Assembling the Christie
One rigging frame
With the Christie One rigging frame, the projector can be secured to trusses or structures built for the
purpose of positioning the projector.
With the frame:
•
Up to three projectors can be stacked in landscape orientation.
•
A single projector can be positioned in portrait mode but no stacking is permitted.
Christie ships the frame separately from the projector.
Affected products
The Christie One rigging frame is designed for use with the following projectors.
•
HS Series projectors (D13HD-HS, D13WU-HS, D13HD2-HS, D13WU2-HS, D16HD-HS, D16WU-
HS, D20HD-HS, D20WU-HS, DWU1612-HS, DWU2022-HS)
•
H Series (D12HD-H and D12WU-H)
•
Q Series (DWU951-Q, DHD951-Q, DWX951-Q, DXG1051-Q, DWU851-Q, DHD851-Q, DWX851-
Q)
•
GS Series (DHD635-GS, DWU635-GS, DHD635-GS China, DWU635-GS China, DHD630-GS,
DWU630-GS, DHD630-GS China Black, DWU630-GS China, DHD630-GS Black, DWU630 GS
Black, DHD1075-GS, DWU1075-GS, DHD1075-GS China, DWU1075-GS China, DWU6322-GS,
DWU7062-GS, DWU1082-GS, DHD850-GS, DWU850-GS, DHD700-GS, DWU700-GS)
Required components
The following components are required.
Christie One rigging frame (P/N: 140-113106-03 or higher)
Safety warnings and guidelines
Read all safety and warning guidelines before starting this procedure.
Danger! If not avoided, the following results in death or serious injury.
•
Do not stack the device unless specified in this manual.
•
The supporting structure must safely support the combined load of the product, all attached
hardware, and components following all local safety standards and regulations.
•
Use all mounting points, including the safety point, when installing the product overhead.
Assembling the Christie One Frame Instruction Sheet
020-101901-04 Rev. 1 (03-2020)
Copyright
©
2020 Christie Digital Systems USA, Inc. All rights reserved.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Christie One
Summary of Contents for Christie One
- Page 1 Assembling the Christie One rigging frame With the Christie One rigging frame, the projector can be secured to trusses or structures built for the purpose of positioning the projector. With the frame: • Up to three projectors can be stacked in landscape orientation.
- Page 2 Optional tools • Adjustment tool provided with the Christie One rigging frame Physical specifications Learn the weight and physical dimensions of the Christie One rigging frame. • Weight: 40.37 kg (89 lbs) • Dimensions: 790 mm x 790 mm x 483 mm Assembling the Christie One Frame Instruction Sheet 020-101901-04 Rev.
- Page 3 7. Lift the projector onto the base plate through the top opening of the frame. Ensure the lens mount faces the front of the frame, as indicated below. Assembling the Christie One Frame Instruction Sheet 020-101901-04 Rev. 1 (03-2020) Copyright © 2020 Christie Digital Systems USA, Inc. All rights reserved.
- Page 4 Refer to the image below for the mounting points on the base plate for each projector series. Assembling the Christie One Frame Instruction Sheet 020-101901-04 Rev. 1 (03-2020) Copyright © 2020 Christie Digital Systems USA, Inc. All rights reserved.
- Page 5 TIP HAZARD! Stacked frames must be secured together using all locking pins. • Do not stack the device unless specified in this manual. Assembling the Christie One Frame Instruction Sheet 020-101901-04 Rev. 1 (03-2020) Copyright © 2020 Christie Digital Systems USA, Inc. All rights reserved.
- Page 6 Projectors must be installed in frames before stacking. 1. Remove the locking pins from each stacking leg. 2. With one person positioned on each side of the framed projector, lift the assembly and place it onto the bottom frame. Stacking in portrait orientation is not permitted 3.
- Page 7 If having trouble adjusting the adjustment screw, use a 4 mm hex key and place it in one of the holes on the adjustment screw, then turn in required direction. Once the image is properly adjusted, tighten the two locking rings.
