Figure 2-1 Location of Critical Temperature Spots (Top Side)

If you integrate the blade in your own system please contact your local sales representative
for further safety information.
2.2.2

Power Requirements

The RTM gets safety extra low voltage (SELV) power from the front blade.
Table 2-3
Characteristic
Measured Max Power dissipation of RTM-ATCA-736x-10G
30
Power Dissipation
RTM-ATCA-736x-10G Installation and Use (6806800P29G)
Hardware Preparation and Installation
Value
30W
