The SAS switches can be implemented using discrete mount/no-mount option.
1.3

Standard Compliances

The product is designed to meet the following standards.
Table 1-1
Standard
UL/EN/IEC 62368-1 and 60950-1
CAN/CSA C22.2 No 60950-1 and
62368-1
CISPR 22
EN 55022
EN 55024
FCC Part 15
EN 300386
NEBS Standard GR-1089 CORE
ISO 8601
NEBS Standard GR-63-CORE
ETSI EN 300019 series
PICMG 3.0 and 3.1
1. The blade does not fulfill the "Unpacked Equipment Shock Criteria" as defined in NEBS GR63 4.3.2. During tests which
consisted of dropping the blade from 100 mm height, we observed that on some blades the ATCA zone 2 and 3 connectors got
damaged. Although it was possible to manually repair the connectors and the blade was fully functional again afterwards, the
criteria imposed by the NEBS standard were not fulfilled.
The product has been designed to meet the directive on the restriction of the use of
certain hazardous substances in electrical and electronic equipment (RoHS)
Directive 2011/65/EU.
RTM-ATCA-736x-10G Installation and Use (6806800P29G)
Standard Compliances
1
Description
Legal safety requirements
EMC requirements on system level (predefined
SMART Embedded Computing system)
Y2K compliance
NEBS level three
Product is designed to support NEBS level three. The
compliance tests must be done with the customer
target system.
Defines mechanics, blade dimensions, power
distribution, power and data connectors, and system
management
Introduction
25
