Chapter 3

FRONT PANEL

The TSU 600 front panel both monitors operation and controls the con-
figuration of the unit. The TSU 600 front panel is shown in Figure 3-1 on
page 3-4. Descriptions of each part of the front panel follow.
Name
LCD Window
Enter
Up and down
arrows
Cancel
Numeric Keypad The numeric keypad contains the numbers 0
61202076L1-1
Operation
Description
Displays menu items and messages in two lines by
16 characters. It also displays alarm and status
information.
Selects active menu items. To select a menu item,
press the number of the item. The menu item
flashes, indicating it is activated. Press Enter to
select the menu item.
Up and down arrows are used to scroll through
and activate the submenu items available in the
current menu. When the submenu items are
scrolled, the flashing cursor indicates the active
parameters.
Pressing the Cancel key stops the current activity
and returns the display to the previous menu.
Repeat until the desired menu level is reached.
When a submenu item is displayed, press Cancel
to exit the current display and return to the previ-
ous menu.
through 9 which are used to activate menu items
and enter information (such as the IP address).
TSU 600 User Manual 3-1
