1. Introduction
This manual is the reference guide when setting up the DinBox RTU M4 device
accompanied with the IEC60870-5-104 application firmware.
Because of the nature of this product and it's field of application, some degree of
technical background knowledge regarding the application and data-communication is
assumed.
This RTU has 8 digital inputs, 2 digital outputs and 2 analog inputs. It can send/receive
data to/from a IEC60870-5-104 master via a GSM (GPRS) network.
The main functionalities of the DinBox RTU M4 are :
 DIN rail mountable housing
 Configuration, setup and monitoring via a GUI via HTML in a standard web browser
 2 x non-isolated analog inputs
 8 x active galvanically isolated digital inputs
 2 x galvanically isolated and independent digital outputs
 2 x analog inputs
 Sierra Wireless HLxxxx 2G 3G 4G WAN module
 SIM card holder
 ST Cortex M4 STM32 processor
 2 x 64K FRAM [8.192*8 bit]
 optional MMC/SD card holder
 optional Power backup via SuperCap
 galvanically isolated 2-wire RS485 interface
