Page 1 48 Ft Diameter Bin — Gamma Models: 40-SERIES 2.66 IN. CORRUGATION BINS 30000 LB. PEAK LOAD ROOF Construction Manual PNEG-4048G Date: 04-29-15 PNEG-4048G...
Page 2 All information, illustrations, photos, and specifications in this manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without notice. PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 3: Table Of Contents
Contents Chapter 1 Safety Precautions ........................7 Safety Guidelines ........................7 Cautionary Symbols ........................9 Safety Decals ...........................10 Safety Sign-off Sheet.........................13 Chapter 2 General Overview ........................15 General Information........................15 Anchor Bolt Charts ........................15 Tools Required for Construction....................18 Guidelines for Proper Storage of Grain Bin Materials Prior to Construction........18 Overview for a Typical Bin Installation ..................19 Guidelines for Construction Procedures and Lifting Jack Usage............20 Guidelines for Placement of the Decal Sidewall Sheet..............21...
Page 4 Close-Punch Connection for a One-Ring Top Stiffener (10 – 14 Ga) and a Two-Ring Stiffener (15 – 16 Ga) .........................52 Two-Ring Top Stiffener (15–16 Ga) to a Two-Ring Stiffener (15–16 Ga) Connection .......52 Two-Ring Top Stiffener (8–14 Ga) to a Two-Ring Stiffener (15–16 Ga) Connection ......53 Two-Ring Top Stiffener (8–14 Ga) to a Two-Ring Stiffener (8–14 Ga) Connection......53 Close-Punch Connection for a Two-Ring Top Stiffener (16 G) to a Two-Ring Stiffener (15 –...
Page 5 Installing the Sidedraw Baffle Chute (Three Post Stiffener) ............145 Installing the Sidedraw Discharge Chute ................... 147 Installing Wind Rings ....................... 153 Assembling Weather Cover for Roller Valve ................155 GSI Group, LLC Limited Warranty ..................157 PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 6 NOTES PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 7: Chapter 1 Safety Precautions
Safety Precautions Topics Covered in this Chapter ▪ Safety Guidelines ▪ Cautionary Symbols ▪ Safety Decals ▪ Safety Sign-off Sheet Safety Guidelines Safety guidelines are general-to-specific safety rules that must be respected at all times in the grain stor- age environment. Our foremost concern is your safety and the safety of others associated with grain handling equipment.
Page 8 Chapter 1: Safety Precautions Follow Safety Instructions — Read and Understand Manual • Carefully read all safety messages in this manual and safety signs on your machine. Keep signs in good condition. Replace missing or damaged safety signs. Be sure new equipment components and repair parts include the current safety signs.
Page 9: Cautionary Symbols
Chapter 1: Safety Precautions • Wear gloves to protect your hands from sharp edges on Gloves plastic or steel parts. • Wear steel-toed boots to help protect your feet from falling Steel-Toed Boots debris. Tuck in any loose or dangling shoestrings. •...
Page 10: Safety Decals
Chapter 1: Safety Precautions Table 1-1 Description of the different cautionary symbols (cont'd.) Symbol Description This symbol indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. This symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage.
Page 11 (61 cm) porthole door cover and the roof manway cover. If a decal has been damaged or is missing in any of these locations, contact the manufacturer for a free replacement decal. GSI Decals 1004 E. Illinois Street Assumption, IL 62510 Phone: 1–217–226–4421...
Page 12 (61 cm) porthole door cover and the roof manway cover. If a decal has been damaged or is missing in any of these locations, contact the manufacturer for a free replacement decal. GSI Decals 1004 E. Illinois Street Assumption, IL 62510 Phone: 1–217–226–4421...
Page 13: Safety Sign-Off Sheet
Chapter 1: Safety Precautions Safety Sign-off Sheet Sign-off sheet verifying that all personnel have read and understood the safety instructions. As a requirement of O.S.H.A., it is necessary for the employer to train the employee in the safe operating and safety procedures for this equipment. This sign-off sheet is provided for your convenience and per- sonal record keeping.
Page 14 NOTES PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 15: Chapter 2 General Overview
These include, but may not be limited to: • A stiffener and sidewall gauge layout chart. If such a chart is not included with this manual, contact GSI. • Roof instructions must be followed. Roof instructions are included in this manual.
Page 16 Chapter 2: General Overview Figure 2-1 Anchor bolt chords for 48 ft. diameter 2–post bin Radius Location of Bolt (B) Anchor Bolt Quantity ft and in 24 – 3-1/4 7.398 Length Length Chord (A) Chord (A) ft and in ft and in 4 –...
Page 17 Chapter 2: General Overview Figure 2-2 Anchor bolt chords for 48 diameter 3–post bin Radius Location of Bolt (B) Anchor Bolt Quantity ft and in 24 – 3-1/4 7.398 Length Length Chord (A) Chord (A) ft and in ft and in 3 –...
Page 18: Tools Required For Construction
Chapter 2: General Overview Tools Required for Construction General tools needed to perform this construction: • Combination wrench set 7/16 in. to 1 in. • Alignment punches 12 in. long • 1/2 in. Drive socket set and ratchet • Nail aprons or tool pouches to hold supplies •...
Page 19: Overview For A Typical Bin Installation
Chapter 2: General Overview Overview for a Typical Bin Installation These are the typical steps one would perform when constructing a grain bin. Procedures may vary depending on the different site requirements. Pre-Assembly Activities • Sorting and grouping parts • Assemble A-frames •...
Page 20: Guidelines For Construction Procedures And Lifting Jack Usage
12.At the completion of the tank, set stiffeners over the anchor bolts and measure the tank to ensure it is in a round condition. Consult with GSI for questions on tolerances. NOTE: For 2 ring doors or vehicle traffic doors, special placement issues may apply. Consult the special instructions provided with two ring doors or vehicle traffic doors for these options.
Page 21: Guidelines For Placement Of The Decal Sidewall Sheet
Chapter 2: General Overview Guidelines for Placement of the Decal Sidewall Sheet Use the following as a general guideline for the proper placement of the decal sheet. NOTE: Refer to the stiffener to sidewall attachment detail and specific gauge sheet for the bin. The decal sheets are located in the third ring from the top.
Page 22 Chapter 2: General Overview All information, illustrations, photos, and specifications in this manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without notice. PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 23: Chapter 3 Hardware Requirements
Hardware Requirements Topics Covered in this Chapter ▪ Bolt and Nut Pairings ▪ Hardware for 2–Post Sidewall Sheets on Bins 18 to 60 Ft in Diameter ▪ Hardware for 3–Post Sidewall Sheets on bins that are 18 to 90 Ft in Diameter and 105 Ft Bins that are 27 Rings and Shorter ▪...
Page 24: Hardware For 2-Post Sidewall Sheets On Bins 18 To 60 Ft In Diameter
Chapter 3: Hardware Requirements Hardware for 2–Post Sidewall Sheets on Bins 18 to 60 Ft in Diameter Reference the chart for hardware requirements for 2–post sidewall sheet connections on bins 18 to 60 ft. in diameter. Table 3-1 Hardware for 2–Post Sidewall Sheets on Bins 18 to 60 ft in Diameter Horizontal Seam Vertical Seam Bolt Stiffener to Sidewall...
