Brio Enterprise Quick Start Guide
1
Connect displays
With Brio powered off, connect a
touch display to Output A
(DisplayPort connector) and connect
the USB cable from the display to a blue
USB port. Optionally, connect a second
display to Output B (DisplayPort) and to a
blue USB port. Set the second display to
the right of the rst display.
A multi-touch display is required for the touch
interface, whiteboarding, and annotating.
4
Activate your Brio
Go to www.updatebrio.com
complete the activation form.
Download the current software and
documents to a USB drive. Connect the
USB drive to Brio. Connect your device to
the same network as Brio using the
information displayed on the Splash Screen
(on the Brio outputs).
Page 1
COM
OUTPUT A/B
Brio Enterprise
NETWORK 1
2
Connect to network
Connect Brio to your network
using the Network 1 connector.
Brio is DHCP enabled when shipped
and is recognized automatically by a
DHCP-enabled network.
5
Access the admin page
and Open a web browser and enter
http: //Brio IP address /admin
(password: admin). From the Software tab in
System Settings, use the Update from USB
on Brio button to update your Brio.
This may take several minutes to complete.
I N A
L INE O UT
1 3
KVM A
I N B
2 4
NETWORK 2
I NPUT A I NPUT B
KVM B
3
Finish connections
and power on Brio
• Connect the speakers to Line Out.
Optionally, audio for a DisplayPort may be
selected in System Settings.
• Optionally, connect DVI sources to Input A
and Input B. For audio, connect In A for the
DVI device connected to Input A and connect
In B for the DVI device connected to Input B.
• Plug in the power cord and press the
power button.
6
Connect devices
To connect personal devices to
Brio and start sharing content,
follow the instructions on the
Splash Screen, and then browse to the
Brio IP address or DNS name (for example
http: //10.10.30.143 or http: //Brio72) for
additional information.
The speci c method for connecting a
device to Brio depends on the operating
system for that device.
LIT GUID START Brio Enterprise 020-101703-02 Rev. 1 (7-2015)
