13. Spare part list
Pos.
Pcs.
Designation
1
1
Pump housing (can only be ordered together with pos.2) ......................................................................... F0619/01-10
2
1
Delivery piston (can only be ordered together with pos.1) ........................................................................ F0619/02-03
3
1
Spring centring ring ................................................................................................................................... F0619/03-03
4
1
Piston centring ring .................................................................................................................................... F0619/04-03
5
0-1
Screw connection (G¼) ............................................................................................................................. F0619/05-01
0-1
Screw connection (M10x1) ................................................................................................................. F0619/05-02 001
0-1
Screw connection (9/16"-18 UNF) ...................................................................................................... F0619/05-03 001
6
1
Set screw ................................................................................................................................................... F0619/06-04
7
1
Counter nut ................................................................................................................................................ F0619/07-00
9
1
Ventilation screw M10x1 ........................................................................................................................... 0802000255
10
1
Sealing ring A10x13,5x1,5 .................................................................................................................... 090760305121
11
1
Pressure spring D-40031 (hydraulic) ........................................................................................................... 104005147
12
1
Grooved ring NI 300 .............................................................................................................................. 100150090316
13
1
Valve interior parts .................................................................................................................................... 0438010001
14
1
Retaining ring 9x0,8 .............................................................................................................................. 090047202411
15
1
Sealing ring A36x42x2 .......................................................................................................................... 090760307811
16
1
O-ring 13,5x1,5 .................................................................................................................................. 09037710125141
17
1
Sealing washer ............................................................................................................................................ 080100134
18
1
O-ring 38x4 ........................................................................................................................................ 09037710315141
19
1
O-ring 55x4 ........................................................................................................................................ 09037710286181
20
1
Cartridge type S – EP 2 grease, 400g ............................................................................................................. 0320252
21
1
Sealing screw M10x1 ............................................................................................................................ 090090800213
22
1
Sealing ring A10x14x1 .......................................................................................................................... 090760300311
...a product of
Page 12
Order-no
© BEKA 2015 All rights reserved!
