This guide contains the basic information you need to quickly setup the
Camera. For detailed information on installations or operations, please refer
to the Hardware Manual and Firmware Manual on ACTi website
(www.acti.com).
Step 1: Unpack the Device
Check the camera package and make sure all items are present. The
complete package list is shown on the camera Hardware Manual.
Step 2: Mount the Device
Mounting varies per camera model. Check the most suitable mounting
method from the Hardware Manual or from our Mounting Accessory
Selector Tool (www.acti.com/mountingselector).
Step 3: Connect the Device
Basic Connection Example
PC
Camera
Camera
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
Quick Installation Guide
PoE Switch
Camera
Camera
Power Source
Camera
Camera
Camera
Advertisement
Table of Contents
Related Manuals for ACTi E933M
Summary of Contents for ACTi E933M
- Page 1 Quick Installation Guide This guide contains the basic information you need to quickly setup the Camera. For detailed information on installations or operations, please refer to the Hardware Manual and Firmware Manual on ACTi website (www.acti.com). Step 1: Unpack the Device Check the camera package and make sure all items are present.
- Page 2 Go to Start > My Computer > Network. b. Double-click on the device name. By IP Utility a. Download IP Utility from our website (www.acti.com). b. Run IP Utility to start searching for network devices. c. Click the IP address of the Camera.
- Page 3 On Network without DHCP Server (Default IP) 1. If necessary, configure the IP settings of your PC to match with the network segment of the Camera. PC can be assigned with Camera Defaults IP Address (different from Camera) IP Address: Example: 192.168.0.100 192.168.0.99...
- Page 4 Setup menu to modify the Camera settings. For more detailed instructions, please refer to the “Firmware Manual” downloadable from the website (www.acti.com). ACTi Connecting Vision and its logo are registered trademarks of ACTi Corporation. Microsoft and Windows are registered trademarks of Microsoft Corporation.
