88 5022 611
Nantucket
Buffet
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A .
Top
1 pc.
C.
Front Rail
1 pc.
F.
Back Rail
1 pc.
H.
Door
1 pc.
For assembly see instructions in carton : 88 5022 612
I.
Door
1 pc.
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
B.
Bottom
1 pc.
D.
Front Rail
1 pc.
J.
Back Post
1 pc.
E.
Back Rail
1 pc.
G.
Shelf
2 pcs.
K.
Back Post
1 pc.
L.
Back Panel
3 pcs.