Page 25: Bolt Torque Specifications
Chapter 3: Hardware Requirements Table 3-2 Hardware for 3-Post Sidewall Sheets on 18 to 90 ft. bins and 105 ft Diameter Bins that are 27 Rings and shorter (cont'd.) Horizontal Seam Vertical Seam Bolt Stiffener to Sidewall Overlap Seam Bolt Gauge Bolt Size (Quantity) Size (Quantity)
Page 26: Identifying Bolt Grades
Grade 2 bolts are designated with a plain head and are not used in GSI grain bins. Grade 5 Bolts Grade 5 bolts are designated by three slash marks on the head and are not used in GSI grain bins.
Page 27: Color Chart For Bin Hardware Bucket Lids
Chapter 3: Hardware Requirements Color Chart for Bin Hardware Bucket Lids For ease of identification, hardware is separated and identified by buckets with color coded lids. Use the following chart to help identify the correct hardware. JS Part YDP Part Bucket Description Color...
Page 28: Bolt Identification
Chapter 3: Hardware Requirements Bolt Identification Use the following information to identify the bolts and where each must be used during installation. Bolt S-10260 An S–10260 is a 5/16 x 1 in. JS bolt that is pre-assembled with a sealing washer. Bolt (S-10260) is used in the following locations: •...
Page 29: Bolt S-7487
Chapter 3: Hardware Requirements Bolt S-7487 An S–7487 is a 3/8 x 1 in. JS bolt that is pre-assembled with a sealing washer. Bolt (S-7487) is used in the following locations: • Use in all sidewall connections for 20 gauge through 10 gauge sidewall to sidewall sheets.
Page 30: Bolt S-10250
Chapter 3: Hardware Requirements Bolt S-10250 An S–10250 is a 7/16 x 1-1/4 in. JS bolt. Bolt (S-10250) is used in the following locations: • Use in bins 36 to 60 ft in diameter. • Use in eave bracket to inside stiffener connection. •...
Page 31: Chapter 4 Assembling Sidewall Sheets
Assembling Sidewall Sheets Topics Covered in this Chapter ▪ Color Codes for Sidewall Gauge Identification ▪ Orientation Detail for Top Sidewall Sheets ▪ Caulking Detail for Standard (Non-Laminated) Sheets ▪ Caulking Detail for Laminated Quad Pattern Sheets Color Codes for Sidewall Gauge Identification Use this chart to interpret the color code painted on the corners of the sidewall sheets.
Page 32: Orientation Detail For Top Sidewall Sheets
Chapter 4: Assembling Sidewall Sheets Orientation Detail for Top Sidewall Sheets To avoid the misalignment of the holes, it is necessary to use the correct orientation of the sidewall sheet during installation. NOTE: Always assemble the top sidewall sheets with the orientation shown. Figure 4-1 2–Post top sidewall sheet orientation Top of the top sidewall sheet Bottom of the top sidewall sheet...
Page 33: Caulking Detail For Standard (Non-Laminated) Sheets
Chapter 4: Assembling Sidewall Sheets Caulking Detail for Standard (Non-Laminated) Sheets To keep out moisture from overlapping the sheets, apply caulk to each sidewall sheet prior to installion. NOTE: Always assemble the sidewall sheets with the overlap in the same direction. •...
Page 34 Chapter 4: Assembling Sidewall Sheets 10 in. (25.4 cm) Strip of caulk 10 in. (25.4 cm) Strip of caulk • Use the supplied tube caulk to fill the larger gaps that occur with heavier gauges and laminated gauges. See Caulking Detail for Laminated Quad Pattern Sheets, page 35 for details about caulk laminated sidewall sheets.
Page 35: Caulking Detail For Laminated Quad Pattern Sheets
Chapter 4: Assembling Sidewall Sheets Caulking Detail for Laminated Quad Pattern Sheets To keep out moisture from overlapping the sheets, it is necessary to apply caulk to each sheet prior to installing. Caulking and Assembling the Individual Sidewall Sheets Each sidewall sheet must be layered and caulked prior to assembling sidewall sheet seams together. Figure 4-4 Laminated quad punched sidewall panel view from outside of the bin Strip of caulking 12 in.
Page 36 Chapter 4: Assembling Sidewall Sheets • When assembling two assembled laminated sheets to each other, apply a strip of caulk (A) near the outside edge of the outer sheet, between the outer two (2) rows of bolts and outside the last row of bolts.
Page 37: Chapter 5 Base Angle Installation
Base Angle Installation Topics Covered in this Chapter ▪ Installing the Base Angle ▪ Anchor Bolt Detail ▪ Installing the Base Angle Shims ▪ Anchor Bolt Washer Installation Installing the Base Angle Installing the base angle ring will help reinforce and seal the final ring. What You Should Know The base angle overlap should be offset two holes from the stiffener.
Page 38 Chapter 5: Base Angle Installation Figure 5-1 Exploded view of base angle (view from the inside of the bin) Final ring assembly 3/8 in. nut (S-9426) Base angle (B-7025) Base angle offset example 3/8 x 1 in. bolt (S-7487) Optional mastic sealer (or equivalent) PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 39: Anchor Bolt Detail
Chapter 5: Base Angle Installation Anchor Bolt Detail The following is the minimum requirement for anchoring a standard bin. Refer to sidedraw instructions for special anchoring details. • 5/8 in. diameter anchor bolt (A) is the minimum allowed, 3/4 in. diameter anchor bolt (A) is the mini- mum with side draw flume system.
Page 40: Installing The Base Angle Shims
Chapter 5: Base Angle Installation Installing the Base Angle Shims A section of the base boot plate will rest on top of the base angle, therefore causing the base boot to rest unevenly on the foundation. To offset this, base angle shims are required to ensure the base boot sets evenly on the foundation.
Page 41: Anchor Bolt Washer Installation
Chapter 5: Base Angle Installation Anchor Bolt Washer Installation Anchor bolt washers help to cover the oversized hole in the base plate. Before You Begin Anchor bolts are secured, and base plates installed. 1. Place a square plate washer (B) onto the anchor bolt (A). NOTE: A square plate washer (provided) must be installed between the base boot (C) and washer (D).
Page 42 NOTES PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 43: Chapter 6 Stiffeners
Stiffeners Topics Covered in this Chapter ▪ Stiffener Part Number Description ▪ Color Codes for Stiffener Gauge Identification ▪ Standard Stiffeners ▪ Top Stiffeners ▪ Stiffeners Splice ▪ Base Stiffeners ▪ Base Boots ▪ Close-Punch Connection for a One-Ring Top Stiffener (15 – 16 Ga) and a Two-Ring Stiffener (15 –...
Page 44 Chapter 6: Stiffeners ▪ Close-Punch Two-Ring Stiffener (2 – 6 Ga) to a Laminated Stiffener (2 Ga) with an Insert (10–12 Ga) ▪ Close-Punch Laminated Stiffeners (2 Ga) with Inserts (10 – 12 Ga) ▪ Close-Punch Laminated Stiffener (2 Ga) with an Insert (10 – 12 Ga) to a Laminated Base Stiffener (2 Ga) with a Base Insert (10 –...
Page 45: Stiffener Part Number Description
Chapter 6: Stiffeners Stiffener Part Number Description Part numbers are printed on the end of each stiffener with the last two numbers designating the gauge of the material. Example: CTS-216514 will be printed on a 14 gauge, standard two-ring stiffener. If the stiffener was 8 gauge, it would change the part number to CTS-216508.
