Q:
Emergency stop
device, rotary release
S:
"Release brake"
buttons
G:
Bluespot
F:
Warning signal lamps
E:
Personal protection
system (laser scanner)
Not visible:
• Acoustic signal
transmitter
5.3 Safety and warning devices
E
F
S
F
Fig. 5:
Safety devices and warning signs
3 842 560 593/2020-07 ActiveShuttle: ActiveShuttle 1.0, Bosch Rexroth AG
Q
S
Q
About this product
25/68
G
F
E
E
F
560 592-09
