- Page 1 Garda Roll Roll Easy Micro Micro Easy MOTORI TUBOLARI TUBULAR MOTORS ROHRMOTOREN MOTEURS TUBULAIRES MOTORES TUBULARES ISTRUZIONI - INSTRUCTIONS - EINSTELLANLEITUNGEN INSTRUCTIONS - INSTRUCCIONES...
- Page 3 TRANSLATION OF THE ORIGINAL INSTRUCTIONS ELECTRICAL CONNECTIONS - To prevent any danger or malfunction, the size of electrical control components connected to the motor must be compatible with the electrical features of the motor. - Means for disconnection must be incorporated in the fixed wiring in accordance with the national installation standards.
- Page 4 1- brown 2- black 3- blue 4- yellow-green...
- Page 5 HOW TO PREPARE THE MOTOR STOP RING NUT ADAPTOR DRIVING PULLEY STOP RING NUT 1. Insert the adaptor in the stop ring nut mating the groove with the reference notch and push till they touch. 2. Fix the driving pulley on the motor pin until the stop pin clicks.
- Page 6 ADJUSTING limit switch. SCREWS STOP RING NUT EU DECLARATION OF CONFORMITY CHERUBINI S.p.A. declares that the product is in conformity with the relevant Union harmonisation legislation: Directive 2014/35/EU Directive 2014/30/EU Directive 2011/65/EU The full text of the EU declaration of conformity is available upon request at the...
- Page 8 CHERUBINI S.p.A. Via Adige 55 25081 Bedizzole (BS) - Italy Tel. +39 030 6872.039 | Fax +39 030 6872.040 info@cherubini.it | www.cherubini.it CHERUBINI Iberia S.L. Avda. Unión Europea 11-H Apdo. 283 - P. I. El Castillo 03630 Sax Alicante - Spain Tel.