Page 46: Standard Stiffeners
Chapter 6: Stiffeners Standard Stiffeners Use the following information to determine the differences between the types of standard two-ring stiffeners. Figure 6-1 Standard stiffeners Call Out Part Number Description Length Available Gauges CTS-2165XX Two-ring stiffener 63.969 in. (162.5 cm) 8 – 14 CTS-2161XX Two-ring stiffener 63.969 in.
Page 47: Top Stiffeners
Chapter 6: Stiffeners Top Stiffeners Use the following information to determine the differences between the types of top stiffeners. Figure 6-2 Images of the top stiffeners Call Part Number Description Length Available Gauges CTS-2069XX Inside stiffener (for roof) 23.938 in. (61 cm) 2 –...
Page 48: Stiffeners Splice
Chapter 6: Stiffeners Stiffeners Splice Use the following information to determine the gauge of the stiffener splice needed to connect the stiffeners. Figure 6-3 Stiffener splice Call Out Part Number Description Length Available Gauges CTS–2177XX Stiffener long 15.906 in. (40.4 splice CTS–2164XX Stiffener splice...
Page 49: Base Stiffeners
Chapter 6: Stiffeners Base Stiffeners Use the following information to determine the differences between the base stiffeners. Figure 6-4 Images of the base stiffeners Call Out Part Number Description Length Available Gauges CTS–2189XX Base stiffener 72.110 in. (183 cm) 2 – 6 CTS-2207XX Base stiffener 72.110 in.
Page 50: Base Boots
Chapter 6: Stiffeners Base Boots Use the following information to determine the differences between the base boots. Figure 6-5 Images of the base boots Part Number Description Height Call Out Base Plate Size CTS–2121XX Base boot weldment for 16 11.391 in. 6 x 9 x 3/8 in.
Page 51: Close-Punch Connection For A One-Ring Top Stiffener (15 - 16 Ga) And A Two-Ring Stiffener (15 - 16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a One-Ring Top Stiffener (15 – 16 Ga) and a Two-Ring Stiffener (15 – 16 Ga) Reference the following information for a close-punch connection of a one-ring top stiffener (CTS- 2185XX) to a two-ring stiffener (CTS-2163XX). Figure 6-6 One-Ring Top Stiffener (15 –...
Page 52: Close-Punch Connection For A One-Ring Top Stiffener (10 - 14 Ga) And A Two-Ring Stiffener (15 - 16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a One-Ring Top Stiffener (10 – 14 Ga) and a Two-Ring Stiffener (15 – 16 Ga) Reference the following information for a close-punch connection of a one-ring top stiffener (CTS- 2202XX) to a two-ring stiffener (CTS-2161XX). Figure 6-8 One-Ring Top Stiffener (10 –...
Page 53: Two-Ring Top Stiffener (8-14 Ga) To A Two-Ring Stiffener (15-16 Ga) Connection
Chapter 6: Stiffeners Two-Ring Top Stiffener (8–14 Ga) to a Two-Ring Stiffener (15–16 Ga) Connection Reference the following information when connecting a two-ring top stiffener (CTS-2169XX) to a two-ring stiffener (CTS-2161XX). Figure 6-10 Two-Ring Top Stiffener (8–14 Ga) to a Two-Ring Stiffener (15–16 Ga) Connection Two-ring top stiffener (CTS-2193XX) Two-ring stiffener (CTS-2161XX) Splice (CTS-2164XX)
Page 54: Close-Punch Connection For A Two-Ring Top Stiffener (16 G) To A Two-Ring Stiffener (15 - 16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Top Stiffener (16 G) to a Two-Ring Stiffener (15 – 16 Ga) Reference the following information for a close-punch connection of a two-ring top stiffener (CTS- 2182XX) to a two-ring stiffener (CTS-2163XX). Figure 6-12 Two-Ring Top Stiffener (16 G) to a Two-Ring Stiffener (15 –...
Page 55: Close-Punch Connection For A Two-Ring Stiffener (15 - 16 Ga) To A Two-Ring Stiffener (15 - 16 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (15 – 16 Ga) to a Two-Ring Stiffener (15 – 16 Ga) Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2163XX) to a two-ring stiffener (CTS-2163XX). Figure 6-14 Two-Ring Stiffener (16 Ga) to a Two-Ring Stiffener (16 Ga) Close-Punch Connection Two-ring stiffener (CTS-2163XX) Two-ring stiffener (CTS-2163XX) Splice (CTS-2164XX)
Page 56: Close-Punch Connection For A Two-Ring Stiffener (8-14 Ga) To A Two-Ring Stiffener (8-14 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (8–14 Ga) to a Two-Ring Stiffener (8–14 Ga) Reference the following information for a close-punch connection of a two-ring stiffener (CTS-2166XX) to a two-ring stiffener (CTS-2166XX). Figure 6-16 Two-Ring Stiffener (8–14 Ga) to a Two-Ring Stiffener (8–14 Ga) Close-Punch Connection Two-ring stiffener (CTS-2166XX) Two-ring stiffener (CTS-2166XX) Splice (CTS-2164XX)
Page 57: Two-Ring Stiffener (8 - 14 Ga) To A Close-Punch Base Stiffener (8 Ga) Connection
Chapter 6: Stiffeners Two-Ring Stiffener (8 – 14 Ga) to a Close-Punch Base Stiffener (8 Ga) Connection Reference the following information when connecting a two-ring stiffener (CTS-2165XX) to a close-punch two-ring stiffener (CTS-2207XX). Figure 6-18 Two-Ring Stiffener (8 – 14 Ga) to a Close-Punch Two-Ring Stiffener (8 Ga) Connection Two-ring stiffener (CTS-2165XX) Close-punch two-ring stiffener (CTS-2207XX) Splice (CTS-2164XX)
Page 58: Two-Ring Stiffener (8 - 14 Ga) To A Close-Punch Base Stiffener (2 - 6 Ga) Connection
Chapter 6: Stiffeners Two-Ring Stiffener (8 – 14 Ga) to a Close-Punch Base Stiffener (2 – 6 Ga) Connection Reference the following information when connecting a two-ring stiffener (CTS-2165XX) to a close-punch two-ring stiffener (CTS-2189XX). Figure 6-20 Two-Ring Stiffener (8 – 14 Ga) to a Close-Punch Two-Ring Stiffener (2 – 6 Ga) Connection Two-ring stiffener (CTS-2165XX) Close-punch two-ring stiffener (CTS-2189XX) Splice (CTS-2177XX)
Page 59: Close-Punch Connection For A Two-Ring Stiffener (8 - 14 Ga) To A Base Stiffener (8 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (8 – 14 Ga) to a Base Stiffener (8 Ga) Reference the following information when connecting a two-ring stiffener (CTS-2166XX) to a base stiff- ener (CTS-2207XX). Figure 6-22 Two-Ring Stiffener (8–14 Ga) to a Two-Ring Base Stiffener (8 Ga) Close-Punch Connection Close-punch two-ring stiffener (CTS-2166XX) Close-punch base stiffener (CTS-2207XX) Splice (CTS-2164XX)
Page 60: Close-Punch Connection For A Two-Ring Stiffener (2 - 6 Ga) To A Base Stiffener (2 - 6 Ga)
Chapter 6: Stiffeners Close-Punch Connection for a Two-Ring Stiffener (2 – 6 Ga) to a Base Stiffener (2 – 6 Ga) Reference the following information when connecting a two-ring stiffener (CTS-2162XX) to a base stiff- ener (CTS-2189XX). Figure 6-24 Two-Ring Stiffener (2 – 6 Ga) to a Two-Ring Base Stiffener (2 – 6 Ga) Close-Punch Connection Close-punch two-ring stiffener (CTS-2162XX) Close-punch base stiffener (CTS-2189XX) Splice (CTS-2177XX)
Page 61: Two-Ring Stiffener (8 - 14 Ga) To A Base Stiffener (10 - 14Ga) Connection
Chapter 6: Stiffeners Two-Ring Stiffener (8 – 14 Ga) to a Base Stiffener (10 – 14Ga) Connection Reference the following information when connecting a two-ring stiffener (CTS-2165XX) to a base stiff- ener (CTS-2200XX). Figure 6-26 Two-Ring Stiffener (8–14 Ga) to a Base Stiffener (10–14 Ga) Connection Two-ring stiffener (CTS-2165XX) Base stiffener (CTS-2200XX) Splice (CTS-2164XX)
Page 62: Two-Ring Stiffener (15-16 Ga) To A Base Stiffener (10 - 14 Ga) Connection
Chapter 6: Stiffeners Two-Ring Stiffener (15–16 Ga) to a Base Stiffener (10 – 14 Ga) Connection Reference the following information when connecting a two-ring stiffener (CTS-2161XX) to a base stiff- ener (CTS-2200XX). Figure 6-28 Two-Ring Stiffener (15–16 Ga) to a Base Stiffener (10 – 14 Ga) Connection Two-ring stiffener (CTS-2161XX) Base stiffener (CTS-2200XX) Splice (CTS-2164XX)
Page 63: Close-Punch Two-Ring Stiffener (8 - 14 Ga) To A Laminated Stiffener (2 Ga) With An Insert (10 - 12 Ga)
Chapter 6: Stiffeners Close-Punch Two-Ring Stiffener (8 – 14 Ga) to a Laminated Stiffener (2 Ga) with an Insert (10 – 12 Ga) Reference the following information for a close-punch connection with a two-ring stiffener (CTS-2166XX) to a laminated stiffener (CTS-2210XX) and insert (CTS-2211XX). Figure 6-30 Close-Punch Two-Ring Stiffener to a Laminated Stiffener with an Insert Close-punch two-ring stiffener (CTS-2166XX) Close-punch laminated stiffener (CTS-2210XX)
Page 64: Close-Punch Laminated Stiffeners (2 Ga) With Inserts (10 - 12 Ga)
Chapter 6: Stiffeners Close-Punch Laminated Stiffeners (2 Ga) with Inserts (10 – 12 Ga) Reference the following information for a close-punch connection of a laminated stiffener (CTS-2228XX) to a laminated stiffener (CTS-2229XX). Figure 6-32 Close-Punch Laminated Stiffeners with Inserts Close-punch laminated stiffener (CTS-2228XX) Close-punch insert (CTS-2229XX) 3/8 x 1 Bolt (S-7485)
Page 65: Base Stiffener (10-14 Ga) To A Base Boot Connection
Chapter 6: Stiffeners Base Stiffener (10–14 Ga) to a Base Boot Connection Reference the following information when connecting a base stiffener (CTS-2200XX) to a base boot (CTS-2121XX). Figure 6-34 Base Stiffener (10–14 Ga) to a Base Boot Connection Base stiffener (CTS-2200XX) Base boot (CTS-2121XX) 3/8 x 1 Bolt (S-7485) 3/8 Nut (S-9426)
Page 66: Close-Punch Connection For A Base Stiffener (8 Ga) To A Base Boot
Chapter 6: Stiffeners Close-Punch Connection for a Base Stiffener (8 Ga) to a Base Boot Reference the following information for a close-punch connection for a base stiffener (CTS-2207XX) to a base boot (CTS-2110XX). Figure 6-36 Base Stiffener (8 Ga) to a Base Boot Close-Punch Connection Close-punch base stiffener (CTS-2207XX) Close-punch base Boot (CTS-2110XX) 3/8 x 1 Bolt (S-7485)
Page 67: Close-Punch Connection For A Base Stiffener (6 Ga) To A Base Boot
Chapter 6: Stiffeners Close-Punch Connection for a Base Stiffener (6 Ga) to a Base Boot Reference the following information for a close-punch connection for a base stiffener (CTS-2219XX) to a base boot (CTS-2131XX). Figure 6-38 Base Stiffener (8 Ga) to a Base Boot Close-Punch Connection Close-punch base stiffener (CTS-2219XX) Close-punch base Boot (CTS-2131XX) 3/8 x 1 Bolt (S-7485)
Page 68: Close-Punch Laminated Base Stiffener (2 Ga) With Insert (10 - 12 Ga) To A Base Boot
Chapter 6: Stiffeners Close-Punch Laminated Base Stiffener (2 Ga) with Insert (10 – 12 Ga) to a Base Boot Reference the following information when connecting a close-punch laminated base stiffener (CTS- 2210XX) with insert (10 – 12 Ga) to a base boot (CTS-2109XX or CTS-2110XX). Figure 6-40 Close-Punch Laminated Base Stiffener to a Base Boot Close-punch laminated base stiffener (CTS- 2210XX)
Page 69: Close-Punch Standard Stiffener To A 12-Bolt Pattern Laminated Stiffener With Insert
Chapter 6: Stiffeners Close-Punch Standard Stiffener to a 12–Bolt Pattern Laminated Stiffener with Insert Reference the following information for a close-punch connection of a standard stiffener (CTS-2166) to a 12–bolt pattern laminated stiffener (CTS-2183XX) with insert (CTS-2184XX). Figure 6-41 Close-Punch Standard Stiffener to a 12–Bolt Pattern Laminated Stiffener with Insert Close punch standard stiffener (CTS-2166XX) Close-punch laminated stiffener (CTS-2183XX) Close-punch insert (CTS-2184XX)
Page 70: 12-Bolt Pattern Close-Punch Laminated Stiffeners With Insert
Chapter 6: Stiffeners 12–Bolt Pattern Close-Punch Laminated Stiffeners with Insert Reference the following information for a close-punch connection of two 12–bolt pattern laminated stiff- eners (CTS-2183XX) with an inserts (CTS-2184XX). Figure 6-43 Close-Punch 12–Bolt Pattern Laminated Stiffeners with Insert Close-punch laminated stiffener (CTS-2183XX) Close-punch Insert (CTS-2184XX) 3/8 x 1 Bolt (S-7485) 3/8 Nut (S-9426)
Page 71: Close-Punch 12-Bolt Pattern Laminated Stiffener To Laminated Base Stiffener With An Inserts To A Base Boot
Chapter 6: Stiffeners Close-Punch 12–Bolt Pattern Laminated Stiffener to Laminated Base Stiffener with an Inserts to a Base Boot Reference the following information for a close-punch connection of a 12–bolt pattern laminated stiffener (CTS-2183) to a laminated base stiffener (CTS-2196XX) with a inserts (CTS-2184XX and CTS-2196XX) to a base boot (CTS-2131XX).
