16.8 Protective fi elds
16.8.1
Front protective fi elds
Table 13: When driving forward
Zone
Vreg
Vmax
[mm/s]
[mm/s]
1
0
50
2
300
350
3
650
700
4
1000
1050
3 842 560 593/2020-07 ActiveShuttle: ActiveShuttle 1.0, Bosch Rexroth AG
Protective fi eld
Protective fi eld
Width
Length
[mm]
[mm]
500
270
100
700
460
100
100
900
690
100
100
900
970
200
100
Technical data
61/68
100
100
100
100
100
100
100
200
100
100
100
