The Communication Between The Controller And Tiles

    1. Connect a USB cable between the controller and the computer running the controller software. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.

  • Page 37: Locking And Unlocking The Controller

    1. Download the firmware file to a computer connected to the controller for the upgrade or to a USB key. 2. Unzip the downloaded firmware file. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.
  • Page 38 To verify the upgrade was successful, in the top left corner of the controller display verify the version number displayed is 1.0.5.9. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved.

  • Page 39: Cleaning The Led Panels

    1. Place the one end of the removal tool against the LED module. 2. Slowly attach the other end of the removal tool to the LED module. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc.
  • Page 40 Maintaining the LED panels 3. Pull the LED modules vertically off the tile. Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 41: Safety

    • IEC 61000-4-6/EN61000-4-6 • IEC 61000-4-8/EN61000-4-8 • IEC 61000-4-11/EN61000-4-11 Velvet LED Display System Installation and Setup Guide–CoreIII Series 020-002147-01 Rev. 1 (01-2024) Copyright ©2024 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
