13.4

Power supply and battery backup

Power Supply
Input Voltage
Current
Inrush Current
Protection
Memory Retention
Battery Type
Lamp
Output Power
Line Regulation
Output Signals
Input Signals
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Proprietary, High efficiency, switch mode, constant power output
100-120VAC and 200-240VAC,
50/60 Hz, auto-range selection
3A Max
Inrush current protection less than 50A at 90°, ½ line cycle, cold start
Dual fuse system: each fuse rated at F4A 250V (Fast acting type)
EMI filtering integrated into the power supply
Power supply has integrated thermal cutoff
AC power cutoff when either the cover is removed or when the lamp
drawer is removed from the unit
Retention time for calendar and clock: 10 years
Register variables: greater than 15 years
Integrated lithium type, non replaceable
+22.0V at 4.5A typ
Lamp: nominal 100W (dependent on lamp age and long life mode
selected)
From min Vin to max Vin lamp: +/-2%
Polarized type: NPN transistor
Maximum voltage withstand capability (V
Maximum carry current: 10mA
Polarized type: photo-diode of optocoupler; cathode side accessible
through I/P pins
Bias current, per I/P: 5mA max.
Logical low time, for momentary signals: 40mS, minimum
): 30VDC
ce
Technical Specifications
93
