- Page 2 Assembly Instructions 2/4 IMPORTANT Wood Screw * Do not tighten up all the bolts until each part is properly assembled. * You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future. * Use a soft cloth between these parts and the floor.
- Page 3 Assembly Instructions 3/4 STEP 4 Head Cap Bolt Slide Back Panel (F) into place. Attach Back and Front Stretcher (I), (J) to the unit with Head Cap Bolts. Attach Side Panel (C) to the other side of unit with Head Cap Bolts. Head Cap Bolt STEP 5 Attach Side Rack (Q) to Side Panel (B) with...
- Page 4 Assembly Instructions 4/4 STEP 8 Cam Lock Screw Turn over Top (A) and put Cam Lock Screws into the pre-drilled holes. Tighten up Cam Lock Screws. STEP 9 Place Top (A) onto the unit. Cam Lock Put Cam Locks into the holes of the Side Panel (B) and (C) and tighten all Cam Locks as to secure the top with...
-
Page 5: Hardware List
88 5086 95C Drawer (N) UNIT PART LIST HARDWARE LIST Pull Handle 3 pcs. Front Part Wood Screw (short) 1 pc. for each Side Part for base part drawer. 1 pc. for each Side Part 18 pcs.(+1 extra) drawer. 1 pc. for each drawer. - Page 6 88 5086 95C Drawer (O) UNIT PART LIST HARDWARE LIST Pull Handle 1 pcs. Front Part Wood Screw (short) Side Part 1 pc. Side Part for base part 1 pc. 1 pc. . 6 pcs.(+1 extra) Base Part Back Part...
