ACTi TCM-1231 Specifications

B ull e t C am e ra
TCM-1231
* The bracket needs to be purchased separately.
PHOTO INDICATION
1
2
3
1 DC 12V Power Input
2 Audio Input / Output &
Digital Input / Output
ACCESSORY OPTIONS
Camera Bracket
PMAX-1103
w w w . a c t i . c o m
4
3 Reset Button
4 Ethernet Port
Aluminum, max. load 10 kg (22.05
lb), tilt angle 90°, swivel angle 360°
* Latest product information: www.acti.com/product/
* Accessory information: www.acti.com/accessory/
H.264 Megapixel Outdoor IP
IR D/N PoE Bullet Camera
• 1/3" Aptina Progressive Scan CMOS
• Day and night function with mechanical IR cut fi lter
• Minimum illumination 0 lux with IR LED on
• Built-in f3.3-12 mm / F1.6 Megapixel vari-focal lens
• 18 fps at 1280 x 1024 resolution
• Selectable H.264, MPEG-4 SP, MJPEG compressions
with dual streaming
• Two-way audio
• Video motion detection
• Digital input and digital output
• Wide Dynamic Range
• Weatherproof IP66 rated casing
• Powered by PoE Class 3 / DC 12V

DIMENSION DIAGRAM

77[3.03'']
50[2'']
Popular Mounting Solutions
Corner PMAX-1103
PMAX-0402
Pole PMAX-1103
PMAX-0502
* For more mounting solutions, please refer to Mounting Accessory section of Buyer's
Guide or Project Planner on www.acti.com
220.00[8.7'']
195.45[7.7'']
207.40[8.2'']
Unit: mm [inch]
+
+
110809
