The following table lists the types of Ethernet controllers
Table 3-2
Front Panel Location Controller
ETH1 1G/10G
ETH2 1G/10G
ETH3 1G/10G
ETH4 1G/10G
ETH5/6 1G
ETH7/8 1G
ETH9 1G/10G
ETH10 1G/10G
3.2.3.2

SAS Connector

The RTM-ATCA-736x-10G and RTM-ATCA-737x-10G blades provides one SAS connector
at its face plate. The location of the connector is shown in the following figure.
The RTM-ATCA-736x-10G-SP does not contain a SAS connector.

Figure 3-6 Location of SAS Connector

RTM-ATCA-736x-10G Installation and Use (6806800P29G)
Ethernet Controller Types
Intel 82599 (U52)
Intel 82599 (U40)
Intel i350 (U59)
Intel 82599 (U3)
Controls, LEDs, and Connectors
Count
2x
2x
4x
2x
Ethernet Type
1G SFP,10G SFP+
1G SFP,10G SFP+
10,100,1Gb Copper
1G SFP,10G SFP+
