88 5080 941
Kitchen Island
IMPORTANT NOTE
.
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure
a completed product as it was designed.
Part List
Hardware List
Small
Hex Wrench
Hex Wrench
1 pc.
1 pc.
M6x35
Head Cap Bolt
16 pcs. (+1 extra)
For assembly see instructions in carton 88 5080 942
Tools required for assembly : Phillips screwdriver
F.
Foot
4 pcs.
Flat Washer
4 pcs.(+1 extra)
M6x50
Head Cap Bolt (long)
4 pcs. (+1 extra)
Adjustable Pin
Cam Lock
4 pcs. (+2 extra)
4 pcs.(+2 extra)
Cam Lock Screw
Spring Washer
4 pcs.(+1 extra)
4 pcs.(+1 extra)
Tools recommended for assembly : Level
A.
Top
1 pc.
Pull Handle
8 pcs.
M4x25
Machine Screw
8 pcs.