Page 72: Close-Punch 12-Bolt Pattern Laminated Stiffener To Laminated Base Stiffener With An Inserts To A Base Boot
Chapter 6: Stiffeners Close-Punch 12–Bolt Pattern Laminated Stiffener to Laminated Base Stiffener with an Inserts to a Base Boot Reference the following information for a close-punch connection of a 12–bolt pattern laminated stiffener (CTS-2183) to a laminated base stiffener (CTS-2194XX) with a inserts (CTS-2184XX and CTS-2195XX) to a base boot (CTS-2109XX or CTS-2110XX).
Page 73: Chapter 7 Roof Assembly
Roof Assembly Topics Covered in this Chapter ▪ Attaching the Inside Stiffener to the Top Outside Stiffener ▪ Attaching the Eave Bracket to the Inside Stiffener ▪ Attaching the Eave Angle to the Sidewall Sheet ▪ Connecting the Tension Member to the Eave Bracket ▪...
Page 74: Attaching The Inside Stiffener To The Top Outside Stiffener
Chapter 7: Roof Assembly Attaching the Inside Stiffener to the Top Outside Stiffener The inside stiffener supports the eave bracket. It is installed to the inside perimeter of the sidewall sheet at the same time as the top outside stiffener. The inside stiffeners are only located at the eave bracket locations in the sidewall sheet.
Page 75 Chapter 7: Roof Assembly Figure 7-2 Inside stiffener to the two-ring top stiffener for bins with an even number of rings Sidewall Corrugation spacer (S-7041) 3/8 x 1-1/2 in. flange bolt (S-7488) Sealing washer (S-3558) 3/8 in. flange nut (S-9426) Two-ring top stiffener (CTS-2169XX or CTS-2182XX) Inside stiffener (CTS-2069XX)
Page 76: Attaching The Eave Bracket To The Inside Stiffener
Chapter 7: Roof Assembly Attaching the Eave Bracket to the Inside Stiffener Eave brackets secure the roof rafter to the sidewall. Before You Begin Install the inside stiffeners to the sidewalls before proceeding. 1. Attach the eave bracket (A) to the inside stiffener (C) and install flange bolts (D). 2.
Page 77: Attaching The Eave Angle To The Sidewall Sheet
Chapter 7: Roof Assembly Attaching the Eave Angle to the Sidewall Sheet The eave angle secures the bottom of the roof panels to the bin eave. What You Should Know Eave angles are bolted to the inside surface of the sidewall and will overlap each section. 1.
Page 78 Chapter 7: Roof Assembly 6. Install the optional tab seal (F) to the tabs (G) of the eave angle (A). 7. Tighten all hardware to the recommended torque specification. See Bolt Torque Specifications, page Figure 7-5 Exploded view of eave angle First eave angle (CTR-0720) 5/16 in.
Page 79: Connecting The Tension Member To The Eave Bracket
Chapter 7: Roof Assembly Connecting the Tension Member to the Eave Bracket Tension members connect to the eave brackets and are installed around the inside of the bin eave. Before You Begin Ensure all eave angles, inside stiffeners and eave brackets are installed before proceeding. What You Should Know IMPORTANT: Install bolts as shown, from the backside of the eave bracket.
Page 80: Attaching The Center Collar Rafter Clips To The Rafter
Chapter 7: Roof Assembly Attaching the Center Collar Rafter Clips to the Rafter Center collar rafter clips secure the A-frame rafter sections to the center collar. What You Should Know Each assembled roof rafter receives two center collar rafter clips, identified as the left center collar rafter clip (D) and the right center collar rafter clip (E).
Page 81: Attachment Locations Of Purlins To Rafters
Chapter 7: Roof Assembly Attachment Locations of Purlins to Rafters Purlins are horizontal members between the rafters that give support to the roof structure. The length of the purlin determines its location on the A-frame assembly. The following reference depicts a completely assembled A-frame roof rafter section with diagonal bracing installed.
Page 82: Assembling Purlin Number 3
Chapter 7: Roof Assembly Assembling Purlin Number 3 Purlin number 3 is located third from the eave. Before You Begin Place two roof rafters on the ground with roof panel clip holes facing up. A-frame assemblies will have diagonal bracing installed and be placed periodically throughout the perimeter of the roof. What You Should Know The A-frame assembly consists of two roof rafters identified as the left-hand roof rafter (A) and the right- hand roof rafter (B).
Page 83 Chapter 7: Roof Assembly Figure 7-9 Assembling Purlin Number 3 Left-hand roof rafter (CTR-1447) 7/16 in. flange nut (S-10251) Right-hand roof rafter (CTR-1447) 7/16 x 1-1/4 in. flange bolt (S-10250) Purlin number 3 (CTR-1450) 7/16 in. flange nut (S-10251) Upper right purlin clip (CTR-1453) Lower left purlin clip (CTR-1214) Upper left purlin clip (CTR-1454) Lower right purlin clip (CTR-1215)
Page 84: Assembling Purlin Number 2
Chapter 7: Roof Assembly Assembling Purlin Number 2 Purlin number 2 is located second from the eave. Before You Begin Place two roof rafters on the ground with roof panel clip holes facing up. A-frame assemblies will have diagonal bracing installed and be placed periodically throughout the perimeter of the roof. What You Should Know The A-frame assembly consists of two roof rafters identified as the left-hand roof rafter (A) and the right- hand roof rafter (B).
Page 85 Chapter 7: Roof Assembly Figure 7-10 Assembling Purlin Number 2 Left-hand roof rafter (CTR-1447) 7/16 in. flange nut (S-10251) Right-hand roof rafter (CTR-1447) 7/16 x 1-1/4 in. flange bolt (S-10250) Purlin number 3 (CTR-1449) 7/16 in. flange nut (S-10251) Upper right purlin clip (CTR-1453) Lower left purlin clip (CTR-1214) Upper left purlin clip (CTR-1454) Lower right purlin clip (CTR-1215)
Page 86: Assembling Purlin Number 1
Chapter 7: Roof Assembly Assembling Purlin Number 1 Purlin number 1 is located closest to the eave. Before You Begin Place two roof rafters on the ground with roof panel clip holes facing up. A-frame assemblies will have diagonal bracing installed and be placed periodically throughout the perimeter of the roof. What You Should Know The A-frame assembly consists of two roof rafters identified as the left-hand roof rafter (A) and the right- hand roof rafter (B).
Page 87 Chapter 7: Roof Assembly Figure 7-11 Assembling Purlin Number 1 Left-hand roof rafter (CTR-1447) 7/16 in. flange nut (S-10251) Right-hand roof rafter (CTR-1447) 7/16 x 1-1/4 in. flange bolt (S-10250) Purlin number 3 (CTR-1448) 7/16 in. flange nut (S-10251) Upper right purlin clip (CTR-1453) Lower left purlin clip (CTR-1214) Upper left purlin clip (CTR-1454) Lower right purlin clip (CTR-1215)
Page 88: Assembling The Center Collar
Chapter 7: Roof Assembly Assembling the Center Collar The center collar assembles A-frame assemblies together at the top. The center collar assembly is a two piece design and will need to be spliced together with splice plates. The center collar channels and the cap plates will also be assembled to the center collar on the ground to make sure all the parts align together.
Page 89 Chapter 7: Roof Assembly 5. Locate the columns of three holes (H) that are not paired on the inside radius of the center collar (A) and install four center collar channel clips (G) opposite to each other using the flange bolts (B) and the flange nuts (C).
