ACTi TCM-7411 Specifications

Fi xe d D o m e C am e ra
TCM-7411
PHOTO INDICATION
1
2
1 Ethernet Port
2 DC 12V Power Input
ACCESSORY OPTIONS
Dome Cover
PDCX-1101
w w w . a c t i . c o m
3
4
3 Reset Button
4 Audio Input / Output &
Digital Input / Output
4-inch, smoke, vandal proof
* Latest product information: www.acti.com/product/
* Accessory information: www.acti.com/accessory/
H.264 Megapixel IP D/N Outdoor
Vandal Proof PoE Rugged Dome
• 1/3" Aptina Progressive Scan CMOS
• Day and night function with mechanical IR cut fi lter
• Minimum illumination 0.05 Lux at F1.0
• Built-in f3.3 - 12 mm / F1.6 Megapixel vari-focal lens
• 18 fps at 1280 x 1024 resolution
• Selectable H.264, MPEG-4 SP, MJPEG compressions
with dual streaming
• Two-way audio
• Video motion detection
• Digital input and digital output
• Wide Dynamic Range
• Vandal proof and weatherproof IP66 rated casing
• Powered by PoE Class 3 / DC 12V

DIMENSION DIAGRAM

Popular Mounting Solutions
Surface Accessories not required
Wall PMAX-0308
Pendant PMAX-0101
PMAX-0103
Corner PMAX-0101
PMAX-0303
PMAX-0402
Pole PMAX-0101
PMAX-0303
PMAX-0502
Flush PMAX-1003
* For more mounting solutions, please refer to Mounting Accessory section of Buyer's
Guide or Project Planner on www.acti.com
Unit: mm [inch]
+
+ +
+ +
110809
