4 Scope of delivery

The scope of delivery includes the following, according to customer order:
• 3 842 560 431 ActiveShuttle 1.0 Transport vehicle incl. square spanner, mounted
lifting aid, operating instructions "ActiveShuttle 1.0 Transport vehicle"
• 3 842 560 106, Handheld Controller 1.0
• 3 842 560 422, Charging station ActiveShuttle 1.0 incl. operating instructions
"ActiveShuttle 1.0 Transport vehicle"
• 3 842 560 101, Lithium-ion battery incl. operating instructions
"ActiveShuttle 1.0 Transport vehicle"

4.1 Condition on delivery

• Transport vehicle ActiveShuttle 1.0 ready for use incl. lithium-ion battery and
installed lift aid
• Handheld controller 1.0 ready for connection
• Charging station ActiveShuttle 1.0 ready for connection
• Lithium-ion battery ready for connection

5 About this product

5.1 Specifi cations
5.1.1

Use

ActiveShuttle 1.0
• Automated material transport in production with operator-defi ned
– driving ranges
– loading and unloading points and
– speeds
in areas used jointly with passenger traffi c.
• Transport of KLTs stacked on dollies with a
– total weight incl. dolly of up to 260 kg and a
– max. stacking height of 1,200 mm.
Handheld controller 1.0
To control the ActiveShuttle 1.0 in the "Manual" operating mode
Charging station ActiveShuttle 1.0
To charge the lithium-ion battery in the ActiveShuttle 1.0.