Page 90 Chapter 7: Roof Assembly Figure 7-14 Installing the long center collar channels to the center collar channels clips 7/16 in. x 1-1/4 in. flange bolt (S-10250) Center collar channel clip (CTR-0775) 7/16 in. flange nut (S-10251) Long center collar channel (CTR-1145) 7.
Page 91 12.Locate the holes in the cap plates and install four vendor eye bolts (O) for lifting. Eye bolts are NOT supplied by GSI. NOTE: Eyebolt will pass through multiple layers of steel: the cap plates, the long center collar chan- nels and the center collar channel spacers .
Page 92 Chapter 7: Roof Assembly 15.Loosen and remove all the bolts securing the center collar channels and the center collar channel clips. 16.Use the appropriate lifting device and qualified personnel to lift the cap plates and the center collar channels as an assembly (D) from the center collar assembly and keep it aside. 17.Remove the center collar and cap plates assembly (Q) from the center collar assembly (R) and keep it aside at a clean place.
Page 93: Center Collar Placement
Chapter 7: Roof Assembly Center Collar Placement The following figure gives the approximate height needed to install the center collar. With two sidewall rings in place, position the center collar at the height specified, measuring from the bottom of the center collar to the foundation as shown. If additional rings are required for construction pur- poses, add 32 in.
Page 94: Lifting Sequence For The A-Frame Assemblies
Chapter 7: Roof Assembly Lifting Sequence for the A-Frame Assemblies The layout of the roof structure consists of standard A-frame assemblies and A-frame assemblies with diagonal bracing that are installed in a specific sequence to evenly distribute the weight as they are being installed.
Page 95: Guidelines For Assembling And Lifting The A-Frame Rafter Sections
Chapter 7: Roof Assembly Guidelines for Assembling and Lifting the A-Frame Rafter Sections The roof is assembled in sections and referred to as A-frame rafter sections. Each A-frame rafter section is assembled on the ground and lifted into place. IMPORTANT: Do not drill additional holes in purlins. Install the flange bolts and nuts as dictated by the number of holes in the purlin.
Page 96 Chapter 7: Roof Assembly • Always ensure hardware is tightened prior to lifting. • Always practice safety when assembling rafter sections. Be aware of others around you when moving long A-frame sections. • Use evenly distributed connection points of support when lifting. •...
Page 97: Attaching The A-Frames To The Center Collar
Chapter 7: Roof Assembly Attaching the A-Frames to the Center Collar The A-frame rafters must be installed to support the center collar and main roof structure. Before You Begin The center collar should be assembled and secured to the support pole, and the A-frame rafters should be assembled.
Page 98: Attaching The A-Frame To The Eave Bracket
Chapter 7: Roof Assembly Attaching the A-Frame to the Eave Bracket Assemble the lower portion of the A-frame rafters to the sidewalls. 1. Lower the A-frame rafter assembly (A) along the side of the eave bracket (C), and align with the proper holes.
Page 99: Assembling The Roof Panel Clips
Chapter 7: Roof Assembly Assembling the Roof Panel Clips The roof panel clips are located at the top of the roof rafters nearest to the center collar rafter clips. Before You Begin The A-frame rafters should be fully assembled and installed to the center collar and the eave brackets. What You Should Know The A-frame assembly consists of two roof rafters identified as the left-hand roof rafter (A) and the right- hand roof rafter (C).
Page 100: Installing The Hole Intermediate Purlins
Chapter 7: Roof Assembly Installing the Hole Intermediate Purlins Intermediate purlins must be installed to connect each A-frame roof rafter assembly together. The inter- mediate purlins connecting each A-frame roof rafter assembly have six holes on each side to secure them with the purlin clips.
Page 101: Installation Of The Roof Panel Support Clips
Chapter 7: Roof Assembly NOTE: Purlin part numbers will vary with location. After You Finish Repeat this procedure for the remaining 6–hole intermediate purlins of the roof assembly. Installation of the Roof Panel Support Clips Roof panel support clips will support the roof panel. Before You Begin Roof panel support clips will be installed before installation of the roof panels.
Page 102 Chapter 7: Roof Assembly Figure 7-25 Installation of the roof panel support clips Purlin 2 Roof panel support clips (CTR-1458) Roof panel support clips (CTR-1459) Purlin 3 Roof panel support clips (CTR-1460) 7/16 1-1/4 in. flange bolt (S-10250) Purlin 1 7/16 in.
Page 103: Installation Locations For Temperature Cable Brackets (Optional)
GSI is not responsible for the effectiveness or performance of any tem- perature cable monitoring system or layout.
Page 104: Installing The Temperature Cable Support Brackets (Optional)
Chapter 7: Roof Assembly Installing the Temperature Cable Support Brackets (Optional) Before You Begin Determine the correct location of the temperature cable support channel with the structure of the A-frame Assembly. See Installation Locations for Temperature Cable Brackets (Optional), page 103.
Page 105 Chapter 7: Roof Assembly 4. Install a quick link (C) to each cable bracket to support the temperature cables. IMPORTANT: Do not attach weights to the temperature cables; secure the bottom of cables to the floor with light twine. No roof rafter shall support more than one cable. Figure 7-28 Supplier quick link Temperature cable hanging bracket (CRP- Supplier quick link...
Page 106: Attaching The Roof Panels
Chapter 7: Roof Assembly Attaching the Roof Panels Roof panels overlap the previous roof panel, giving protection from outside elements. Before You Begin Ensure all A-frame roof rafter assemblies are installed, and ensure all intermediate purlins are installed and properly tightened. Predetermine the manway access location. What You Should Know For adjustment purposes, roof panels will be installed to each rafter first, causing exposed gaps between each roof panel group (see figure below).
Page 107 Chapter 7: Roof Assembly Figure 7-31 Exploded views of the upper and lower portions of the roof panel Roof panel (CTR-0390) 5/16 x 1 flange bolt with sealing washer (S- 10260) Exposed gap 5/16 in. flange nut (S-3611) A-frame roof rafter assembly Roof panel holes (drilled through eave angle) 4.
Page 108 Chapter 7: Roof Assembly Figure 7-32 Installing roof panels into exposed gaps Roof panel (CTR-0390) 5/16 in. flange nut (S-3611) Exposed gap 3/8 in. x 1-1/2 in. flange bolt (S-7488) 5/16 x 1 flange bolt with sealing washer (S- 3/8 in. flange nut (S-9426) 10260) 5.
Page 109 Chapter 7: Roof Assembly Figure 7-33 Field drill holes Roof panel (CTR-0390) Roof panel support clip Roof panel holes (drilled through roof panel Roof rafter support clips) Roof panel holes (drilled through rafter) PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 110: Installing The Roof Flashing
Chapter 7: Roof Assembly Installing the Roof Flashing The roof flashing will seal the area between the center collar and the roof panels. What You Should Know Each roof flashing section overlaps and bolts together with the previously installed roof flashing section. 1.
Page 111 Chapter 7: Roof Assembly 6. Install flange bolts (B) and flange nuts (C), securing the roof flashing section (A) to the roof panel ribs. 7. Continue installing the remaining flashing until the gap between the center collar and roof panels is covered.
Page 112: Installing The Cap Plates Assembly
Chapter 7: Roof Assembly Installing the Cap Plates Assembly The following procedure is for installing the center collar channels and cap plates assembly onto the center collar in the roof. Before You Begin Determine the appropriate lifting chains and lifting device for lifting the center collar channels and cap plates assembly as a unit.
