SUBSURFACE
INSTRUMENTS,
AML PRO
™
OPERATOR'S
MANUAL
INC.
• Originally designed by NASA engineers
for use in lunar exploration
• Re-designed to find buried objects and pipes of all kinds
including PVC, PE, Rubber, Steel, etc.
• Patented, Radio Frequency Technology
• Lightweight, Durable Construction
www.ssilocators.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AML PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SubSurface Instruments AML PRO

Summary of Contents for SubSurface Instruments AML PRO

  • Page 1 SUBSURFACE INSTRUMENTS, INC. AML PRO ™ OPERATOR’S MANUAL • Originally designed by NASA engineers for use in lunar exploration • Re-designed to find buried objects and pipes of all kinds including PVC, PE, Rubber, Steel, etc. • Patented, Radio Frequency Technology •...
  • Page 2 AML SAFETY INFO READ & OBSERVE ALL INSTRUCTIONS Save these instructions for future reference. INSPECTION OF THE AML PRO DO NOT open the housing of this unit, doing so will damage the transmission and receiving antennas. There are no user serviceable parts inside. Opening the sealed case will void the warranty.

  • Page 3: Operation

    II/2M laser. Avoid direct exposure to the beam. Do not direct the laser beam at People or animals. Do not stare into the laser beam. The AML Pro produces Laser Class II/2M laser radiation according lish to IEC 60825-1. Looking directly into the...
  • Page 4 User Reference - Scanning QR Codes The AML Pro has several QR Codes placed on the blade’s face. Scan these codes for more operator information, and for continu- ing updates provided by the manufacturer. AML Pro additional information can be accessed from your smart phone using a stan- dard QR code App.

  • Page 5: Fcc/Ic/Ce Statements

    FCC/IC/CE STATEMENTS Currently under Test Certification. IC (Industrie Canada) Currently under Test Certification. CE (European Countries) Currently under Test Certification.
  • Page 6 AML PRO FEATURES Backside view of unit...
  • Page 7 AML Pro for extended periods of time in all weather conditions. 3) CONTROL PANEL There are six function buttons on the AML Pro control panel, these buttons will provide you with the ability to navigate through the Menu Screen, as well as having access to the many features on your AML Pro Unit.
  • Page 8 Unit, in such case turn the AML Pro off wait for 10 seconds and then turn it back on. Also, turn the AML Pro off before the auto shutoff setting for low battery turns the Unit off.

  • Page 9: Flow Chart

    FLOW CHART MAIN SCREEN INTERFACE 27 57 sats Time Status Messages 4494 N Angle º Latitude Location 6298 W Sensitivity Longitude Phase Bars GENERAL STATUS MESSAGES STATUS MESSAGES OPERATE RF transmitter on STANDBY RF transmitter off POWER EVENTS USB PWR External battery plugged in BAT PWR Internal battery plugged in...
  • Page 10 GENERAL STATUS MESSAGES GPS EVENTS SATS Number of GPS Satellites LOGGED Log record filed to memory NO LOCK No GPS satellites found FULL No room for new logs DISCARD Erase records from memory EMPTY No records saved in memory CALIBRATION EVENTS PASS System ready RF TEST...
  • Page 11 OPERATION OF THE AML PRO Figure 11-1 OPERATOR FUNCTION CONTROLS There are six function buttons on the AML Pro control panel: 1. On/Off - Press and hold the On/Off Button to turn the unit On or Off. 2. TX (Transmitter) - Press the TX Button to turn the transmitter On or Off.
  • Page 12 AML Pro. Figure 12-2 shows the (Sensitivity Level) selected SENSITIVITY Level of the AML Pro (1 to 32). Use the UP or DOWN arrow Buttons to set the SEN 27 57 sats level from 1 to 32 with 32 being the 4494 N most sensitive.
  • Page 13 AML PRO MENU SETTINGS Press the MENU Button to show the AML Pro selectable functions and settings. NOTE: The MENU will time out after 30 seconds if no changes are made. Either press the Menu button, or let the MENU time out to save changes. If the unit is turned off while in the menu screen, it will NOT save the changes recently made.
  • Page 14 SLEEP SEC delay from 0, 10, 20 or 30 seconds. This function places the factory sett i ngs AML Pro in sleep mode, or pause, once the unit has stopped sensing Figure 14-1 motion. When the AML Pro goes into...
  • Page 15 The FACTORY SETTINGS returns > factory sett i ngs all items in the first menu screen of the AML Pro to the settings and Figure 15-3 specifications as originally set at the factory. All memory data will be erased speaker volume if the unit is reset to factory settings.
  • Page 16 Set to adjust the time manually. This time change will have to be re-entered manually to come back from Daylight Savings Time. The TIME ZONE SET will have to be reset if the AML Pro is transferred for use in other time zones.
  • Page 17 The above Table shows the TIME ZONE SET value versus LOCAL TIME. To set the Real Time Clock (RTC) on your AML Pro unit using the value table located at the bottom of this map, enter the two digit OFF-SET value (00 - 23) that is relative to the...
  • Page 18 27 57 RF test 27 57 wait > CALIBRATE (Radio Frequency Calibration) T i me zone set The CALIBRATE function recalibrates > Cal i brate 27 57 pass the RF Board from backup files in the backl i ght off/on microprocessor.

