Exfo X-Cite XI120
Fluorescence Illumination System
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
$
995
.00
In Stock
Qty Available: 1
Used and in Excellent Condition
Open Web Page
https://www.artisantg.com/56439-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r

Advertisement

loading
Need help?

Need help?

Do you have a question about the XI120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EXFO XI120

  • Page 1 Exfo X-Cite XI120 Fluorescence Illumination System In Stock Qty Available: 1 Used and in Excellent Condition Open Web Page https://www.artisantg.com/56439-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 SERIES 120 USER’S GUIDE...
  • Page 3 EXFO Photonic Solutions Inc. Every effort has been made to insure information in this manual is accurate, however, information in this manual is subject to change without notice and does not represent a commitment on the part of the authors.
  • Page 4 Table of Contents X-Cite 120 Message Reference ..............2 Introduction ......................3 Checking the contents of the box ..............4 Front Panel ..................... 5 Rear Panel ...................... 5 Safety Precautions..................... 6 Installing the Lamp Module ................9 Inserting and Removing the Light Guide..........13 Installing the Collimating Adapter ............
  • Page 5 X-Cite 120 Message Reference Symbol Message Description XXXX H Lamp Hours Displays the accumulated hours the lamp has been on Constant bulb The lamp is on and ready for use Flashing bulb Lamp is striking or warming up (90 sec.) Constant bulb with no symbol No lamp detected or lamp is 4000+ hrs old.
  • Page 6 The X-Cite 120 joins the EXFO Life Sciences & Industrial Division family of light systems offering the same high level of innovation, quality and reliability that our commercial customers have come to expect.
  • Page 7 7. X-Cite 120 Users guide If your packaged unit is missing any of the above components, call EXFO Life Sciences & Industrial Division at (418) 683-0211 or TOLL FREE 1-800-663-3936. Any additional optional items purchased to customize the unit will also be present.
  • Page 8 Front Panel display Iris adjustment wheel (Optional) Power on/off switch Rear Panel Air vents Light guide port AC Receptacle Checking the contents of the box...
  • Page 9 Safety Precautions The X-Cite 120 is equipped with two safety sensors to protect the user from accidental UV exposure. In addition, please observe the following precautions during use. This series of cautions, warnings and dangers relate to the operation and maintenance of the X-Cite 120.
  • Page 10 Warning Should this X-Cite 120 unit be used in a manner not specified by EXFO Life Sciences & Industrial Division, the protection provided by the equipment may be impaired. Warning The method in which lamps are disposed of must comply with local rules &...
  • Page 11 Caution The lamp module’s operational life can be significantly shortened if it is handled incorrectly. Do not touch the bulb’s glass envelope or the inside surface of the reflector. Skin oils can cause the lamp module to fail prematurely. Caution Prior to opening the unit and handling the lamp module, allow the lamp module to cool down completely.
  • Page 12 Installing the Lamp Module 1. Be sure the AC power cord is disconnected from the unit. 2. Remove the screw from the lamp housing side panel and remove the panel from the unit cover. 3. Carefully remove the lamp module from its container, holding only the ceramic components.
  • Page 13 Position the lamp so that the two leading edges of the lamp ceramic mount slide into the groove of the lamp bracket. The middle of the lamp should be in position to fit into the spring clamp. Tip: Make sure that the “This side out” label is facing outwards before trying to insert the lamp This side...
  • Page 14 7. Attach the 2-pin lamp power connector to its mate on the lamp-housing wall. Tip: the 2-pin lamp power connector will only attach in the correct orientation. If you are having difficulty attaching the connector, try rotating it by 180º 8.
  • Page 15 9. Replace the lamp housing side panel and tighten the fastening screw. Note: if the lamp is not installed correctly, the constant lamp with a “no” symbol will display when power is turned on to the unit. Warning This unit is designed for bench top use only! Always ensure that the unit is operated on a hard, stable surface.