Page 113 Chapter 7: Roof Assembly Figure 7-36 Lifting the center collar channel and cap plates assembly Tube caulk (S-10319) Cap plate assembly, approximately 164.8 lb (74.75 kg) Appropriate lifting chains 7/16 x 1-1/4 in. flange bolt (S-10250) Appropriate lifting device 7/16 in. nut (S-10251) 8.
Page 114 Chapter 7: Roof Assembly Figure 7-37 Cap plate assembly installed 3/8 x 1 in. bolt with sealing washer (S- 3/8 in. nut (S-456) 7487) PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 115: Installing The Conveyor Support Brackets To The Peak Cap
Chapter 7: Roof Assembly Installing the Conveyor Support Brackets to the Peak Cap Conveyor support brackets are attached to the peak cap and allow support for a conveyor or catwalk system. 1. Place tube caulk (D) around the bolt holes located in the cap plate where the conveyor support brackets (B) will be installed.
Page 116 NOTES PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 117: Chapter 8 Accessories
Accessories Topics Covered in this Chapter ▪ Installing Roof Ladder Steps ▪ Roof Ring Placement ▪ Installing a Roof Ring ▪ Installation of Peak–To– Exhauster Ladder Kit ▪ Preparation for Roof Exhauster Installation ▪ Assembly of Roof Exhauster ▪ Installing Roof Exhauster Assembly ▪...
Page 118: Installing Roof Ladder Steps
Chapter 8: Accessories Installing Roof Ladder Steps Roof ladder steps will allow access to roof and manway access. What You Should Know Each eave-to-peak ladder step package (E) differs with the diameter of each bin. When installing the ladder steps, always start from the eave and work up toward the peak, installing the longest step first and the shortest step last.
Page 119 Chapter 8: Accessories Use the following table as a guide to the location of each ladder step (rung). Table 8-1 Ladder Rung Placement Chart Bin Diameter Location 36 ft. 42 ft. 48 ft. 54 ft. 60 ft. 66 ft. LS-260-3 ↑...
Page 120: Roof Ring Placement
Chapter 8: Accessories Roof Ring Placement The roof ring is a tubular ring bolted to the exterior of the roof. The placement location and quantity of roof ring kits vary with the size of each bin. The exhauster roof ring (A) on the 48 ft bin will be installed in the seventh roof panel rib hole from the top. The eave roof ring (B) will be installed in the last roof panel rib hole located at the eave end of the bin.
Page 121: Installing A Roof Ring
Chapter 8: Accessories Installing a Roof Ring Quantity and part numbers of roof ring kits vary with the location placement and with the size of each bin. The following procedure will be similar for each kit. What You Should Know The roof ring and threaded stud may become dislocated from each other during high winds or when the inside pressure of the bin is too great.
Page 122 Chapter 8: Accessories 6. Install the threaded stud (F) with stud nuts (G) to the end of the roof ring section (B). NOTE: Install the threaded stud (F) to the side where the next roof ring section will be installed. 7.
Page 123: Installation Of Peak-To- Exhauster Ladder Kit
Chapter 8: Accessories Installation of Peak–To– Exhauster Ladder Kit Before installing the roof exhauster, the peak-to-exhauster ladder kit may be installed onto the roof to have access to the roof exhauster. Before You Begin Determine the location of the roof exhauster. What You Should Know This procedure is to install the peak to exhauster ladder kit onto the roof .
Page 124: Preparation For Roof Exhauster Installation
Chapter 8: Accessories Table 8-2 Peak-to-Exhauster Ladder Rung Kit Bin Diameter Location 36 ft 42 ft 48 ft 54 ft 60 ft 66 ft LS-260-3 LS-260-2 LS-260-4 ↑ Bin Peak LS-260-4 LS-260-5 LS-260-3 LS-260-5 LS-260-6 LS-260-3 LS-260-4 LS-260-6 LS-260-4 LS-260-5 Bolt Hole LS-260-3 LS-260-5...
Page 125 Chapter 8: Accessories Figure 8-6 Using the roof exhauster flashing and mounting plate as a template 5/16 in. flange nut (S-3611) Roof panel Exhauster mounting plate Marked or scribed hole to be cut 5/16 x 1 in hex bolt (S-10260) Field bent inside tab on roof exhauster mounting plate Holes to be field drilled...
Page 126 Chapter 8: Accessories Figure 8-7 Using the roof exhauster flashing and mounting plate as a template Marked or scribed hole to be cut 6. After the roof panels are cut appropriately, install the roof panels onto the roof in the desired location.
Page 127: Assembly Of Roof Exhauster
Chapter 8: Accessories Assembly of Roof Exhauster Assembly of the roof exhauster is done prior to installing onto the roof. 1. Apply a strip of tube caulk (C) along the mating surface of the roof exhauster hood (B) and the exhauster mounting plate (E).
Page 128: Installing Roof Exhauster Assembly
Chapter 8: Accessories Installing Roof Exhauster Assembly The roof exhauster assembly replaces one of the roof flashing panels and allows for the roof exhauster to be installed. Before You Begin IMPORTANT: Determine the location of the roof exhauster and remove the existing roof flashing panel at this location.
Page 129 Chapter 8: Accessories Figure 8-9 Installing roof exhauster Roof exhauster flashing (CTR-0818) 5/16 flange nut (S-3611) 5/16 x 1 flange bolt, with sealing washer Sealing caulk (S-10260) 5/16 x 1 flange bolt with sealing washer (S- Sealing caulk 10260) Roof exhauster assembly 7.
Page 130 Chapter 8: Accessories Figure 8-10 Sealing caulk location Roof exhauster assembly Sealing caulk PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 131: Installing The Manway Cover
Chapter 8: Accessories Installing the Manway Cover Installation of a manway cover is necessary if a manway hole is present. Round manway cover details for bins 60 ft. and smaller. 1. Apply caulking to the underside of the moisture diverter (N), and install to the manway roof panel (L).
Page 132 Chapter 8: Accessories Figure 8-11 Manway cover Hinge base (ACD-4506) 5/16 in. nut (S-396) Hinge leaf (ACD-4505) Latch (ACD-4514) 5/16 x 1 in. hex bolt (S-10260) #10–24 lock nut (S-2010) #10–24 x 5/8 in. long bolt (S-2009) 5/16 x 1 in. hex bolt (S-10260) Handle (ACD-4513) Manway roof panel Handle gasket (CRP-5003)
Page 133: Installing The Center Collar Dome Cap (Optional)
Chapter 8: Accessories Installing the Center Collar Dome Cap (Optional) Before You Begin Before installing the dome cap make sure the center collar plates are installed on the center collar. What You Should Know Field drilling holes on the cap plates may be required to install the dome cap assembly. 1.
Page 134 Chapter 8: Accessories Figure 8-12 Center Collar Dome Cap Dome cap collar weldment (CTR-1207-BS) 5/16 in. flange nut (S-3611) 3/8 in. x 1-1/2 in. flange bolt (S-7488) Washer 3/8 in. flange nut (S-456) Cap hold down (CRP-4654) Peak cap (CRP-4602) Hold down bracket Peak cap handle (PR-331) 5/16 in.
