Setup #3: Dose - EXFO Novacure 2100 User Manual

5.5.3

Setup #3: Dose

Features to note When you set a dose value, the Novacure automatically calculates and sets
intensity and exposure time values that enable it to efficiently produce the desired dose. If you
modify either the register's desired intensity or if the lamp module's maximum available intensity
decreases, the Novacure automatically increases the exposure time to enable it to produce the
desired dose. Similarly, if you modify the exposure time value, the Novacure will automatically
calculate and set the necessary intensity needed to produce the desired dose. Any intensity or time
value modified by the user which does not meet the maximum and minimum allowed values will
not be accepted and must be re-entered. Note that if the mode of operation is set to "toggle" or
"Extim", the Novacure cannot regulate the dose setting. Only the intensity will be regulated. See
Sections 5.6 and 9.1 for more detail.
1. Press Dose:.
Setup Parameters for Register X.....
Intensity: Time: Dose:
2. Follow the displayed instructions.
Dose setup. Insert light guide into
receptacle on front panel..
Insert the light guide into the radiometer port as a safety precaution. Safely fixtured light guides, however, do not need
to be repositioned.
BUSY..........Reading Intensity. DO NOT
remove light guide until setup completed
Both shutters fully open, enabling the Novacure to measure the full available light output.
The Novacure's output intensity is measured at the light guide entrance, not at the light guide exit or radiometer.
3. Read and note the maximum available intensity as shown on the display and press Cont:.
Max Intensity Available: XXXXX mW/cm2
Use the first three keys
4.
mJoules/cm2.
Set Desired Dose:
+10000 +1000
If the required dose value is larger than 99,900 mJ, press Joules: and continue to step 5. Otherwise,
skip to step 6 after pressing OK:.
34 Programming the Novacure
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Dwell: MMenu:
Cont:
MMenu: Cont:
(+10000; +1000; and +100)
XXXXX mJ/cm2
+100 Joules:
to set up the desired dose in
OK:
