5-3 Graph screen

The graph screen displays saved data in a graph format.
The data displayed in a lift format on the left-hand side of the screen is displayed in a graph format on the
right-hand side of the screen.
* Caution
In case flags were set in the file list screen, data of the section beginning with data next to data
with flag to the latest data or to the next data with
Up to ten (10) data is displayed in a screen format. When ten data is exceeded,
appears at the bottom of the graph on the right-hand side of the screen, and the graph can be
scrolled using
Rightward scroll occurs when the switch is pressed.
HI
Leftward scroll occurs when the switch is pressed.
LO
and switches.
LO
HI
flag is displayed in a graph format.
20