Page 135 Chapter 8: Accessories Top view Isometric view Section through Center collar 10 in. PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 136: Ladder Section Assembly
Chapter 8: Accessories Ladder Section Assembly The inside ladder package consists of the ladder, starter brackets, standoff brackets, reinforcement straps, and ending bracket. The ladder should to be assembled before installing it to the bin structure. What You Should Know When assembling ladder sections, ensure all slip resistant ladder rungs are oriented in the same direction.
Page 137: Inside Ladder Placement
Chapter 8: Accessories Inside Ladder Placement The inside ladder provides manway access from inside the bin. What You Should Know Begin by temporarily positioning the ladder (B) directly under the manway roof panel (A) for the correct placement location. Mark or scribe this location where each side of the ladder’s vertical channels meet the sidewall.
Page 138 Chapter 8: Accessories 5. Working down from the starter brackets (C and K), and in alignment, install a ladder standoff bracket (H) at every horizontal seam or 32 in. from the previous installed bracket. Install a flange bolt (D) and a flange nut (G), securing each ladder standoff bracket (H) to the sidewall. NOTE: Installing a plumb line to the starter bracket will help keep each bracket aligned evenly.
Page 139 Chapter 8: Accessories Figure 8-15 Installing ladder brackets Ladder assembly 5/16 x 3/4 in. bolt (S-7482) Starter bracket (RH LDR-4347) Starter bracket (LH LDR-4346) See sidewall hardware chart. 3/8 in. field drilled hole location Approximately 18-3/4 in. (47.62 mm) 5/16 x 3/4 in. bolt (S-7482) 3/8 in.
Page 140: Installing Inside Ladder Bottom Bracket
Chapter 8: Accessories Installing Inside Ladder Bottom Bracket The ladder bottom bracket keeps the lower portion of the ladder secure. What You Should Know The lower portion of the ladder may need to be cut to fit properly. Field drilling will be required to complete installation.
Page 141: Guidelines For Installing A Sidedraw System
90 degrees apart. Installation of multiple systems requires approval of GSI. • Sidedraw systems are intended for use with dry, flowable grain. Sidedraws are not to be used for poorly flowing products. This is not unique to GSI bins and flume systems, but is a general rule for such systems.
Page 142 Chapter 8: Accessories Figure 8-17 Two and three post stiffener examples Typical 24-ring bin Two post stiffener Typical 29-ring bin Three post stiffener Sidewall sheet Standard height of discharge chute 16 ft. 4 in. (5 NOTE: Use the following tables as a guide or reference for the proper placement of the sidedraw system. Table 8-3 Sidewall Instructions (Two Post Stiffener) Number of Rings on the Bin Chute Location Horizontal Starting Location...
Page 143: Installing The Sidedraw Baffle Chute (Two Post Stiffener)
Chapter 8: Accessories Table 8-3 Sidewall Instructions (Two Post Stiffener) (cont'd.) Number of Rings on the Bin Chute Location Horizontal Starting Location Top bolt holes in chute to be located on 2nd corrugation of body sheet. 11, 12, 15, 17, 19, 21, and 23 Center chute over vertical seam.
Page 144 Chapter 8: Accessories Figure 8-18 First Chute Locations (Two Post Stiffener Only) and Spacing of each baffle chute Stiffener’s center line Field drilled hole location (7/16 in. diameter hole) Second ring from top of bin 3/8 x 1-1/2 in. flange bolt (S-7488) Suitable baffle chute locations 3/8 in.
Page 145: Installing The Sidedraw Baffle Chute (Three Post Stiffener)
Chapter 8: Accessories Installing the Sidedraw Baffle Chute (Three Post Stiffener) The Sidedraw baffle chute helps direct the bin contents to the discharge chute. 1. Determine the sidedraw system location, and ensure the installation of baffle chutes (C) will not interfere with stiffeners (A).
Page 146 Chapter 8: Accessories Figure 8-19 First chute locations (three post stiffener only), and spacing of each baffle chute Stiffener’s center line Field drilled hole location (7/16 in. diameter hole) Second ring from top of bin 3/8 x 1-1/2 in. flange bolt (S-7488) Suitable baffle chute locations 3/8 in.
Page 147: Installing The Sidedraw Discharge Chute
Chapter 8: Accessories Installing the Sidedraw Discharge Chute The following instructions discribe the installation of the sidedraw discharge chute. What You Should Know Field cutting is required to create the opening for the discharge chute. Cutting the opening will require two sidewall panels to be modified.
Page 148 Chapter 8: Accessories 3. Measure approximately 4 in. (16.16 cm) upward from the sidewall horizontal seam (E), and place a mark or scribe, creating a horizontal center line (G). 4. Place another mark or scribe where the vertical center line (D) and the horizontal center line (G) meet, creating the center of the discharge chute location (F).
Page 149 Chapter 8: Accessories 7. Measure approximately 8-1/2 in. (21.59 cm) on each side of the horizontal center line (G), and place a mark or scribe. 8. Using these marks, create an outline of the discharge chute hole to be cut. 9.
Page 150 Chapter 8: Accessories NOTE: To ensure proper watershed, the discharge chute assembly (H) is installed behind the upper sidewall panel (I) and in front of the lower sidewall panel (J). Figure 8-23 Discharge chute assembly (view form inside the bin) Discharge chute assembly Lower sidewall panel Upper sidewall panel...
Page 151 Chapter 8: Accessories Figure 8-24 Field drilling discharge chute assembly (view from inside the bin) Discharge chute assembly 3/8 x 1-1/2 in. flange bolt (S-7488) Upper sidewall panel 3/8 in. flange nut (S-456) Lower sidewall panel 14.Place the baffle chute (B) into place and field drill necessary holes, securing with flange bolts and flange nuts.
Page 152 Chapter 8: Accessories Figure 8-25 Reinstall baffle chute (view from inside the bin) Baffle chute Field drilled hole location 15.Tighten hardware to the recommended torque specifications. See Bolt Torque Specifications, page PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 153: Installing Wind Rings
Chapter 8: Accessories Installing Wind Rings Installation of wind rings is similar for a two and a three post bin design, although hardware quantities may vary. What You Should Know Before installing, determine the bin size, sidewall gauge thickness, and height. Use the hardware chart to match the correct bolt length with the correct sidewall gauge thickness when installing the wind ring brack- ets to the stiffeners (Refer to hardware requirements chapter).
Page 154 Chapter 8: Accessories 7. Slide the wind ring coupling collar (K), aligning the three pre-drilled holes, and install flange bolts (F) and hex nuts (G). Field drill the remaining three holes (L) using the wind ring coupling collar (K) as a guide or template.
Page 155: Assembling Weather Cover For Roller Valve
Chapter 8: Accessories Assembling Weather Cover for Roller Valve The following instructions are for assembling the weather cover for the roller valve. 1. Install the weather cover kit after the gate has been installed. 2. Use bead caulking at all seams where the weather cover attaches to the gate. 3.
Page 156 NOTES PNEG-4048G 48Ft Diameter 40-Series Bin...
Page 157: Gsi Group, Llc Limited Warranty
12 months after sale to the original end-user or if a foreign sale, 14 months from arrival at port of discharge, whichever is earlier. The end-user’s sole remedy (and GSI’s only obligation) is to repair or replace, at GSI’s option and expense, products that in GSI’s judgment, contain a material defect in materials or...
Page 158 Authorities having jurisdiction should be consulted before installations are made. 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.com GSI is a worldwide brand of AGCO Corporation. Copyright © 2015 by GSI Group Printed in the USA CN #123456...