  • Page 19: Event Messages

    4494 N The USB PWR indicates when the 4494 N auxiliary battery pack is connected to 6298 W 6298 W the AML Pro. Turn the AML Pro Unit Figure 19-1 27 57 usb pwr OFF before connecting the external 27 57...

  • Page 20: Logging Events

    SATS (Satellites) 27 57 sats The SATS line indicates the number 4494 N of satellites in which the AML Pro is 6298 W 27 57 no lock communicating. To increase the level 0000 N of accuracy it is preferable to use 7 or...

  • Page 21: Calibration Events

    AML Pro to the external lithium battery supply or connect the AML Pro to a computer to recharge the coin battery. Every time a CLK BAT event takes place, the TIME ZONE SET needs to be reset.
  • Page 22 USING THE AML PRO Operation of the AML Pro is technique sensitive. We advise that you practice on a known buried object like a culvert pipe or other partially exposed objects. Once the principals of operation are understood, acquiring a technique is relatively simple with a little practice.
  • Page 23 Locating an Object with the AML Grip the AML Pro by the handle with the fingers firmly placed along the finger knurls. Do not hold the unit above the knurls as it will produce false readings. Hold the handle parallel to the ground at waist level and 12 to 24 inches out in front of your body.
  • Page 24 Objects are further than they appear Tilt the handle 10º when locating the when in the searching position. exact edge of an object. 10° Blade Face Blade Face Figure 24-1 Figure 24-2 10° Note: Read the Safety Notes before operating your AML Pro.
  • Page 25 Make sure you found the pipe by scanning 3’ to either side 4. Mark the spot on the ground 5. The distance between both points, is the depth of the pipe * AML Pro has an integrated level to determine 45º angle. Subsuface pipe or object...

  • Page 26: Battery Replacement

    Battery Pack (Houses (3) 9-Volt Batteries) IMPORTANT: Turn the AML Pro OFF before replacing batteries or before connecting the battery pack. To Replace Batteries in Your AML Pro Unit: 1. Unscrew the battery access cap and remove the battery sleeve.

  • Page 27: Technical Specifications

    • Cube ....23”l x 19”w x 9”h 58.4cm x 48.3cm x 22.9cm • Weight ..17lbs ......7.7kg Includes • (1) AML Pro Unit • (2) Battery Sleeves (Each housing [3] 9-Volt Batteries) • (1) Lithium Rechargeable Battery Pack with Battery Chargers and Cables •...
  • Page 28 SSI sub folder. Extracting GPS Coordinates Figure 28-2 1. Connect your AML Pro to your computer with the supplied USB mini cable. Turn on the AML Pro, automatic notifications Figure 28-3...
  • Page 29 Figure 29-2 - Check the box for “Run as administrator” and click “OK” - “Apply” the changes then click “OK” 2. Run the GPS Log Transfer application 3. Computer will automatically recognize the COMM Port the AML Pro is Figure 29-3...
  • Page 30 .XML and .CSV (Comma Separated Value) formats. 7. You will be prompted to “Clear AML Figure 30-2 GPS Records” upon successful completion of the file transfer; choose “Yes” to clear the AML Pro’s logs, “No” to retain the current logs. Exit software.

  • Page 31: Appendix (Firmware Update)

    Downloads Tab: http://www.ssilocators.com/specialty- products/all-materials-locator-pro-series/ The AML Unit shows the current firmware version on the top left of the LCD screen as the AML Pro Figure 31-3 is powering up, when you need to update your...
  • Page 32 3. Connect your AML Pro to your computer with the supplied USB mini cable. Turn on the AML Pro; if this is the first time connecting this AML Pro to the computer, follow step “4”. Otherwise go to step “5”.
  • Page 33 Figure 33-3 Remember the Firmware Update process brings your unit back to factory setting. Go to page 16 to adjust the AML Pro to your Time Zone, Make note that the AML Pro DOES NOT adjust for Daylight savings, add one(1) to your Time Zone Set to adjust the time manually.

  • Page 34: Warranty Statement

    WARRANTY STATEMENT Warranty Period: 36 months Failure to register your or (3) years from original user’s AML Pro within 30 days purchase date. The All Materials of receipt, will void the Locator-Pro (AML Pro) is warranty. Any unit suspected of being...
  • Page 37 Instruments Inc. Locating accuracy and safety, all encompassed, are the sole responsibility of the “Operator- user” of the product. SubSurface Instruments, Inc. is not responsible for errors and/or omissions in this manual. Information in this manual is subject to change without notice.
  • Page 38 SubSurface Instruments, Inc. 920.347.1788 phone 920.347.1791 fax 855.422.6346 (855-I-can-find-it) info@ssilocators.com www.ssilocators.com Proudly Made in the USA Your Local Dealer: Rev 08/2015...
