5.5 GETTING STARTED

1. Open calibrator top.
2. Turn on calibrator power by toggling the power button towards the back of the unit
(power switch on left side of the calibrator see Diagram 7).
3. Once calibrator is powered up, re-zero function begins automatically. Please wait for
completion. (User will hear operation of solenoid valves and stepper motor).
4. Software will startup with Real-Time Page. Select desired UUT from drop-down to
begin performing calibrations. (See Section 6.5 to setup new UUT profiles)
Power
Switch
RS232
Expert System Interface
Diagram 7
14
