11.2 INTE PRESSURE TRANSDUCER SPECIFICATIONS
Accuracy
Expressed in %FS as constant temperature.
Accuracy as RSS non-linearity, hysteresis and non-repeatability
ROOM SUM SQUARES (RSS)
NON-LINEARITY (±0.1%)
HYSTERESIS (±0.05%)
NON-REPEATABILITY (±0.02%)
√0.0129%
Total Error Band
(Worst Case) Over a Temperature Range of -10
Non-Linearity:
Hysteresis:
Non-Repeatability:
Thermal Zero Shift:
Thermal Span Shift:
Zero Offset:
Span Offset:
Long-term stability error not included.
0.01%
2
0.0025%
2
0.0004%
2
0.0129%
±0.11%FS at constant temperature
±0.1% FS
±0.05% FS
±0.02% FS
<±0.32% FS
<±0.24% FS
±0.2% FS
±0.2% FS
±1.13% FS
F to 130 F
o o
