SubSurface Instruments LD-18 Operation Manual page 58

< >=Order Code
1 Sensitivity knob <234121>
Company name label <234117>
2
3 Color button (black) <incl. No.14>
Membrane switch <234119>
4
5 Sensitivity switch assembly <234138>
Housing case (Upper side) <234134>
6
7 with LCD panel <234134>
LCD harness assembly with chassis <234142>
8
9 Rubber washer for sensitivity switch <228406>
Case bracket (A) <228313>
10
11 Case bracket (B) <228314>
Tapping screw (3x8)
12
Tapping screw (3x16)
13
14 Short-circuit switch assembly <234140>
Battery holder <228303>
15
16 Flat tapping screw (3x25)
PCB bracket <234116>
17
18 Spring washer
Small screw (M3x6)
19
20 PCB assembly for USB <234128>
and the connecting harness <234141>
21 Battery terminal base <228205>
Battery spring <046128>
22
23 Tapping screw (3x10)
Tapping screw (3x8)
24
25 Metal washer
Stiffening plate for snap latch <228315>
26
27 Tapping screw (3x6)
Hexagon nut (M3)
28
29 Waterproof cover for USB connector <234120>
Power harness assembly <234139>
30
31 Hexagon nut (M14) <228402>
Harness assembly of sensor input <234135>
32
33 Holding plate for P.U. <228320>
Waist belt fittings <007113>
34
35 Binding small screw (M3x10)
Battery cushion <234125>
36
37 Serial numbers label
Tapping screw (3x16)
38
39 Smal screw (M3x10)
Serial No. panel label (silk print) <234118>
40
41 Waterproof cover for headphone <228407>
Housing case (Lower side) <234133>
42
Hedphone harness assembly <234136>
43
44 Small screw (M3x5)
Model name plate <234115>
45
46 Headphone connector cove <234009>
Digital PCB <234126>
47
48 Spacer <234132>
Analog PCB <234127>
49
50 Rubber cushion for battery latch <234131>
Snap latch for battery <007114>
51
52 Snap latch base <228309>
Battery cover <228308>
53
54 Small screw (M2x6)
Small screw (M2x4)
55
56 Battery terminal base <234113>
Hexagon nut (M2)
57
58 Battery cover packing <228405>
Battery terminal <228311>
59
53
Parts list and illustrations
