- Page 1 Lynx DSS L205-S1-EX Industrial Ethernet 5-port Device Server Switch...
- Page 2 6643-22801...
-
Page 3: General Information
Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 4: Safety And Regulations
Safety and Regulations Warning signs are provided to prevent personal injuries and/or damages to the product. The following levels are used: Level of warning Description Consequence Consequence personal injury material damage Indicates a potentially Possible death or Major damage to the hazardous situation major injury product... - Page 5 WARNING - PROTECTIVE FUSE It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personell. 6643-22801...
- Page 6 WARNING - POWER SUPPLY CONNECTION There are safety regulations on which power sources that shall be used in conjunction with the product. Refer to Interface Specifications. WARNING - REDUCE THE RISK OF FIRE To reduce the risk of fire, use only telecommunication line cords with a cable diameter of AWG 26 or larger.
-
Page 7: Care Recommendations
If the product is used in a manner not according to specification, the protection provided by the equipment may be impaired. If the product is not working properly, contact the place of purchase, nearest Westermo distributor office or Westermo technical support. -
Page 8: Atex Certification
ATEX certification ATEX certification number Baseefa12ATEX0119X Standards EN 60079-0, EN 60079-15 Certification code Ex nA IIC T3 Gc (-40°C ≤ Ta ≤ +70°C) ATEX code II 3G Specific Conditions of Use The equipment must be installed in an area of not more than pollution degree 2 in accordance with IEC/EN 60664-1, and in an enclosure that provides a minimum degree of protection of at least IP54 and complies with the relevant requirements of EN 60079-0 and EN 60079-15. - Page 9 ATEX-Zertifizierung ATEX-Zulassungsnummer Baseefa12ATEX0119X Standards EN 60079-0, EN 60079-15 Zertifizierungscode Ex nA IIC T3 Gc (-40 °C ≤ Ta ≤ +70 °C) ATEX-Code II 3G Spezifische Einsatzbedingungen Die Geräte müssen in einem Bereich welcher einem maximalen Verschmutzungsgrad der Stufe 2 gemäß IEC/EN 60664-1 entspricht und in einem Gehäuse, das einen Schutzgrad von mindestens IP54 bietet und die relevanten Anforderungen von N 60079-0 und EN 60079-15 erfüllt, installiert werden.
- Page 10 Certification ATEX Numéro de certification ATEX Baseefa12ATEX0119X Normes EN 60079-0, EN 60079-15 Code de certification Ex nA IIC T3 Gc (-40°C ≤ Ta ≤ +70°C) Code ATEX II 3G Conditions spéciales d'utilisation L'équipement doit être installé dans une zone où le degré de pollution ne dépasse pas le degré...
-
Page 11: Agency Approvals And Standards Compliance
Agency approvals and standards compliance Type Approval / Compliance EN 61000-6-1, Immproducty residential environments EN 61000-6-2, Immproducty industrial environments EN 61000-6-3, Emission residential environments EN 61000-6-4, Emission industrial environments EN 50121-4, Railway signalling and telecommunications apparatus IEC 62236-4, Railway signalling and telecommunications apparatus Safety UL 62368-1, Safety Communication Technology Marine... -
Page 12: Declaration Of Conformity
Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives. The full EU declaration of conformity and other detailed information is www.westermo.com/support/product-support. -
Page 13: Hardware Overview
Hardware Overview Location of interface ports and LEDs LED Indicators Power connection Position Direction* / description Output values Out / VBUS In/out / D- = 5 VDC max In/out / D+ = 400 mA max Shield RS-232 Position Signal Direction Description Input/output values No.1 Data Set Ready... -
Page 14: Interface Specifications
Interface specifications Power Operating voltage Rated: 24 to 48 VDC Operating: 19 to 60 VDC Rated current 140 mA (290 mA) @ 24 VDC (with 500 mA USB load) 70 mA (140 mA) @ 48 VDC (with 500 mA USB load) Rated frequency Inrush current, I 22.7·10... - Page 15 Connection USB receptacle connector type A Console Electrical specification LVTTL/LVCMOS-level Data rate 115.2 kbit/s Data format 8 data bits, no parity, 1 stop bit, no flow control Circuit type SELV Connection 2.5 mm jack, use only Westermo cable 1211-2027 6643-22801...
-
Page 16: Type Tests And Environmental Conditions
Type tests and environmental conditions Environmental phenomena Basic standard Description Test levels Electrostatic discharge EN 61000-4-2 Enclosure Contact: ±6 kV Air: ±8 kV Fast transients EN 61000-4-4 Power port ±2 kV Ethernet Status out/Digital in Serial ports Enclosure Surge EN 61000-4-5 Power port L-E: ±2 kV, 42 Ω, 0.5 μF, 1.2/50 μs L-L: ±2 kV, 42 Ω, 0.5 μF, 1.2/50 μs... - Page 17 Environmental Temperatures EN 60068-2-1 Operating -40 to +70°C (-40 to +158°F)* EN 60068-2-2 Storage and transport -50 to +85°C (-58 to +185°F) Humidity EN 60068-2-30 Operating 5 to 95 % relative humidity Storage and transport Altitude Operating 2 000 m/70 kPa MTBF MIL-C217F2, Ground Benign, 25°C...
-
Page 18: Connection To Console Port
The following steps needs to be taken 1. Connect the serial diagnostic cable to the console port (use only Westermo cable 1211-2027). 2. Connect cable to your computer (USB port, if drivers are needed they can be downloaded from our Web page). -
Page 19: Connector Information
Connector Information Power connection Product 4-position Direction Description Input values marking No. 1 +DC1 Input Supply voltage input DC1 = (19 - 60) VDC No. 2 +DC2 Input Supply voltage input DC2 = 290 mA @ 24 VDC No. 3 -COM Input Common... -
Page 20: Led Indicators
LED indicators Status Description Product has no power. GREEN All OK, no alarm condition. Alarm condition, or until product has started up. (Alarm conditions are configurable, see ''WeOS Management Guide''). BLINK Location indicator ("Here I am!"). Activated when connected to IPConfig Tool, or upon request from Web or CLI. - Page 21 Mounting This product should be mounted on 35 mm DIN-rail, which is horizontally mounted inside an apparatus cabinet or similar. It is recommended that the DIN-rail is connected to ground. Snap on the product to the DIN-rail according to the figure. Mounting Lynx with integrated DIN-clip: Removal This product has an integrated DIN-clip.
-
Page 22: Getting Started
This product runs Westermo Operating System (WeOS) which provides several management tools that can be used for configuration of the product. • WeConfig tool This is a custom Westermo tool used for discovery of attached Westermo products. Note! Version of WeConfig tool must be 10.4.0 or higher. • Web Configuration of the product using the web browser. -
Page 23: Referring Documents
Referring documents Type Description Document number Management Guide Westermo OS management guide 6101-3201 Factory default on L205-S1 EX It is possible to set the product to factory default settings by using two straight standard Ethernet RJ-45 cables. 1. Power off the switch and disconnect all Ethernet cables (copper and fibre). - Page 24 Dimensions Measurements are stated in millimeters. 96 ±1 52 ±1 92 ±1 6643-22801...
- Page 25 Westermo • SE-635 35 Stora Sundby, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com REV. I 6643-22801 2020-12 Westermo Network Technologies AB, Sweden...