  • Page 16 4. To remove the light guide, firmly grip the strain relief near the light guide retainer and pull out firmly. Note: the X-Cite 120 is designed for use with a 3mm liquid light guide. EXFO Life Sciences & Industrial Division can not guarantee the performance of the X- Cite if using light guides other than those supplied by EXFO Life Sciences &...
  • Page 17 Installing the Collimating Adapter 1. Make sure power is off to the X-Cite 120 unit. 2. The existing lamp housing must be removed from the microscope before the collimating adapter can be mounted. Do not discard the existing mounting hardware, since it will be used to secure the collimating adapter to the microscope.
  • Page 18 Powering Up and Powering Down 1. Plug the X-Cite 120 unit into a properly grounded AC outlet. 2. Ensure that the lamp and light guide have been properly installed and that the cover is securely fastened. Warning! Turning power on to the X-Cite 120 unit without the light guide properly installed in the unit and in the microscope can increase your risk of exposure to UV light 3.
  • Page 19 Adjusting the Illumination (Optional) If your X-Cite 120 system includes the optional iris adjustment, then it is possible to manually change the amount of illumination out of the unit. Iris adjustment (optional) The iris adjustment includes 5 different illumination settings. Notch 1.
  • Page 20 Troubleshooting Service to be completed by qualified repair personnel only! If the unit fails to power up or function properly, use the following checklist to eliminate the most common causes of problems. Check that: 1. The AC power cord is securely plugged into a functional AC wall plug. 2.
  • Page 21 The lamp has been installed correctly. See section 5 – Installing the Lamp Module. It may be necessary to replace the lamp or to replace the light guide. Contact your sales representative for information on purchasing a new lamp or light guide. If the LCD display does not light: 1.
  • Page 22 Technical Specifications 12.1 Lamp module A, D: Ceramic Components. B: Reflector. C: Bulb. E: Intelli-Lamp Connector. F: Lamp Power Connector Lamp Module High Pressure 120 Watt metal halide short arc Lamp Module Life 2000 hours (typical) Warm Up 90 seconds (typical) Technical Specifications...
  • Page 23 12.2 Light guide Light Delivery Flexible liquid filled light guide 1.5m or 3m in length with a core diameter of 3mm. Custom light guides are also available. Liquid Light Guide End Fitting Liquid Light Guide Dimensions in mm Core End Fitting End Fitting Minimum Bend Radius(mm)
  • Page 24 12.3 Power Input Power Supply: High efficiency, switch mode, constant power output Input Voltage: 100-240V, 50/60Hz Current: 2.4 – 1.0A (100/ 240V) Input Surge: 50A max. (cold start) Protection: Short circuit protection Overvoltage (up to 135%, +/- 5% of nominal) EMI filtering integrated into the PFC module Lamp driver circuit has integrated thermal cutoff Fuse Rating:...
  • Page 25 12.5 Environmental Specifications: Operating Conditions Operating Temperature: 5 to 40ºC Altitude: 2000m max. Humidity: 15 to 90% RH (non-condensing) Atmospheric Pressure: 70 to 106 kPa Overvoltage Category: Pollution Degree: Transport and Storage Conditions Temperature: -10 to +70°C Relative Humidity: 10 to 95% RH (non-condensing) Atmospheric Pressure: 50 to 106 kPa Technical Specifications...
  • Page 26 Warning: Changes or modifications not expressly approved by EXFO Life Sciences & Industrial Division could void the user’s authority to operate the equipment.
  • Page 27 WEEE Directive (2002/96/EC) The symbol above indicates that this product should not be disposed of along with municipal waste, that the product should be collected separately, and that a separate collection system exists for all products that contain this symbol within member states of the European Union.
  • Page 28 13 Contact Information EXFO Life Sciences & Industrial Division Tel: (905) 821-2600 Fax: (905) 821-2055 1-800-668-8752 (USA and Canada) xcite@exfo.com www.exfo-xcite.com 13 Contact Information...
  • Page 29 13.1 Service Contacts Service information may be obtained by contacting your nearest X-Cite Service Centre: EXFO Life Sciences & Industrial Division 1-800-668-8752 (USA and Canada) 2260 Argentia Rd. Tel: (905) 821-2600 Mississauga, Ontario L5N 6H7 Fax: (905) 821-2055 CANADA techsupport.exfo.psi@exfo.com www.exfo-xcite.com...
  • Page 31 Printed in Canada 035-00199 Rev. 3...
